The GE DS200DTBDG1ABB is a high-density terminal board designed for GE Mark V Speedtronic turbine control systems. It acts as a structured signal interface between field wiring and internal control circuitry, enabling stable, organized, and noise-resistant signal distribution in complex industrial automation environments.
Widely deployed in power generation and heavy industry, this module is valued for its reliability in managing large volumes of digital and control signals while maintaining system integrity under harsh operating conditions.
Technical Specifications (with Dimensions & Weight)
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200DTBDG1ABB |
| Series | Mark V Speedtronic |
| Product Type | Terminal Board / Signal Interface Module |
| Function | Digital signal termination & expansion interface |
| Relay Capacity | Up to 20 relays (typical configuration) |
| Terminal Capacity | High-density multi-signal termination |
| Connector Types | 34-pin / 40-pin connectors + auxiliary interfaces |
| Operating Voltage | 12–24 VDC (system dependent) |
| Contact Rating | Up to 10A switching capacity |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | approx. 210 × 125 × 30 mm |
| Weight | approx. 0.6–2.0 kg (varies by revision) |
| Mounting Type | Rack-mounted industrial control cabinet board |
Its compact yet robust structure ensures efficient installation inside GE turbine control racks without compromising signal density or stability.
Recommended Related Models
- GE DS200DTBBG1ABB Digital Input Expansion Board
- GE DS200QTBAG1ACB RST Terminal Board
- GE DS200QTBAG1ADC Enhanced Terminal Board
- GE DS200RTBAG3AHC Relay Terminal Board
- GE DS200DCFBG1A Power Supply Module
These modules are commonly integrated into Mark V systems for full-scale turbine control and signal management.
