Allen Bradley 1768-M04SE CompactLogix 4-Axis Sercos Interface Module
Allen Bradley 1768-M04SE CompactLogix 4-Axis Sercos Interface Module
0.0
Points
Brand:Allen Bradley PLC Item No.:1768-M04SE Product Origin:USA Product Dimensions:132.02 x 56.68 x 105.1 mm Product Weight:0.2 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1768-M04SE CompactLogix 4-Axis Sercos Interface Module delivers advanced motion control capability for industrial automation systems requiring accuracy, speed, and dependable synchronization. Designed for machine builders and automation engineers, this module provides an efficient connection between CompactLogix controllers and servo motion systems.
With its multi-axis control capability and high-speed communication performance, the 1768-M04SE helps improve machine productivity, enhance positioning accuracy, and simplify complex motion system development.
This module is an ideal solution for manufacturers seeking reliable motion control performance in advanced automation applications.
Technical Specifications
Specification
Details
Product Model
1768-M04SE
Product Type
CompactLogix 4-Axis Sercos Interface Module
Product Series
CompactLogix
Motion Axes Supported
4 Axes
Communication Interface
SERCOS Interface
Communication Data Rate
4 Mbps / 8 Mbps
Motion Control Type
Position and Velocity Control
Supported Applications
Servo Motion Control Systems
Backplane Current
969 mA at 5.2V DC
Power Dissipation
5.04 W
Mounting Type
DIN Rail or Panel Mounting
Module Configuration
Single Slot Module
Enclosure Type
Open Style
Dimensions (W × H × D)
132.02 × 56.68 × 105.10 mm
Weight
0.20 kg (0.44 lb)
Recommended Related Models
Model
Product Type
Description
Allen Bradley 1768-L43
CompactLogix Controller Module
CompactLogix controller designed for industrial automation applications
Allen Bradley 1768-L45
CompactLogix Controller Module
Advanced controller option for larger motion and control systems
Allen Bradley 1768-PA3
CompactLogix Power Supply Module
Power supply solution for CompactLogix control platforms
Popular Related Models
Model
Product Type
Description
Allen Bradley 1756-M08SE
ControlLogix Sercos Interface Module
Multi-axis motion interface solution for ControlLogix systems
Allen Bradley 1769-SM1
CompactLogix Communication Module
Communication expansion solution for CompactLogix applications
Allen Bradley 2094-BM02
Kinetix Servo Drive Module
Servo drive solution for advanced motion control systems
Industrial Applications
The Allen Bradley 1768-M04SE CompactLogix 4-Axis Sercos Interface Module is a high-performance motion control solution designed for advanced automation systems requiring precise multi-axis synchronization and reliable servo communication. Built for CompactLogix control platforms, this module provides efficient SERCOS-based motion connectivity for machine builders developing high-speed and accurate motion applications.
Designed for demanding industrial environments, the 1768-M04SE enables coordinated axis control, improved machine performance, and flexible motion system integration across various automation industries.
Application Field
Typical Uses
Motion Control Systems
Multi-axis servo positioning, synchronized movement, and precision automation
Packaging Machinery
High-speed packaging lines, indexing systems, and automated handling equipment
Robotics Applications
Coordinated motion systems requiring accurate positioning control
Manufacturing Equipment
CNC-related machines, assembly systems, and production automation
OEM Machine Building
Custom machines requiring advanced servo communication and motion control
The 1768-M04SE provides engineers with a reliable motion interface solution for improving machine accuracy, productivity, and overall automation performance.
Advanced Motion Control Advantages
The Allen Bradley 1768-M04SE CompactLogix 4-Axis Sercos Interface Module combines precise motion management with efficient communication technology, delivering a powerful solution for modern industrial automation.
Advantage
Description
Four-Axis Motion Capability
Supports coordinated control of multiple servo axes for complex machine applications
High-Speed SERCOS Communication
Enables fast and reliable communication between controllers and motion devices
Precise Position Control
Provides accurate synchronization for demanding motion applications
CompactLogix Integration
Designed for seamless integration with CompactLogix automation platforms
Flexible Servo Connectivity
Supports advanced servo drive systems for industrial motion applications
Reliable Industrial Performance
Provides stable operation for continuous automation processes
Technical FAQs
1. What is the main function of the 1768-M04SE module?
The 1768-M04SE is a SERCOS interface module designed to provide motion control communication between CompactLogix controllers and servo drive systems.
2. How many motion axes can the 1768-M04SE control?
The module supports up to four coordinated motion axes for synchronized industrial applications.
3. What communication technology does this module use?
The module uses SERCOS communication technology for high-speed motion control data exchange.
4. Can the 1768-M04SE support servo drive applications?
Yes. It is designed for integration with compatible servo drive systems used in industrial motion applications.
5. What type of motion control applications are suitable for this module?
It is suitable for positioning systems, synchronized motion equipment, packaging machines, and precision automation systems.
6. How does the module improve machine performance?
It enables accurate axis coordination, faster motion response, and improved synchronization between control components.
7. Can the 1768-M04SE be installed in a CompactLogix system?
Yes. The module is designed specifically for CompactLogix automation platforms.
8. What programming environment is used for configuring this module?
The module is configured through compatible Logix programming software for developing and managing motion applications.
9. Does the module support feedback-based motion control?
Yes. It supports advanced motion applications requiring precise feedback and coordinated axis operation.
10. Is the 1768-M04SE suitable for high-speed industrial machines?
Yes. It is designed for applications requiring fast communication, accurate positioning, and reliable motion performance.
