GE IC200ALG230D VersaMax Analog Voltage/Current Input Module
GE IC200ALG230D VersaMax Analog Voltage/Current Input Module
0.0
Points
Brand:GE Fanuc PLC Item No.:IC200ALG230D Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200ALG230D VersaMax Analog Voltage/Current Input Module is a versatile analog interface designed for industrial automation systems requiring dependable acquisition of voltage and current signals. Featuring four configurable analog input channels, the module supports a wide range of standard industrial signal formats, making it suitable for process monitoring, machine automation, and distributed control applications.
With 12-bit conversion accuracy, rapid signal updates, and flexible jumper-selectable input ranges, the IC200ALG230D enables precise monitoring of field instrumentation while integrating seamlessly into GE VersaMax PLC architectures. Its compact construction and dependable performance make it an excellent solution for both new automation projects and maintenance of existing VersaMax installations.
Technical Specifications
Specification
Description
Manufacturer
GE Fanuc / Emerson
Model
IC200ALG230D
Product Type
Analog Voltage/Current Input Module
Product Family
VersaMax
Number of Inputs
4 Single-Ended Channels
Input Types
Voltage / Current
Voltage Ranges
±10 VDC, 0–10 VDC, ±5 VDC
Current Ranges
4–20 mA, 0–20 mA (External 250 Ω Resistor)
Resolution
12 Bit
Update Rate
0.4 ms per Channel
Input Filter Response
5 ms
Voltage Input Impedance
≥1 MΩ
Current Input Impedance
250 Ω (External Resistor)
Accuracy
±0.1% Full Scale (Typical at 25°C)
Isolation
Backplane-to-Field Electrical Isolation
Channel Isolation
None
Backplane Current Consumption
125 mA @ 5 VDC
Diagnostics
Internal Power Monitoring
Status Indicators
INT PWR LED, OK LED
Mounting
VersaMax I/O Carrier
Operating Temperature
0°C to +60°C
Dimensions
Approx. 110 × 66.8 × 50 mm
Weight
Approx. 0.24 kg
Recommended Companion Models
Model
Product Name
IC200CPU005
VersaMax CPU Module
IC200PWR102F
VersaMax Expanded Power Supply Module
IC200CHS022J
VersaMax Compact Box-Style I/O Carrier Module
IC200ERM002F
VersaMax Expansion Receiver Module
Frequently Selected Alternatives
Model
Product Name
IC200ALG240
VersaMax 8-Channel High-Resolution Analog Input Module
IC200ALG260C
VersaMax 8-Channel Analog Voltage/Current Input Module
IC200ALG264H
VersaMax 15-Channel Analog Current Input Module
IC693ALG223C
Series 90-30 Analog Current Input Module
Where It Excels in Industrial Use
GE VersaMax PLC analog signal acquisition systems
Process control applications requiring voltage and current monitoring
Pressure, flow, temperature, and level transmitter interfaces
Industrial machine performance monitoring
OEM equipment with distributed I/O architectures
Water and wastewater automation systems
Manufacturing process data collection
SCADA and remote telemetry installations
Energy management and utility monitoring
Factory automation systems requiring precise analog measurements
Key Strengths at a Glance
4-channel analog input module for voltage and current signals
Supports ±10 VDC, 0–10 VDC, ±5 VDC, 4–20 mA, and 0–20 mA inputs
12-bit analog-to-digital conversion for accurate measurements
Fast 0.4 ms channel update rate
Configurable input ranges via onboard jumpers
Electrical isolation between module and backplane
Compact VersaMax carrier-mounted design
Built-in diagnostic LED indicators
Flexible integration with VersaMax distributed I/O systems
Reliable performance in demanding industrial environments
Technical FAQs
1. What is the primary function of the GE IC200ALG230D?
The IC200ALG230D is a VersaMax analog input module that converts industrial voltage and current signals into digital values for processing by a GE VersaMax PLC. It provides four configurable analog input channels.
2. How many analog input channels are available?
The module provides 4 single-ended analog input channels, allowing multiple field instruments to be monitored simultaneously.
3. Which input signal ranges are supported?
The IC200ALG230D supports:
±10 VDC
0–10 VDC
±5 VDC
4–20 mA
0–20 mA (using an external 250 Ω resistor)
Input type and range are selected using onboard jumper settings.
4. What resolution does the module provide?
The module features 12-bit analog-to-digital conversion, delivering reliable signal resolution for industrial process control applications.
5. What types of field devices can be connected?
Typical connected devices include pressure transmitters, flow meters, temperature transmitters, level sensors, signal conditioners, and other industrial instruments providing standard analog voltage or current outputs.
6. Does the IC200ALG230D provide channel isolation?
The module provides electrical isolation between the module electronics and the VersaMax backplane, while individual input channels are not isolated from each other.
7. What is the input update speed?
The IC200ALG230D provides an update rate of approximately 0.4 ms per channel, enabling responsive acquisition of changing process signals.
8. How is the module configured?
Input modes and signal ranges are configured using onboard jumper selections, allowing the module to accommodate different voltage and current applications without additional hardware.
9. What diagnostic features are included?
The module includes INT PWR and OK LED indicators for monitoring internal power and module operating status, helping simplify troubleshooting and maintenance.
10. Which automation platform is compatible with the IC200ALG230D?
The IC200ALG230D is designed specifically for the GE VersaMax PLC and distributed I/O platform, installing directly onto compatible VersaMax I/O carriers.
