Brand:ABB PLC Item No.:1MRK000508-BD Product Origin:Sweden (SE) Product Dimensions:225 x 25 x 187 mm Product Weight:0.245 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ABB 1MRK000508-BD Binary Input Module is an industrial-grade digital signal processing component developed for reliable monitoring and control applications in power automation systems.
The module provides an important connection between field equipment and intelligent protection devices by collecting binary signals from external electrical components. It enables accurate monitoring of operational states, switching conditions, and alarm information, supporting faster response and improved system visibility.
Designed for ABB protection and control environments, the 1MRK000508-BD delivers stable performance in applications where signal accuracy and system availability are critical. Its compact structure and reliable electronic design make it suitable for substations, industrial facilities, and electrical infrastructure projects.
For engineers seeking dependable digital input expansion and replacement solutions, the ABB 1MRK000508-BD provides efficient integration and long-term operational reliability.
Technical Specifications
Parameter
Details
Manufacturer
ABB
Model Number
1MRK000508-BD
Product Type
Binary Input Module
Module Function
Digital Signal Acquisition
Input Channels
16 Binary Inputs
Input Type
RL110 Binary Input
Rated Input Voltage
110–125 VDC
Application
Protection and Control Systems
Signal Type
Digital Binary Signal
Mounting Type
Industrial Rack Installation
Dimensions
225 x 25 x 187 mm
Weight
0.25 kg (0.55 lb)
Operating Environment
Industrial Electrical Automation Systems
Recommended Related Models
Model
Product Type
Description
ABB 1MRK000508-CD
Binary Input Module
Digital input module designed for ABB protection applications
ABB 1MRK000614-AB
Binary Output Module
Output interface module for protection and control systems
ABB 500BIO01
Binary Input Module
Digital input expansion module for ABB automation platforms
ABB 500BID01
Binary Input Device
Industrial binary signal acquisition component
Popular Related Models
Model
Category
ABB 1MRK000508-BD
Binary Input Module
ABB 1MRK000508-CD
Digital Input Module
ABB 1MRK000614-AB
Binary Output Module
ABB 500BIO01
Protection I/O Module
ABB REG670
Generator Protection Relay
Applications
The ABB 1MRK000508-BD Binary Input Module is a high-reliability signal interface component designed for protection, monitoring, and automation systems. It is used to collect external digital signals from field devices and transfer accurate status information to ABB protection and control platforms.
This binary input module is widely used in:
Application Area
Description
Power Substation Automation
Monitors circuit breaker status, alarms, and switching signals in electrical substations
Generator Protection Systems
Provides reliable digital signal acquisition for generator monitoring and protection
Industrial Power Control
Integrates external equipment signals into automation and control systems
Electrical Distribution Networks
Supports status monitoring and event recording applications
Protection Relay Systems
Enables accurate binary signal processing for protection logic and diagnostics
The ABB 1MRK000508-BD is an ideal choice for system upgrades, equipment replacement, and maintenance projects where stable digital input performance is required.
Advantages
The ABB 1MRK000508-BD Binary Input Module provides dependable signal acquisition and efficient system integration for industrial electrical applications.
Advantage
Description
Accurate Digital Signal Detection
Ensures reliable recognition of external switching and status signals
Multiple Input Channels
Supports efficient monitoring of several field devices within one module
High System Compatibility
Designed for integration with ABB protection and control solutions
Stable Industrial Performance
Suitable for continuous operation in demanding electrical environments
Fast Event Monitoring
Helps protection systems respond quickly to status changes
Simplified Maintenance
Improves troubleshooting efficiency through reliable signal monitoring
With ABB’s proven protection technology, this binary input module helps improve operational reliability, reduce maintenance time, and enhance the performance of electrical automation systems.
