Brand:GE Fanuc PLC Item No.: IC200UAA007 Product Origin:USA Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200UAA007 Micro PLC Module is a compact industrial controller developed for the VersaMax Micro family. Combining PLC processing, AC digital inputs, AC triac outputs, serial communications, and an integrated universal AC power supply into a single unit, it delivers an efficient and dependable automation solution for standalone machine control.
Engineered for applications using 120 VAC field devices, the IC200UAA007 minimizes cabinet space while simplifying wiring and installation. Its isolated triac outputs provide reliable switching performance for industrial loads, while the integrated CPU offers dependable control for a wide variety of automation tasks.
With expandable architecture, proven VersaMax Micro reliability, and a rugged industrial design, the IC200UAA007 remains a practical solution for OEM equipment, production machinery, and modernization projects requiring long-term operational stability.
Technical Specifications
Parameter
Details
Model
IC200UAA007
Product Type
Micro PLC Module
Series
GE VersaMax Micro
Total I/O Points
28 Points
Digital Inputs
16 × 120 VAC Inputs
Input Type
AC Reactive Inputs
Digital Outputs
12 × AC Outputs
Output Type
Solid-State Triac Outputs
Output Voltage
120/240 VAC
Maximum Output Current
0.5 A per Output
Power Supply Input
100–240 VAC Nominal
Input Frequency
50/60 Hz
Input Power Rating
16 VA
High-Speed Counter
Not Supported
PWM / Pulse Train Output
Not Supported
Expansion Capacity
Up to 4 Expansion Units
Communication Ports
Dual Serial Ports
Real-Time Clock
Integrated
Mounting Type
Panel Mount
Operating Temperature
0°C to 55°C
Dimensions
150 × 90 × 76 mm
Weight
Approx. 0.60 kg
Recommended Companion Models
Model
Product Name
IC200UEX012
VersaMax Micro Expansion Unit
IC200UER016
VersaMax Micro Relay Output Expansion Module
IC200UEI016
VersaMax Micro Digital Input Expansion Module
IC200ACC403
VersaMax Micro Backup Battery
Frequently Selected Alternatives
Model
Product Name
IC200UAA003
VersaMax Micro 14-Point AC PLC Module
IC200UAR028
VersaMax Micro 28-Point Relay Output PLC Module
IC200UDD040
VersaMax Micro 40-Point DC PLC Module
IC200UDR040
VersaMax Micro 40-Point Relay Output PLC Module
Where It Excels in Industrial Use
• Designed for GE VersaMax Micro PLC systems, the IC200UAA007 integrates CPU processing, AC digital inputs, AC triac outputs, and an AC power supply into a compact controller for standalone industrial automation applications.
• Ideal for packaging equipment, conveyor systems, material handling machinery, HVAC control, and production equipment that primarily uses 120 VAC field devices.
• Suitable for applications utilizing pushbuttons, selector switches, limit switches, proximity sensors, signal lamps, and other industrial AC input and output devices.
• An excellent choice for OEM machine builders and retrofit projects where compact installation, dependable operation, and simplified wiring are key design requirements.
Key Strengths at a Glance
• Integrates a complete PLC solution with 16 AC inputs, 12 isolated AC triac outputs, CPU, communications, and power supply within one compact controller.
• Operates directly from a universal 100–240 VAC power source, eliminating the need for an external DC power supply.
• Features isolated output groups with replaceable fuse protection and RC snubber circuits for improved reliability when controlling inductive loads.
• Supports expansion with up to four VersaMax Micro expansion units, providing flexibility as automation requirements grow.
Technical FAQs
1. What type of module is the GE IC200UAA007?
The IC200UAA007 is a 28-point VersaMax Micro PLC with an integrated CPU, AC digital inputs, AC triac outputs, and AC power supply.
2. How many input channels are available on the IC200UAA007?
The controller provides 16 isolated 120 VAC digital input channels.
3. How many output channels does the module provide?
It includes 12 isolated 120/240 VAC triac output channels.
4. What type of outputs are used in the IC200UAA007?
The controller uses solid-state triac outputs designed for switching AC loads.
5. What power supply does the controller require?
The IC200UAA007 operates from a nominal 100–240 VAC power source at 50/60 Hz.
6. Does this PLC support high-speed counters or pulse train outputs?
No. This model does not support high-speed counters, PWM, or pulse train output functions.
7. Can the AC inputs accept DC signals?
No. The input circuits are designed exclusively for AC input signals.
8. Can expansion modules be connected to the IC200UAA007?
Yes. The controller supports up to four VersaMax Micro expansion units depending on the application.
9. Are the output groups electrically isolated?
Yes. The triac outputs are arranged in isolated groups with independent commons and replaceable fuse protection.
10. What should be verified before replacing the IC200UAA007?
Confirm the AC supply voltage, field wiring, output load ratings, PLC program compatibility, communication settings, and expansion configuration before installation.
