Brand:Schneider PLC Item No.:HMIDT643 Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider HMIDT643 Touchscreen Display Module is a high-performance operator interface component from the Harmony GTU series, designed for advanced industrial visualization and machine control applications. It provides a 12.1-inch touchscreen interface with XGA resolution, enabling operators to monitor processes, manage equipment settings, and interact efficiently with automation systems.
Built for modern industrial environments, the HMIDT643 combines a durable display design with flexible connectivity options, making it suitable for demanding automation projects requiring reliable visualization and intuitive machine interaction. Its compatibility with Harmony GTU Box Modules allows engineers to create scalable HMI solutions tailored to different industrial requirements.
Technical Specifications
Parameter
Specification
Product Type
Touchscreen Display Module
Model Number
Schneider HMIDT643
Manufacturer
Schneider Electric
Product Family
Harmony GTU
Display Type
TFT Color LCD
Display Size
12.1 inch
Display Resolution
1024 × 768 pixels (XGA)
Display Colors
16 million colors
Touch Panel Type
Analog Resistive Multi-Touch
Touch Resolution
1024 × 1024
Rated Supply Voltage
12–24 VDC
Voltage Limits
10.8–28.8 VDC
Power Consumption
Approx. 23 W
Communication Interface
USB 2.0 Type A / USB 2.0 Mini-B / WLAN
Wireless Communication
2.4 GHz WLAN
Backlight Life
Approx. 50,000 hours
Installation Type
Panel Mount
Cutout Dimensions
Approx. 301.5 × 227.5 mm
Dimensions
Approx. 315 × 241 × 67 mm
Weight
Approx. 3 kg
Recommended Companion Models
Model
Product Name
Schneider HMIG3U
Harmony GTU Premium Box Module
Schneider HMIG5U2
Harmony GTU Open Box Module
Schneider HMIDT642
Harmony GTU 12.1-inch Smart Display Module
Schneider HMIDT732
Harmony GTU 15-inch Smart Display Module
Frequently Selected Alternatives
Model
Product Name
Schneider HMIDT642
Harmony GTU 12.1-inch Smart Display
Schneider HMIDT551
Harmony GTU 10.1-inch Advanced Display
Schneider HMIDT651
Harmony GTU 12.1-inch Advanced Display
Schneider HMIDT952
Harmony GTU 15-inch Wide Display Module
Where It Excels in Industrial Use
• Designed for industrial human-machine interface applications requiring a reliable touchscreen display for machine operation, monitoring, and visualization tasks.
• Suitable for factory automation, process control, packaging equipment, and industrial machinery systems using Schneider Electric Harmony GTU platforms.
• Provides a high-visibility operator interface solution for applications where efficient control access, clear data presentation, and long-term reliability are essential.
Key Strengths at a Glance
• Features a 12.1-inch TFT color LCD with XGA resolution for clear visualization of machine data, alarms, and operating parameters.
• Supports flexible integration with Harmony GTU Box Modules, allowing scalable HMI configurations for different automation architectures.
• Includes touchscreen operation, USB connectivity, and wireless communication capability for convenient industrial interaction and system integration.
Technical FAQs
Q1: What is the primary function of the Schneider HMIDT643?
The Schneider HMIDT643 is a Harmony GTU touchscreen display module designed to provide an operator interface for industrial automation systems.
Q2: Which Schneider Electric product family does the HMIDT643 belong to?
The HMIDT643 belongs to the Schneider Electric Harmony GTU HMI display family.
Q3: What type of display technology does the HMIDT643 use?
The HMIDT643 uses a color TFT LCD display with XGA resolution for industrial visualization applications.
Q4: Which Box Modules can be combined with the HMIDT643?
The HMIDT643 can be connected with compatible Harmony GTU Box Modules to create a complete HMI terminal configuration.
Q5: What communication features are available on the HMIDT643?
The display supports USB interfaces and wireless LAN communication through its integrated WLAN functionality.
Q6: What type of touchscreen technology is used in this display?
The HMIDT643 uses an analog resistive multi-touch panel designed for industrial operator interaction.
Q7: What should be confirmed before replacing an existing HMIDT643 unit?
Engineers should verify Harmony GTU compatibility, Box Module configuration, power requirements, mounting dimensions, and application software compatibility before replacement.
Q8: How does the HMIDT643 improve machine operation efficiency?
It provides direct visualization and operator control functions, helping users monitor processes, adjust parameters, and respond quickly to system conditions.
Q9: Can the HMIDT643 be used in industrial environments?
Yes, it is designed for industrial automation applications with features supporting reliable operation in factory environments.
Q10: What software is commonly used for configuring the HMIDT643?
The HMIDT643 is configured through Schneider Electric HMI engineering software compatible with Harmony GTU terminals.
