Brand:Schneider PLC Item No.:HMIDT651 Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider HMIDT651 Touchscreen Display Module is an advanced operator interface component from the Harmony GTU series, developed for industrial automation applications requiring reliable visualization and intuitive machine interaction. With its 12.1-inch wide display and WXGA resolution, it provides operators with a clear and efficient interface for monitoring processes, controlling equipment, and accessing critical operational information.
Designed with Schneider Electric’s modular HMI concept, the HMIDT651 works together with compatible Harmony GTU Box Modules to create scalable operator terminals for various automation environments. Its robust display performance, touchscreen capability, and industrial-grade protection make it a practical choice for modern machine control applications.
Technical Specifications
Parameter
Specification
Product Type
Touchscreen Display Module
Model Number
Schneider HMIDT651
Manufacturer
Schneider Electric
Product Family
Harmony GTU
Display Type
Color TFT LCD
Display Size
12.1 inch
Display Resolution
1280 × 800 pixels
Display Colors
262,144 colors
Touch Panel Type
Analog Resistive Single Touch
Touch Resolution
1024 × 1024
Rated Supply Voltage
12–24 VDC
Voltage Limits
10.8–28.8 VDC
Power Consumption
Approx. 11.5 W
Backlight Life
Approx. 50,000 hours
Installation Type
Panel Mount
Front Protection Rating
IP66 / IP67
Operating Temperature
0°C to 60°C
Cutout Dimensions
Approx. 295 × 217 mm
Dimensions
Approx. 308.5 × 230.5 × 67 mm
Weight
Approx. 3 kg
Recommended Companion Models
Model
Product Name
Schneider HMIG3U
Harmony GTU Premium Box Module
Schneider HMIG5U2
Harmony GTU Open Box Module
Schneider HMIDT643
Harmony GTU Smart Display Module
Schneider HMIDT732
Harmony GTU 15-inch Smart Display Module
Frequently Selected Alternatives
Model
Product Name
Schneider HMIDT551
Harmony GTU 10.1-inch Advanced Display Module
Schneider HMIDT351
Harmony GTU 7-inch Advanced Display Module
Schneider HMIDT642
Harmony GTU 12.1-inch Smart Display Module
Schneider HMIDT952
Harmony GTU 15-inch Wide Advanced Display Module
Where It Excels in Industrial Use
• Designed for advanced industrial HMI applications requiring a high-resolution touchscreen interface for machine control, visualization, and operator interaction.
• Suitable for factory automation, process industries, packaging systems, and machine builders using Schneider Electric Harmony GTU platforms.
• Provides a reliable operator display solution for applications requiring clear process visualization, flexible system integration, and efficient equipment management.
Key Strengths at a Glance
• Features a 12.1-inch wide TFT color display with 1280 × 800 pixel resolution, delivering detailed visualization of industrial applications.
• Supports modular integration with Harmony GTU Box Modules, allowing flexible HMI system configurations for different automation requirements.
• Offers a durable industrial touchscreen design with IP66/IP67 front protection and compatibility with demanding factory environments.
Technical FAQs
Q1: What is the primary function of the Schneider HMIDT651?
The Schneider HMIDT651 is an Advanced Display Module designed to provide touchscreen visualization and operator interaction for Harmony GTU HMI systems.
Q2: Which Schneider Electric product family does the HMIDT651 belong to?
The HMIDT651 belongs to the Harmony GTU Advanced Display product family, designed for modular industrial HMI applications.
Q3: What type of display technology is used in the HMIDT651?
The HMIDT651 uses a color TFT LCD display with a 12.1-inch screen size and 1280 × 800 pixel resolution.
Q4: Which Box Modules are compatible with the HMIDT651?
The HMIDT651 can be combined with compatible Harmony GTU Box Modules to create a complete operator terminal solution.
Q5: What type of touchscreen technology does the HMIDT651 use?
The display uses an analog resistive touchscreen designed for industrial operator control applications.
Q6: What communication interfaces are available when using the HMIDT651 system?
Communication capabilities depend on the connected Harmony GTU Box Module, which provides interfaces such as Ethernet, USB, and serial communication options.
Q7: What should be checked before replacing an existing HMIDT651 unit?
Engineers should verify Harmony GTU compatibility, connected Box Module type, HMI project configuration, power requirements, and mounting specifications.
Q8: How does the HMIDT651 improve industrial operation efficiency?
It provides operators with clear visualization and direct interaction capabilities, helping improve process monitoring and equipment control efficiency.
Q9: Can the HMIDT651 be used in harsh industrial environments?
Yes, the display features industrial protection ratings including IP66/IP67 front protection for suitable installation conditions.
Q10: What software is used to configure the HMIDT651?
The HMIDT651 is configured through Schneider Electric-compatible HMI engineering software used for Harmony GTU terminals.
