Brand:Schneider PLC Item No.: HMIDT732 Product Origin:France Product Dimensions:650 × 120 × 90 mm Product Weight:4.5 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider HMIDT732 Touchscreen Display Module is a high-performance HMI display component from the Harmony GTU series, designed for industrial automation environments requiring a large and intuitive operator interface. With its 15-inch TFT color display and XGA resolution, it provides excellent visibility for process graphics, machine parameters, alarms, and control functions.
Built around Schneider Electric’s modular HMI architecture, the HMIDT732 allows users to combine the display module with compatible Box Modules to create flexible automation terminals. Its robust touchscreen design, industrial communication capability, and user-friendly interface make it suitable for a wide range of machine control and process monitoring applications.
Technical Specifications
Parameter
Specification
Product Type
Touchscreen Display Module
Model Number
Schneider HMIDT732
Manufacturer
Schneider Electric
Product Family
Harmony GTU
Display Type
Color TFT LCD
Display Size
15 inch
Display Resolution
1024 × 768 pixels (XGA)
Display Colors
16 million colors
Aspect Ratio
4:3
Touch Panel Type
Analog Resistive Multi-Touch
Touch Resolution
1024 × 1024
Rated Supply Voltage
12–24 VDC
Supply Voltage Range
10.8–28.8 VDC
Power Consumption
Approx. 22 W
Communication Interface
USB 2.0 Type A / USB 2.0 Mini-B
Backlight Life
Approx. 50,000 hours
Brightness Sensor
Supported
Cooling Method
Natural Convection
Installation Type
Indoor Panel Mount
Front Protection Rating
IP66 / IP67
Cutout Dimensions
Approx. 383.5 × 282.5 mm
Dimensions
Approx. 397 × 296 × 67 mm
Weight
Approx. 4.5 kg
Recommended Companion Models
Model
Product Name
Schneider HMIG3U
Harmony GTU Premium Box Module
Schneider HMIG5U2
Harmony GTU Open Box Module
Schneider HMIDT642
Harmony GTU 12.1-inch Smart Display Module
Schneider HMIDT952
Harmony GTU 19-inch Wide Smart Display Module
Frequently Selected Alternatives
Model
Product Name
Schneider HMIDT752
Harmony GTU 15-inch Wide Smart Display Module
Schneider HMIDT651
Harmony GTU 12.1-inch Advanced Display Module
Schneider HMIDT643
Harmony GTU 12.1-inch Smart Display Module
Schneider HMIDT952
Harmony GTU 19-inch Wide Display Module
Where It Excels in Industrial Use
• Designed for industrial HMI applications requiring a large-format touchscreen interface for machine visualization, process monitoring, and operator control.
• Suitable for factory automation, production lines, energy systems, packaging machinery, and industrial equipment requiring clear graphical operation displays.
• Provides a flexible visualization solution for Schneider Electric Harmony GTU systems where reliable performance, modular integration, and intuitive operation are essential.
Key Strengths at a Glance
• Features a 15-inch color TFT LCD touchscreen with XGA resolution, providing detailed visualization of operating data, alarms, and control interfaces.
• Supports modular integration with Harmony GTU Box Modules, allowing engineers to build scalable HMI solutions for different automation architectures.
• Includes multi-touch resistive technology, front USB connectivity, and brightness sensing functions for improved operator interaction and usability.
Technical FAQs
Q1: What is the primary function of the Schneider HMIDT732?
The Schneider HMIDT732 is a Harmony GTU touchscreen display module designed to provide visualization and operator interaction functions for industrial automation systems.
Q2: Which Schneider Electric product family does the HMIDT732 belong to?
The HMIDT732 belongs to the Harmony GTU range of modular industrial HMI display solutions.
Q3: What type of display technology is used in the HMIDT732?
The HMIDT732 uses a color TFT LCD display with a 15-inch screen size and 1024 × 768 pixel XGA resolution.
Q4: What touchscreen technology does the HMIDT732 use?
The HMIDT732 uses an analog resistive multi-touch panel designed for reliable industrial operator input.
Q5: Which Box Modules are compatible with the HMIDT732?
The HMIDT732 can be combined with compatible Harmony GTU Box Modules to create complete HMI terminal configurations.
Q6: What communication interfaces are available on the HMIDT732?
The display provides USB 2.0 Type A and USB 2.0 Mini-B interfaces, while additional communication functions depend on the connected Box Module.
Q7: What should be checked before replacing an HMIDT732 display?
Engineers should confirm Harmony GTU compatibility, connected Box Module type, HMI project configuration, power requirements, and mechanical installation conditions.
Q8: How does the HMIDT732 improve industrial operation efficiency?
It provides operators with a larger visualization area for monitoring processes, adjusting parameters, and responding quickly to machine conditions.
Q9: Can the HMIDT732 operate in industrial environments?
Yes, the display is designed for industrial installation with a protected front panel and support for demanding automation applications.
Q10: What software environment is used with the HMIDT732?
The HMIDT732 operates as part of Harmony GTU HMI systems configured through Schneider Electric-compatible HMI engineering software.
