Brand:Schneider PLC Item No.:HMIS85 Product Origin:France Product Dimensions:163 × 129.15 × 129.4 mm Product Weight:0.405 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider HMIS85 Touchscreen Display Module is a compact industrial HMI display designed for small automation systems requiring efficient visualization and operator interaction. As part of the Harmony SCU series, it provides a practical interface solution for machine builders and system integrators developing space-saving control applications.
With its 5.7-inch TFT color display, analog touchscreen technology, and modular replacement design, the HMIS85 delivers dependable performance for equipment monitoring, parameter configuration, and basic process control tasks. Its compact structure makes it especially suitable for OEM machinery where installation flexibility and operational reliability are key requirements.
Technical Specifications
Parameter
Specification
Product Type
Touchscreen Display Module
Model Number
Schneider HMIS85
Manufacturer
Schneider Electric
Product Family
Harmony SCU
Display Type
LED Backlit Color TFT LCD
Display Size
5.7 inch
Display Resolution
320 × 240 pixels (QVGA)
Display Colors
65,536 colors
Touch Panel Type
Analog Touchscreen
Backlight Type
White LED
Backlight Life
Approx. 50,000 hours
Brightness Adjustment
16 levels via touchscreen
Viewing Angle
60° Left / 60° Right / 40° Top / 60° Bottom
Communication Interface
Depends on Connected SCU Rear Module
Installation Type
Panel Mount
Compatible Rear Modules
HMISAC / HMISBC
Operating Temperature
0°C to 50°C
Dimensions
Approx. 163 × 129.15 × 129.4 mm
Weight
Approx. 0.405 kg
Recommended Companion Models
Model
Product Name
Schneider HMISCU8A5
Harmony SCU 5.7-inch HMI Controller
Schneider HMISBC
Harmony SCU Replacement Rear Module
Schneider HMISCU8B5
Harmony SCU 5.7-inch Advanced HMI Controller
Schneider HMISAC
Harmony SCU Replacement Rear Module
Frequently Selected Alternatives
Model
Product Name
Schneider HMIS65
Harmony SCU 3.5-inch Touchscreen Display Module
Schneider HMISTU855
Harmony STU 5.7-inch Touchscreen HMI
Schneider HMIGTO1300
Harmony GTU Open Box Module
Schneider HMIDT642
Harmony GTU 12.1-inch Smart Display Module
Where It Excels in Industrial Use
• Designed for compact industrial HMI applications requiring a reliable touchscreen interface for machine operation, parameter adjustment, and basic process visualization.
• Suitable for small automation equipment, OEM machines, packaging systems, and standalone control applications where installation space and operational simplicity are important.
• Provides an efficient operator interface solution within the Schneider Electric Harmony SCU platform, enabling easy machine maintenance, quick upgrades, and dependable local control.
Key Strengths at a Glance
• Features a 5.7-inch color TFT LCD touchscreen display with QVGA resolution, providing clear visualization for compact industrial systems.
• Uses LED backlight technology with long operating life and adjustable brightness levels for improved readability in different working environments.
• Designed as a replacement display module for Harmony SCU controllers, allowing convenient maintenance and simplified system upgrades.
Technical FAQs
Q1: What is the primary function of the Schneider HMIS85?
The Schneider HMIS85 is a small touchscreen display module designed to provide operator visualization and control functions for Harmony SCU HMI systems.
Q2: Which Schneider Electric product family does the HMIS85 belong to?
The HMIS85 belongs to the Harmony SCU HMI product family, which is designed for compact machine control and simple process applications.
Q3: What type of display technology is used in the HMIS85?
The HMIS85 uses a backlit LED color TFT LCD display with a 5.7-inch screen size and 320 × 240 pixel QVGA resolution.
Q4: What touchscreen technology is integrated into the HMIS85?
The HMIS85 uses an analog touchscreen panel designed for reliable operator input in industrial environments.
Q5: Which controller modules are compatible with the HMIS85?
The HMIS85 can be combined with compatible Harmony SCU rear modules, including HMISAC and HMISBC replacement rear modules, to form complete HMI controller configurations.
Q6: What communication functions are available when using the HMIS85?
Communication capabilities depend on the connected Harmony SCU rear controller module, which may provide Ethernet, USB, serial link, and CANopen communication interfaces.
Q7: What applications are commonly suitable for the HMIS85?
The HMIS85 is commonly used for compact machines, simple automation systems, OEM equipment, and small process control applications requiring local operator interaction.
Q8: How does the HMIS85 improve machine operation efficiency?
It provides a compact touchscreen interface that allows operators to monitor equipment status, adjust settings, and access machine functions more efficiently.
Q9: What should be checked before replacing an HMIS85 display module?
Engineers should verify Harmony SCU compatibility, rear module configuration, HMI application settings, wiring connections, and installation requirements before replacement.
Q10: What maintenance practices are recommended for the HMIS85?
Regular inspection of the touchscreen surface, cable connections, mounting condition, and system communication status helps maintain reliable long-term operation.
