Brand:Schneider PLC Item No.:HMISBC Product Origin:France Product Dimensions:190 × 92 × 88 mm Product Weight:0.35 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider HMISBC Controller Rear Module is a compact automation controller designed for Harmony SCU HMI systems, providing a combination of processing capability, communication flexibility, and integrated I/O control. It serves as the control foundation behind compatible HMIS65 and HMIS85 display modules, enabling engineers to build customized operator interfaces for small and medium automation applications.
With built-in analog and digital I/O resources, multiple communication interfaces, and a compact installation design, the HMISBC offers an efficient solution for machine builders seeking reliable control performance without requiring a separate PLC and HMI combination. Its modular architecture simplifies system design while maintaining the flexibility needed for modern industrial automation projects.
Technical Specifications
Parameter
Specification
Product Type
Controller Rear Module
Model Number
Schneider HMISBC
Manufacturer
Schneider Electric
Product Family
Harmony SCU
Module Type
Simple Process Controller Module
CPU Type
RISC Processor
Processor Frequency
333 MHz
Digital Inputs
8
Digital Outputs
8
Analog Inputs
4
Analog Outputs
2
Rated Supply Voltage
24 VDC
Supply Voltage Range
20.4–28.8 VDC
Power Consumption
Approx. 15 W
Internal Flash Memory
128 MB NAND Flash
Application Memory
128 MB DRAM
Data Storage Memory
128 kB FRAM
Communication Interfaces
Ethernet TCP/IP, RS232/RS485, USB 2.0 Type A, USB 2.0 Mini-B, CANopen
Supported Protocols
Modbus, Modbus TCP/IP, CANopen
Real-Time Clock
Integrated
Software Platform
SoMachine / Harmony
Compatible Displays
HMIS65, HMIS85
Mounting Type
Panel Mount
Panel Thickness
1–6 mm
Dimensions
Approx. 190 × 92 × 88 mm
Weight
Approx. 0.35 kg
Recommended Companion Models
Model
Product Name
Schneider HMIS85
Harmony SCU 5.7-inch Touchscreen Display Module
Schneider HMIS65
Harmony SCU 3.5-inch Touchscreen Display Module
Schneider HMISCU8B5
Harmony SCU 5.7-inch Advanced HMI Controller
Schneider HMISCU6B5
Harmony SCU 3.5-inch Advanced HMI Controller
Frequently Selected Alternatives
Model
Product Name
Schneider HMISAC
Harmony SCU Controller Rear Module with Digital I/O
Schneider HMISCU8A5
Harmony SCU 5.7-inch HMI Controller
Schneider HMISCU6A5
Harmony SCU 3.5-inch HMI Controller
Schneider HMIGTO1300
Harmony GTU Open Box Module
Where It Excels in Industrial Use
• Designed for compact industrial automation systems requiring integrated HMI control, analog signal processing, and machine monitoring capabilities.
• Suitable for OEM machinery, packaging equipment, small process systems, material handling applications, and automation solutions where flexible I/O management is required.
• Provides a powerful rear controller solution for Harmony SCU HMI configurations, working with HMIS65 and HMIS85 display modules to create efficient operator control terminals.
Key Strengths at a Glance
• Integrates a RISC CPU architecture with 333 MHz processing capability, 128 MB Flash NAND memory, 128 MB DRAM, and 128 kB FRAM data storage for stable application execution.
• Provides integrated control resources including 8 digital inputs, 8 digital outputs, 4 analog inputs, and 2 analog outputs for compact automation applications.
• Supports Ethernet TCP/IP, RS232/RS485 serial communication, USB interfaces, and CANopen connectivity for flexible industrial system integration.
Technical FAQs
Q1: What is the primary function of the Schneider HMISBC?
The Schneider HMISBC is a Harmony SCU rear controller module designed to provide processing, communication, and I/O control functions for compact HMI automation systems.
Q2: Which Schneider Electric product family does the HMISBC belong to?
The HMISBC belongs to the Harmony SCU HMI Controller family, which combines operator display capability with compact machine control functions.
Q3: Which display modules can be connected with the HMISBC?
The HMISBC can be combined with Schneider HMIS65 3.5-inch and HMIS85 5.7-inch display modules to build complete Harmony SCU HMI solutions.
Q4: What processor architecture is used in the HMISBC?
The HMISBC uses a RISC CPU architecture designed for reliable execution of HMI and control applications.
Q5: What communication interfaces are available on the HMISBC?
The module provides Ethernet TCP/IP, RS232/RS485 serial communication, USB 2.0 Type A, USB 2.0 Mini-B, and CANopen master communication interfaces.
Q6: What programming environment is used for configuring the HMISBC?
The HMISBC is configured using Schneider Electric automation software compatible with Harmony SCU controllers.
Q7: What I/O resources are available on the HMISBC?
The HMISBC provides 8 digital inputs, 8 digital outputs, 4 analog inputs, and 2 analog outputs for compact automation control tasks.
Q8: Which communication protocols are supported by the HMISBC?
The HMISBC supports industrial protocols including Modbus, Modbus TCP/IP, and CANopen for integration with automation devices.
Q9: What should be checked before replacing an HMISBC module?
Engineers should confirm display compatibility, application software configuration, communication settings, wiring connections, and power supply requirements before replacement.
Q10: What types of machines commonly use the HMISBC?
The HMISBC is commonly applied in compact automation equipment, OEM machinery, and small process control systems requiring integrated HMI and controller functionality.
