Brand:Schneider PLC Item No.: SR2E201BD Product Origin:France Product Dimensions:124.6 × 107.6 × 59.5 mm Product Weight:0.35 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider SR2E201BD Smart Relay Module is a compact programmable controller from the Zelio Logic series, designed for automation projects requiring increased I/O capacity while maintaining a simple and efficient control architecture. It combines programmable logic functions, relay outputs, analog processing capability, and integrated timing features in a compact DIN-rail mounted format.
With 20 integrated I/O points, flexible programming options, and reliable switching performance, the SR2E201BD provides an effective solution for machine builders, OEM manufacturers, and maintenance teams looking to modernize relay-based control systems. Its compact design helps reduce cabinet space while delivering dependable automation performance for a wide range of applications.
• Designed for compact automation systems requiring expanded programmable control capability, integrated timing functions, and reliable relay switching performance.
• Suitable for machine automation, pump control, HVAC systems, lighting management, access control, and OEM equipment requiring more I/O points than standard compact smart relays.
• Provides an efficient replacement for traditional relay logic by combining programmable processing, analog input capability, relay outputs, and DIN-rail installation within the Schneider Electric Zelio Logic platform.
Key Strengths at a Glance
• Features a Zelio Logic compact smart relay architecture with 24 VDC power supply, 12 discrete inputs, and 8 relay outputs, providing a total of 20 integrated I/O points for automation applications.
• Includes built-in clock functionality, enabling scheduled operations, timed sequences, and automatic control processes without additional timing modules.
• Supports ladder logic and function block diagram programming, allowing engineers to create customized control solutions with up to 240 ladder lines and 500 FBD blocks.
Technical FAQs
Q1: What is the primary function of the Schneider SR2E201BD?
The Schneider SR2E201BD is a Zelio Logic compact smart relay designed to perform programmable control operations for small industrial and commercial automation systems.
Q2: Which Schneider Electric product family does the SR2E201BD belong to?
The SR2E201BD belongs to the Zelio Logic compact smart relay family, which provides simple and flexible automation control solutions.
Q3: What type of power supply does the SR2E201BD require?
The SR2E201BD operates with a 24 VDC power supply and supports a voltage range of approximately 19.2–30 VDC.
Q4: How many inputs and outputs are available on the SR2E201BD?
The SR2E201BD provides 12 digital inputs and 8 relay outputs, offering 20 integrated I/O points for compact automation control.
Q5: Does the SR2E201BD support analog signal processing?
Yes, selected inputs support analog signal handling, allowing the module to process simple voltage-based analog signals in automation applications.
Q6: What programming methods are supported by the SR2E201BD?
The SR2E201BD supports ladder logic programming and function block diagram programming for flexible application development.
Q7: What type of outputs are used in the SR2E201BD?
The SR2E201BD uses relay outputs, providing flexible switching capability for different industrial and commercial loads within rated specifications.
Q8: Can the SR2E201BD retain its program after power interruption?
Yes, the module provides memory backup capability with long-term program retention to maintain stored applications during power loss conditions.
Q9: Which software is used to configure the SR2E201BD?
The SR2E201BD can be configured using Schneider Electric Zelio Soft programming software for developing, testing, and transferring automation programs.
Q10: What applications commonly use the SR2E201BD?
The SR2E201BD is commonly applied in compact machines, building automation systems, pump management equipment, lighting control systems, and small industrial monitoring applications.
