Brand:Schneider PLC Item No.:TM200C24R Product Origin:France Product Dimensions:130 x 90 x 70 mm Product Weight:0.405 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Product Introduction and Industrial Control Overview
The Schneider TM200C24R Easy Modicon M200 Controller is a reliable and compact PLC solution developed for machine automation and industrial control applications.
The Easy Modicon M200 series is designed to provide simple, efficient, and cost-effective control solutions for OEM equipment manufacturers and industrial automation projects. The TM200C24R model provides 24 digital I/O points, including digital inputs and relay outputs, making it suitable for applications requiring flexible device control and stable operation.
With support for relay output switching, high-speed input processing, and system expansion capability, the controller can handle a wide range of automation tasks such as machine sequencing, equipment monitoring, and process control.
The TM200C24R is designed for engineers who need a practical PLC platform that balances performance, flexibility, and ease of use. Its compact design helps reduce cabinet space requirements while maintaining reliable industrial control capability.
For machine builders and automation professionals, the Schneider Easy Modicon M200 Controller provides a dependable solution for developing efficient and scalable control systems.
Technical Specifications
Parameter
Specification
Manufacturer
Schneider Electric
Product Series
Easy Modicon M200
Model Number
TM200C24R
Product Type
Logic Controller
Controller Type
PLC Controller
Rated Supply Voltage
100...240 V AC
Digital I/O Number
24
Digital Inputs
14 Inputs
Digital Outputs
10 Relay Outputs
Output Type
Relay Normally Open
Digital Input Voltage
24 V DC
Output Voltage
24 V DC / 220 V AC
Output Current
2 A
Expansion Capability
Supports Expansion Modules
Communication Interface
Serial Communication
Programming Method
PLC Programming
Installation Type
DIN Rail Mount
Protection Rating
IP20
Operating Temperature
0°C to 55°C
Dimensions
130 mm × 90 mm × 70 mm
Weight
0.405 kg (0.89 lb)
Recommended Related Models
Model
Product Type
Schneider TM200C24R
Easy Modicon M200 Controller
Schneider TM200C16R
Easy Modicon M200 Controller
Schneider TM200CE24R
Easy Modicon M200 Controller
Schneider TM200C32R
Easy Modicon M200 Controller
Schneider TM3 Expansion Modules
PLC Expansion Module
Popular Related Models
Model
Product Type
Schneider Modicon M221
Compact PLC Controller
Schneider Modicon M241
Machine Controller
Schneider Modicon M251
Advanced Machine Controller
Schneider Modicon M340
Modular PLC Controller
Schneider Modicon M580
Process Automation Controller
Machine Automation Applications and Compact PLC Control Solutions
The Schneider TM200C24R Easy Modicon M200 Controller is a compact programmable logic controller designed for small and medium-sized automation systems that require reliable control, flexible I/O management, and efficient machine operation.
As part of the Easy Modicon M200 controller family, the TM200C24R provides a practical PLC platform for OEM manufacturers, machine builders, and automation engineers who need stable performance combined with simple configuration and maintenance.
Featuring integrated digital inputs and relay outputs, this controller is suitable for applications requiring dependable logic processing, equipment sequencing, and industrial device management. Its compact design makes it an excellent choice for control cabinets where installation space is limited but reliable automation performance is required.
Typical applications include:
Packaging and assembly machines
Material handling equipment
Small production lines
Pump and motor control systems
Textile machinery
Machine tools
Automated testing equipment
OEM automation solutions
The Schneider TM200C24R helps users build efficient control systems with improved flexibility, simplified commissioning, and dependable industrial performance.
Engineering Advantages and Control Performance Benefits
The Schneider TM200C24R Easy Modicon M200 Controller combines practical PLC functionality with flexible expansion capability, providing an efficient control solution for modern machine automation projects.
Flexible Relay Output Control
The TM200C24R integrates relay outputs that support a wide range of industrial loads, making it suitable for controlling different types of actuators, contactors, and automation devices.
Compact and Efficient PLC Design
The controller features a compact structure that allows convenient installation inside electrical cabinets while providing reliable processing capability for machine control applications.
Fast Signal Processing Capability
With integrated high-speed and fast input functions, the controller can handle applications requiring accurate signal detection and responsive control operations.
Easy System Expansion
The Easy Modicon M200 platform supports additional expansion modules, allowing engineers to increase I/O capacity and adapt the controller to changing application requirements.
Reliable Industrial Automation Performance
Designed for industrial environments, the TM200C24R provides stable operation, easy maintenance, and long-term reliability for automation systems.
Technical FAQs
1. What is the Schneider TM200C24R Easy Modicon M200 Controller mainly used for?
The TM200C24R is mainly used for machine automation, equipment control, and small industrial systems requiring PLC-based logic processing.
2. What type of output technology does the TM200C24R use?
The controller uses relay outputs, allowing it to control various industrial devices that require flexible switching capability.
3. How many I/O points are available on the TM200C24R?
The controller provides 24 integrated digital I/O points for machine control applications.
4. What programming functions can be performed with this PLC controller?
The controller supports common PLC functions including logic operations, timers, counters, sequencing, and automation control programs.
5. What causes PLC input signals to become incorrect during operation?
Possible causes include sensor failures, wiring problems, incorrect input configuration, signal interference, or external device issues.
6. How can engineers troubleshoot relay output failures?
Engineers should check the PLC program status, output indicators, wiring connections, load conditions, and relay operation.
7. Can the TM200C24R be expanded with additional modules?
Yes. The Easy Modicon M200 series supports expansion modules to increase system capability for larger automation projects.
8. Why is PLC program backup important?
A backup allows engineers to quickly restore the control program during maintenance, replacement, or troubleshooting procedures.
9. What communication functions are available for this controller?
The controller supports industrial communication options for integration with automation devices and control systems.
10. What should engineers evaluate before selecting this PLC?
Engineers should consider required I/O quantity, control complexity, expansion requirements, communication needs, and application conditions.
