The Yokogawa ATT4S-00 is a precision-engineered pressure clamp terminal block designed for Yokogawa CENTUM VP / FIO I/O systems. It plays a critical role in ensuring stable, noise-resistant field wiring connections between instrumentation devices and DCS input modules.

Built for mission-critical process industries, this terminal block delivers exceptional mechanical stability and long-term wiring reliability, especially in environments exposed to vibration, temperature variation, and continuous operation demands.

Its compact architecture makes it ideal for high-density marshalling cabinets where wiring clarity and system uptime are essential.

Technical Specifications

Parameter	Details
Model	ATT4S-00
Brand	Yokogawa
Product Type	Pressure Clamp Terminal Block
System Compatibility	CENTUM VP / FIO I/O System
Function	Field signal termination interface
Wiring Method	Spring pressure clamp connection
Installation	DIN rail / I/O base mounting

Physical Dimensions & Weight

Item	Specification
Dimensions (W × H × D)	30 × 70 × 65 mm
Weight	0.10 kg

Recommended Related Models

Yokogawa ATT4S-10 – Surge protection terminal variant
Yokogawa ATA4S-00 – Standard signal terminal block
Yokogawa ATD5S Series – Multi-channel field interface blocks
Yokogawa AAI141 / AAI543 – Analog input modules
Yokogawa ADV151 – Digital input modules
