Brand:Schneider PLC Item No.:TM5PCRS4 Product Origin:France Product Dimensions:109 × 64 × 58 mm Product Weight:0.08 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5PCRS4 Serial Communication Module is a dedicated RS485 communication solution developed for the Modicon TM5 automation platform. It enables reliable serial data exchange between TM5-based control systems and external industrial devices, making it a practical choice for automation projects requiring flexible field connectivity.
Designed for industrial environments, the TM5PCRS4 helps bridge traditional serial communication equipment with modern automation architectures. Its compact modular design, stable RS485 performance, and compatibility with Modicon TM5 systems make it suitable for machine builders, system integrators, and industrial control applications.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5PCRS4
Product Family
Modicon TM5
Module Type
Serial Communication Module
Communication Interface
RS485
Communication Protocol
Modbus ASCII
Connector Type
Female D-Sub 9
Transfer Rate
Up to 115.2 kbit/s
Communication Isolation
Serial Line to Internal Electronics
Communication Channels
1 RS485 Channel
Status Indicators
Status / RxD / TxD LEDs
Compatible System
Modicon TM5 Modular System
Application Type
Serial Device Communication
Maximum Power Dissipation
0.40 W
Installation Method
TM5 Modular Mounting
Protection Rating
IP20
Dimensions
Approx. 99 × 12.5 × 75 mm
Weight
Approx. 50 g
Recommended Companion Models
Model
Product Name
TM5ACBN1
Schneider Modicon TM5 Bus Base Module
TM5SPS3
Schneider Modicon TM5 Interface Power Distribution Module
TM5ACTB12PS
Schneider Modicon TM5 Power Distribution Terminal Block Module
TM5C24D18T
Schneider Modicon TM5 Compact Digital I/O Expansion Block Module
Frequently Selected Alternatives
Model
Product Name
TM5PCRS2
Schneider Modicon TM5 RS232 Serial Communication Module
TM5NCO1
Schneider Modicon TM5 CANopen Communication Module
TM5NEIP1
Schneider Modicon TM5 EtherNet/IP Communication Module
TM5NS31
Schneider Modicon TM5 SERCOS III Communication Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon TM5 automation platforms, providing an RS485 serial communication interface for connecting controllers with industrial devices, field instruments, and third-party automation equipment.
• Suitable for machine automation systems, energy monitoring equipment, process control applications, and industrial networks requiring reliable Modbus-based serial communication.
• Ideal for applications where existing RS485 devices need to be integrated into Modicon TM5 control architectures, extending communication flexibility without adding complex network infrastructure.
Key Strengths at a Glance
• Provides an RS485 serial communication interface with Modbus ASCII support, enabling efficient data exchange between TM5 controllers and external automation devices.
• Supports communication speeds up to 115.2 kbit/s, offering flexible performance for industrial serial communication requirements.
• Features a female D-Sub 9 connector design, allowing convenient connection with standard RS485 communication wiring systems.
• Compact TM5 modular construction helps optimize control cabinet space while providing reliable serial connectivity for distributed automation solutions.
Technical FAQs
1. What type of module is the Schneider TM5PCRS4?
The Schneider TM5PCRS4 is a Modicon TM5 serial communication module designed to provide RS485 connectivity for industrial automation systems.
2. What communication interface does the TM5PCRS4 provide?
The TM5PCRS4 provides an RS485 serial communication interface through a female D-Sub 9 connector.
3. Which communication protocol is supported by the TM5PCRS4?
The TM5PCRS4 supports Modbus ASCII serial communication for integration with compatible industrial devices.
4. What is the maximum communication speed of the TM5PCRS4?
The TM5PCRS4 supports a maximum transfer rate of 115.2 kbit/s.
5. Is the TM5PCRS4 an I/O expansion module?
No. The TM5PCRS4 is a communication module and does not provide digital or analog input/output channels.
6. What type of devices can be connected to the TM5PCRS4?
The module can connect to compatible RS485 devices such as meters, controllers, sensors, drives, and other serial communication equipment.
7. Does the TM5PCRS4 support isolated serial communication?
Yes. The module provides isolation between the serial line and internal electronics to improve communication reliability in industrial environments.
8. What connector type is used on the TM5PCRS4?
The TM5PCRS4 uses a female D-Sub 9 connector for RS485 communication connections.
9. Does the TM5PCRS4 require software configuration?
Yes. Communication parameters, serial settings, and network configuration must be configured through compatible Schneider Electric automation software.
10. What advantage does the TM5PCRS4 provide in automation systems?
It allows modern PLC systems to communicate with RS485-based equipment, improving system integration flexibility and extending the communication capability of TM5 platforms.
