Brand:Schneider PLC Item No.:TM5SAI2L Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5SAI2L Analog Input Module is a flexible signal acquisition solution developed for the Modicon TM5 modular I/O platform. It provides two analog input channels capable of handling standard industrial voltage and current signals, making it suitable for a wide range of automation and monitoring applications.
With dependable analog conversion performance, compact modular construction, and compatibility with Schneider Electric controller systems, the TM5SAI2L helps engineers create scalable automation architectures while maintaining efficient cabinet layouts and simplified maintenance.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5SAI2L
Product Family
Modicon TM5
Module Type
Analog Input Module
Analog Input Channels
2 Channels
Input Type
Differential Analog Input
Voltage Input Range
±10 V DC
Current Input Range
0–20 mA / 4–20 mA
Resolution
12 bits + sign (Voltage), 12 bits (Current)
Measurement Resolution
2.441 mV (Voltage), 4.883 μA (Current)
Input Impedance
≥20 MΩ (Voltage Input)
Load Impedance
≤300 Ω (Current Input)
Sampling Duration
1 ms with filtering / 300 μs without filtering
Measurement Error
<0.08% of full scale at 25°C
Temperature Coefficient
±0.006% FS/°C (Voltage), ±0.009% FS/°C (Current)
Compatible Controllers
Modicon M258 / LMC058
Installation Method
TM5 Modular Mounting
Protection Rating
IP20
Dimensions
Approx. 99 × 12.5 × 75 mm
Weight
Approx. 25 g
Recommended Companion Models
Model
Product Name
TM5ACBN1
Schneider Modicon TM5 Bus Base Module
TM5SPS3
Schneider Modicon TM5 Interface Power Distribution Module
TM5ACTB12PS
Schneider Modicon TM5 Power Distribution Terminal Block Module
TM5C24D18T
Schneider Modicon TM5 Compact Digital I/O Expansion Block Module
Frequently Selected Alternatives
Model
Product Name
TM5SAI2H
Schneider Modicon TM5 High Resolution Analog Input Module
TM5SAI4L
Schneider Modicon TM5 4-Channel Analog Input Module
TM5SAO2L
Schneider Modicon TM5 Analog Output Module
TM5SAI2PH
Schneider Modicon TM5 PT100/PT1000 Temperature Input Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon TM5 modular I/O systems, providing reliable analog signal acquisition for machine automation, process monitoring, and distributed control applications.
• Suitable for packaging machinery, material handling equipment, production lines, and industrial monitoring systems requiring accurate voltage and current feedback from field sensors.
• Ideal for applications using Modicon M258 and LMC058 controllers where flexible analog input expansion is required for sensors, transmitters, and measurement devices.
Key Strengths at a Glance
• Provides two differential analog input channels with 12-bit resolution plus sign for accurate acquisition of voltage and current signals.
• Supports multiple industrial signal ranges, including ±10 V voltage input and 0–20 mA / 4–20 mA current input, allowing compatibility with various field instruments.
• Offers flexible configuration through EcoStruxure Machine Expert, enabling engineers to adapt input parameters according to different automation requirements.
• Compact Modicon TM5 modular design helps reduce cabinet space requirements while maintaining easy wiring, maintenance, and system expansion.
Technical FAQs
1. What type of module is the Schneider TM5SAI2L?
The Schneider TM5SAI2L is a Modicon TM5 analog input module designed for acquiring voltage and current signals in industrial automation systems.
2. How many analog input channels does the TM5SAI2L provide?
The TM5SAI2L provides two differential analog input channels for connecting compatible field sensors and transmitters.
3. What signal types are supported by the TM5SAI2L?
The module supports ±10 V DC voltage signals and 0–20 mA / 4–20 mA current signals.
4. What is the resolution of the TM5SAI2L?
The TM5SAI2L provides 12-bit plus sign resolution for voltage input and 12-bit resolution for current input.
5. Is the TM5SAI2L suitable for pressure and flow sensors?
Yes. The module can process standard analog signals commonly generated by industrial pressure transmitters, flow meters, and other measurement devices.
6. Which Schneider Electric controllers are compatible with the TM5SAI2L?
The TM5SAI2L is compatible with Modicon M258 and LMC058 controller platforms.
7. Does the TM5SAI2L provide isolated analog channels?
The module does not provide channel-to-channel isolation, but provides insulation between the analog channels and the TM5 bus system.
8. What software is used to configure the TM5SAI2L?
The module is configured through Schneider Electric EcoStruxure Machine Expert software.
9. What type of wiring is recommended for the TM5SAI2L?
Shielded cables are recommended for analog signal wiring to reduce electromagnetic interference and improve measurement stability.
10. What applications commonly use the TM5SAI2L?
The module is commonly used in machine control, temperature monitoring, pressure measurement, position feedback, and industrial process monitoring applications.
