Brand:Schneider PLC Item No.:TM5SAI2PH Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5SAI2PH Temperature Input Module is a precision analog measurement solution developed for the Modicon TM5 automation platform. Designed for PT100 and PT1000 temperature probes, it provides accurate thermal data acquisition for industrial machines, production systems, and process monitoring applications.
With 16-bit resolution, two dedicated temperature input channels, and compatibility with Modicon M258 and LMC058 controllers, the TM5SAI2PH helps engineers build reliable temperature control systems with efficient wiring and flexible modular expansion.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5SAI2PH
Product Family
Modicon TM5
Module Type
Temperature Input Module
Input Channels
2 Analog Inputs
Sensor Type
PT100 / PT1000 Temperature Probe
Measurement Type
Resistance Temperature Measurement
Resolution
16 bits
Temperature Range
PT100: -200°C to +850°C
Temperature Range
PT1000: -200°C to +850°C
Resistance Measurement Range
0.1 Ω to 4500 Ω / 0.05 Ω to 2250 Ω
Measurement Resolution
0.1°C
Measurement Current
250 μA ±1.25%
Measurement Error
<0.037% of full scale at 25°C
Temperature Coefficient
0.004% FS/°C
Cable Type
Shielded Cable
Isolation
500 Vrms AC between channel and bus
Power Supply
24 V DC
24 V DC Current Consumption
46 mA
TM5 Bus Current Consumption
2 mA
Maximum Power Dissipation
1.11 W
Compatible Controllers
Modicon M258 / LMC058
Mounting Method
DIN Rail Mount
Protection Rating
IP20
Dimensions
Approx. 99 × 12.5 × 75 mm
Weight
Approx. 0.025 kg
Recommended Companion Models
Model
Product Name
TM5ACBM11
Schneider Modicon TM5 Bus Base Module
TM5ACTB06
Schneider Modicon TM5 6-Pin Terminal Block Module
TM5SPS3
Schneider Modicon TM5 Interface Power Supply Module
Schneider Modicon TM5 2-Channel Analog Input Module
TM5SAI2H
Schneider Modicon TM5 High Resolution Analog Input Module
TM5SAI4L
Schneider Modicon TM5 4-Channel Analog Input Module
TM5SDI12D
Schneider Modicon TM5 Digital Input Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon TM5 modular I/O systems, providing high-accuracy temperature signal acquisition for industrial automation, machine monitoring, and process control applications.
• Suitable for packaging equipment, manufacturing lines, heating systems, thermal processing machines, and industrial systems requiring precise PT100/PT1000 temperature measurement.
• Ideal for Modicon M258 and LMC058 controller platforms where reliable temperature feedback and compact distributed I/O expansion are required.
Key Strengths at a Glance
• Provides two analog temperature input channels with 16-bit resolution, delivering accurate measurement performance for PT100 and PT1000 resistance temperature probes.
• Supports a wide temperature measurement range from -200°C to +850°C, making it suitable for demanding industrial thermal monitoring applications.
• Delivers excellent measurement stability with low non-linearity and high common-mode noise rejection, helping maintain reliable temperature control in industrial environments.
• Compact Modicon TM5 modular construction with DIN rail installation simplifies cabinet integration while allowing flexible system expansion.
Technical FAQs
1. What type of module is the Schneider TM5SAI2PH?
The Schneider TM5SAI2PH is a Modicon TM5 temperature input module designed for PT100 and PT1000 temperature probe measurement applications.
2. How many input channels does the TM5SAI2PH provide?
The TM5SAI2PH provides two analog temperature input channels for connecting compatible resistance temperature sensors.
3. Which temperature sensors are supported by the TM5SAI2PH?
The module supports PT100 and PT1000 resistance temperature probes for industrial temperature measurement.
4. What is the temperature measurement range of the TM5SAI2PH?
The module supports PT100 and PT1000 temperature measurement from -200°C to +850°C.
5. What is the resolution of the TM5SAI2PH?
The TM5SAI2PH provides 16-bit measurement resolution for accurate temperature signal conversion.
6. Which controllers are compatible with the TM5SAI2PH?
The TM5SAI2PH is compatible with Schneider Electric Modicon M258 logic controllers and LMC058 motion controllers.
7. Does the TM5SAI2PH support thermocouple sensors?
No. The TM5SAI2PH is designed specifically for PT100 and PT1000 resistance temperature probes.
8. Does the TM5SAI2PH provide channel isolation?
The module provides insulation between the input channels and the TM5 bus, while the individual channels do not have isolation from each other.
9. What type of cable is recommended for the TM5SAI2PH?
Shielded cable is recommended to improve signal quality and reduce electromagnetic interference during temperature measurement.
10. What software is used to configure the TM5SAI2PH?
The TM5SAI2PH is configured through Schneider Electric automation software used for Modicon TM5 system programming and setup.
