Brand:Schneider PLC Item No.:TM5SBER2 Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5SBER2 Remote Receiver Module is a key communication component within the Modicon TM5 distributed I/O platform. Designed to support remote I/O expansion and power distribution, it enables automation engineers to create flexible, scalable control architectures for advanced industrial machines.
With reliable remote communication capability, integrated power management, and compatibility with Modicon M258 and LMC058 controllers, the TM5SBER2 helps simplify complex wiring structures while improving system organization and maintenance efficiency.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5SBER2
Product Family
Modicon TM5
Module Type
Communication Module
Product Type
Remote Receiver Module
Main Function
Remote I/O Communication and Power Distribution
Compatible Controllers
Modicon M258 / LMC058
Rated Supply Voltage
24 V DC
24 V DC I/O Segment Current Consumption
25 mA
Maximum Power Dissipation
2.22 W
TM5 Power Bus Input Current
0.7 A max.
Generated Current
1156 mA
Maximum I/O Segment Current
10 A
Bus Length
Up to 2500 m
Cable Distance Between Devices
Up to 100 m
Communication Indicator
LED Status Display
Reverse Polarity Protection
Yes (TM5 Power Bus)
Mounting Method
DIN Rail Mount
Protection Rating
IP20 / IP67 system dependent
Operating Temperature
0°C to 60°C
Dimensions
Approx. 99 × 12.5 × 75 mm
Weight
Approx. 0.025 kg
Recommended Companion Models
Model
Product Name
TM5SBET1
Schneider Modicon TM5 Remote Transmitter Module
TM5SPS3
Schneider Modicon TM5 Interface Power Supply Module
TM5ACBM15
Schneider Modicon TM5 Bus Base Module
TM5ACTB12PS
Schneider Modicon TM5 Power Distribution Terminal Block
Schneider Modicon TM5 Remote Receiver Communication Module
TM5NEIP1
Schneider Modicon TM5 Ethernet Interface Module
TM5NCO1
Schneider Modicon TM5 CANopen Interface Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon TM5 automation systems, providing remote I/O communication expansion and distributed power management for complex industrial control architectures.
• Suitable for packaging machinery, material handling systems, assembly equipment, and large-scale automation applications where remote I/O islands are required to improve system flexibility and reduce wiring complexity.
• Optimized for Modicon M258 logic controllers and LMC058 motion controllers, enabling reliable connection between distributed TM5 I/O stations and central control systems.
Key Strengths at a Glance
• Functions as a remote receiver module, enabling communication between remote I/O configurations while distributing power to the TM5 bus and I/O segments.
• Supports long-distance distributed I/O architectures with a maximum bus length of up to 2500 m, helping engineers build scalable automation networks.
• Provides integrated power management capability with 24 V DC supply support and up to 10 A maximum current for the 24 V DC I/O power segment.
• Compact modular construction with DIN rail mounting enables efficient cabinet integration, simplified maintenance, and flexible expansion of TM5 automation systems.
Technical FAQs
1. What type of module is the Schneider TM5SBER2?
The Schneider TM5SBER2 is a Modicon TM5 remote receiver module designed for distributed I/O communication and power distribution within automation systems.
2. What is the main function of the TM5SBER2?
The module provides communication between remote I/O stations and distributes power to the TM5 bus and connected I/O segments.
3. Which Schneider controllers are compatible with the TM5SBER2?
The TM5SBER2 is compatible with Modicon M258 logic controllers and LMC058 motion controllers.
4. What communication distance can the TM5SBER2 support?
The module supports a maximum bus length of approximately 2500 meters depending on system configuration and installation conditions.
5. What supply voltage does the TM5SBER2 require?
The TM5SBER2 operates with a rated 24 V DC power supply.
6. Does the TM5SBER2 provide power distribution functionality?
Yes. The module distributes power to the TM5 power bus and the 24 V DC I/O power segment.
7. Is the TM5SBER2 suitable for distributed machine architectures?
Yes. It is specifically designed for remote I/O configurations where control components are distributed across different machine sections.
8. Which software is used to configure the TM5SBER2?
The TM5SBER2 is configured through Schneider Electric automation programming environments used for Modicon TM5 systems.
9. What protection features are included in the TM5SBER2?
The module includes integrated protection features such as reverse polarity protection on the TM5 power bus supply and monitored power functions.
10. What applications commonly use the TM5SBER2?
The module is commonly applied in machine control, packaging systems, production lines, and distributed automation projects requiring remote TM5 I/O expansion.
