Brand:Schneider PLC Item No.:TM5SDO4TFS Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5SDO4TFS Safety Digital Output Module is engineered for machine builders and automation professionals who require certified functional safety without compromising performance. Featuring four safety-rated solid-state outputs, advanced diagnostic capabilities, and high-speed response, it helps create safer and more reliable industrial automation systems.
As part of the Modicon TM5 Safety platform, the TM5SDO4TFS enables seamless integration into modern safety control architectures for packaging machinery, robotic production lines, motion control systems, and OEM equipment where compliance with international safety standards is a critical requirement.
• Functional Safety Machine Control
Designed for safety-critical automation systems that require certified safety outputs for emergency stop circuits, safety interlocks, and machine shutdown functions.
• Packaging and Robotics Applications
Ideal for packaging machinery, robotic cells, and automated production equipment where personnel safety and reliable output diagnostics are essential.
• Safety Motion Control Systems
Provides safety-rated digital outputs for motion controllers and machine safety architectures compliant with international functional safety standards.
• OEM Safety Automation Solutions
Suitable for OEM equipment requiring compact, modular safety I/O with high diagnostic coverage and simplified system integration.
Key Strengths at a Glance
• Certified Functional Safety Performance
Supports applications up to SIL 3, PL e, and Category 4, helping manufacturers meet stringent international machine safety requirements.
• Advanced Output Diagnostics
Features configurable output monitoring, open-circuit detection, and automatic fault diagnostics to improve system availability and maintenance efficiency.
• Integrated Electronic Protection
Provides protection against overload, short circuit, and inductive switching while maintaining reliable safety output operation.
• High-Speed Safety Switching
Fast safety response and short I/O update times enable reliable protection for modern high-speed industrial machinery.
Technical FAQs
1. What type of module is the Schneider TM5SDO4TFS?
The TM5SDO4TFS is a 4-channel safety digital output module designed for the Modicon TM5 safety I/O platform.
2. How many safety outputs does the TM5SDO4TFS provide?
The module provides four independently monitored safety-rated digital output channels.
3. What safety standards does the TM5SDO4TFS comply with?
The module supports applications up to SIL 3 according to IEC 61508 and IEC 62061, as well as PL e and Category 4 according to EN ISO 13849-1.
4. What output technology is used by the module?
The TM5SDO4TFS uses solid-state FET source outputs with integrated safety diagnostics and OSSD functionality.
5. What is the rated output current of each channel?
Each output channel supports a rated current of 0.5 A, with a maximum combined output current of 2 A.
6. Does the module support output diagnostics?
Yes. It provides configurable output monitoring, open-circuit detection, fault indication, and channel status diagnostics.
7. What protection features are integrated into the TM5SDO4TFS?
The module includes overload protection, short-circuit protection, inductive load protection, and electronic fault detection.
8. What is the maximum switching frequency of the outputs?
The safety outputs support switching frequencies up to 500 Hz for resistive loads.
9. Can the TM5SDO4TFS detect open-load conditions?
Yes. The module incorporates internal current monitoring to detect open-circuit conditions and report diagnostic status.
10. Which Schneider Electric controllers are compatible with the TM5SDO4TFS?
The module is designed for Schneider Electric Modicon TM5 safety architectures and PacDrive LMC motion controller platforms supporting TM5 Safety I/O modules.
