The Schneider TM5SPS1 Power Distribution Module is a dedicated power management component designed to enhance the flexibility and reliability of Modicon TM5 automation systems. By providing a separate 24 V DC I/O power segment, it allows engineers to build larger and more organized control architectures while maintaining stable power delivery.
With its compact modular structure, high current capability, and seamless integration into TM5 systems, the TM5SPS1 is an excellent choice for industrial machines requiring expanded I/O configurations. It helps simplify cabinet design, improve wiring efficiency, and support reliable operation in demanding automation environments.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5SPS1
Product Family
Modicon TM5
Module Type
Power Distribution Module
Application
24 V DC I/O Power Supply
Rated Supply Voltage
24 V DC
Supply Voltage Range
20.4…28.8 V DC
Maximum Output Current
10 A
TM5 Bus Current Consumption
40 mA
24 V DC I/O Segment Current Consumption
25 mA
Maximum Power Dissipation
0.8 W
Short Circuit Protection
External 10 A Slow-Blow Fuse
Isolation Voltage
500 V AC RMS
Compatible Systems
Modicon TM5
Mounting Type
DIN Rail
Protection Rating
IP20
Operating Temperature
-10…55 °C
Dimensions
Approx. 12.5 × 99 × 75 mm
Weight
Approx. 30 g
Recommended Companion Models
Model
Product Name
Schneider TM5ACBM15
TM5 Addressable Bus Base Module
Schneider TM5ACTB12
TM5 Terminal Block
Schneider TM5SDI6D
TM5 Digital Input Module
Schneider TM5SDO16T
TM5 Digital Output Module
Frequently Selected Alternatives
Model
Product Name
Schneider TM5SPS2
TM5 Power Supply Module
Schneider TM5SPS1F
TM5 Fused Power Distribution Module
Schneider TM5SPDG6D6F
TM5 Power Distribution Module
Schneider TM5SPDG12F
TM5 Power Distribution Module
Where It Excels in Industrial Use
• Distributed I/O Power Supply Systems
Designed for Modicon TM5 automation architectures requiring a stable 24 V DC power source for I/O power segments, ensuring reliable operation of connected expansion modules.
• Large-Scale Machine Control Cabinets
Ideal for complex industrial control panels where multiple I/O modules require independent power distribution and efficient electrical organization.
• OEM Automation Equipment
Provides machine builders with a practical power expansion solution for packaging machines, material handling systems, and customized automation platforms.
• Modular Industrial Control Applications
Suitable for scalable automation systems where additional I/O capacity requires structured and dependable 24 V DC power management.
Key Strengths at a Glance
• 10 A I/O Power Segment Capacity
Provides up to 10 A current for the 24 V DC I/O power segment, supporting extensive TM5 I/O configurations and field device connections.
• Dedicated 24 V DC Power Distribution
Designed to supply 24 V DC power to TM5 I/O modules, helping separate power distribution tasks from controller power management.
• Compact Modular Installation
The TM5 modular format allows efficient DIN rail mounting while maintaining a clean and organized control cabinet layout.
• Reliable Industrial Power Management
Supports stable operation in automation environments with integrated monitoring capability and compatibility with Schneider Electric TM5 control systems.
Technical FAQs
1. What type of module is the Schneider TM5SPS1?
The Schneider TM5SPS1 is a power distribution module designed for the Modicon TM5 modular I/O system.
2. What is the primary function of the TM5SPS1?
The module provides a 24 V DC power supply segment for connected TM5 I/O modules and field devices.
3. What input voltage does the TM5SPS1 require?
The TM5SPS1 operates with a rated 24 V DC supply voltage.
4. How much current can the TM5SPS1 provide?
The module can provide up to 10 A for the 24 V DC I/O power segment.
5. Does the TM5SPS1 generate TM5 bus power?
No. The TM5SPS1 provides I/O power segment distribution and does not generate additional TM5 bus power.
6. Which controllers are compatible with the TM5SPS1?
The module is compatible with Modicon TM5 systems and can be used with supported Modicon automation controllers.
7. Does the TM5SPS1 require external protection?
Yes. External fuse protection is required to protect the power segment according to application requirements.
8. What type of applications commonly use the TM5SPS1?
Typical applications include industrial machinery, packaging systems, material handling equipment, and distributed I/O automation systems.
9. Can the TM5SPS1 be combined with other TM5 expansion modules?
Yes. The module is designed to integrate with TM5 electronic modules to expand automation system configurations.
10. What installation method does the TM5SPS1 support?
The module supports DIN rail mounting within industrial control cabinets.
