Brand:Schneider PLC Item No.:TM5SPS2 Product Origin:France Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5SPS2 Power Distribution Module is a high-performance power management component developed for Modicon TM5 automation systems. Unlike standard I/O modules, it focuses on maintaining stable power distribution across expanded TM5 configurations by supplying both the internal TM5 power bus and the 24 V DC I/O power segment.
With its 10 A I/O power segment capability, 1136 mA TM5 bus generation, and compact modular design, the TM5SPS2 provides engineers with a dependable solution for large-scale automation architectures. It helps optimize cabinet organization, simplify wiring, and improve the scalability of industrial control systems.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5SPS2
Product Family
Modicon TM5
Module Type
Power Distribution Module
Main Function
TM5 Bus and 24 V DC I/O Power Distribution
Rated Supply Voltage
24 V DC
Supply Voltage Range
20.4…28.8 V DC
TM5 Power Bus Current Generated
1136 mA
24 V DC I/O Power Segment Current
10 A maximum
Input Current
0.7 A maximum at 24 V DC
Current Consumption
25 mA
Reverse Polarity Protection
Yes
Fuse Protection
Integrated for TM5 bus / External 10 A fuse for I/O segment
Maximum Power Dissipation
1.91 W
Parallel Operation
Supported
Isolation Voltage
500 V AC RMS
Compatible Systems
Modicon TM5
Mounting Type
DIN Rail
Protection Rating
IP20
Dimensions
Approx. 12.5 × 99 × 75 mm
Weight
Approx. 30 g
Recommended Companion Models
Model
Product Name
Schneider TM5ACBM15
TM5 Addressable Bus Base Module
Schneider TM5ACTB12PS
TM5 Power Supply Terminal Block
Schneider TM5SDI12D
TM5 Digital Input Module
Schneider TM5SDO16T
TM5 Digital Output Module
Frequently Selected Alternatives
Model
Product Name
Schneider TM5SPS1
TM5 Power Distribution Module
Schneider TM5SPDG6D6F
TM5 Power Distribution Module
Schneider TM5SPDG12F
TM5 Power Distribution Module
Schneider TM5SMM6D2L
TM5 Mixed I/O Module
Where It Excels in Industrial Use
• Expanded TM5 I/O Power Architectures
Designed for Modicon TM5 systems requiring additional 24 V DC I/O power distribution and TM5 bus power generation, supporting larger and more complex automation configurations.
• Industrial Machine Control Cabinets
Ideal for packaging machinery, material handling equipment, and automated production lines where stable power distribution is essential for multiple I/O modules and field devices.
• Modular OEM Automation Equipment
Provides machine builders with a scalable power expansion solution, helping simplify cabinet layouts and improve system reliability in customized automation projects.
• Distributed I/O Expansion Systems
Suitable for applications requiring independent 24 V DC I/O power segments while maintaining efficient TM5 bus communication and module management.
Key Strengths at a Glance
• Dual Power Distribution Capability
Supplies both the TM5 power bus and the 24 V DC I/O power segment, enabling flexible expansion of TM5 automation islands.
• High Current Output Capacity
Provides up to 10 A for the 24 V DC I/O power segment and generates up to 1136 mA for the TM5 power bus, supporting extensive I/O configurations.
• Integrated Power Protection Design
Features integrated protection for TM5 power bus operation and supports external fuse protection for the 24 V DC I/O power segment.
• Reliable Modular Integration
Designed specifically for Modicon TM5 architectures, allowing easy DIN rail installation and efficient expansion of industrial control systems.
Technical FAQs
1. What type of module is the Schneider TM5SPS2?
The Schneider TM5SPS2 is a power distribution module designed for the Modicon TM5 modular I/O system.
2. What is the main function of the TM5SPS2?
The TM5SPS2 provides power distribution for TM5 I/O modules by supplying the TM5 power bus and the 24 V DC I/O power segment.
3. What input voltage does the TM5SPS2 require?
The module operates with a 24 V DC rated supply voltage and supports a supply range of 20.4 to 28.8 V DC.
4. How much current can the TM5SPS2 provide to the I/O power segment?
The module can provide up to 10 A for the 24 V DC I/O power segment.
5. How much current does the TM5SPS2 generate for the TM5 power bus?
The module generates up to 1136 mA for the TM5 power bus under standard operating conditions.
6. Does the TM5SPS2 support parallel operation?
Yes. The module supports parallel operation when configured according to Schneider Electric system requirements.
7. What type of protection is included in the TM5SPS2?
The module includes integrated TM5 power bus protection and requires external slow-blow fuse protection for the 24 V DC I/O power segment.
8. Which Schneider Electric controllers are compatible with the TM5SPS2?
The TM5SPS2 is compatible with Modicon TM5 systems used with supported logic controllers and motion controllers.
9. What applications commonly use the TM5SPS2?
Typical applications include machine automation, packaging systems, material processing equipment, and distributed I/O control installations.
10. What installation method does the TM5SPS2 support?
The module is designed for DIN rail mounting as part of a Modicon TM5 modular I/O assembly.
