Brand:Schneider PLC Item No.:TMASD1 Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TMASD1 Memory Card Module is a dedicated storage accessory developed for Modicon M2xx controllers, including Modicon M221, M241, and M251 platforms. It provides engineers with a practical solution for application backup, program transfer, and controller maintenance.
Designed for industrial automation environments, the TMASD1 helps simplify machine commissioning and service operations by allowing programs and data to be securely stored and transferred. With its compact format, reliable Flash memory technology, and seamless controller compatibility, it is an essential accessory for professional automation projects.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TMASD1
Product Family
Modicon TM
Module Type
Memory Card Module
Accessory Type
SD Card
Compatible Controllers
Modicon M221 / M241 / M251
Memory Technology
Flash Memory
Memory Capacity
256 MB
Application
Program Transfer / Backup / Data Storage
Data Retention Time
10 Years at 25°C
Read/Write Cycles
100,000 Cycles
MTBF
3,000,000 Hours
Operating Temperature
-10…70°C
Storage Temperature
-25…85°C
Shock Resistance
15 gn
Vibration Resistance
1 gn
Protection Rating
Industrial SD Storage Accessory
Dimensions
Approx. 32 × 24 × 2.1 mm
Weight
Approx. 4 g
Recommended Companion Models
Model
Product Name
Schneider TM241CEC24T
Modicon M241 Ethernet Controller
Schneider TM221CE16R
Modicon M221 Logic Controller
Schneider TM251MESE
Modicon M251 Logic Controller
Schneider TM3XREC1
Modicon TM3 Expansion Receiver Module
Frequently Selected Alternatives
Model
Product Name
Schneider TMAT2PSET
Modicon M221 Power Supply Connector Set
Schneider TM3BCEIP
Modicon TM3 Ethernet Bus Coupler
Schneider TM3AI4
Modicon TM3 Analog Input Module
Schneider TM3DQ16R
Modicon TM3 Digital Output Module
Where It Excels in Industrial Use
• PLC Program Backup and Transfer Applications
Designed for Modicon M2xx controllers, the TMASD1 provides a convenient method for storing, transferring, and restoring controller applications during machine commissioning and maintenance.
• Machine Duplication and OEM Production
Ideal for OEM manufacturers who need to quickly replicate PLC programs across multiple machines, reducing setup time during large-scale equipment deployment.
• Industrial Data Storage and Firmware Management
Supports application backup, firmware loading, and controller data management, helping improve system maintenance efficiency.
• Automation System Maintenance Solutions
Provides engineers with a reliable removable storage option for Modicon M221, M241, and M251 controller environments.
Key Strengths at a Glance
• Dedicated Modicon Controller Memory Expansion
Specifically designed for Modicon M2xx controller families, ensuring compatibility and reliable operation within Schneider Electric automation platforms.
• 256 MB Flash Memory Capacity
Provides sufficient storage space for PLC applications, backups, and controller-related files in industrial automation environments.
• Fast Application Transfer Capability
Allows engineers to copy and restore automation programs efficiently, improving commissioning speed and reducing downtime.
• Long-Term Data Retention Performance
Offers reliable flash memory storage with long retention capability for industrial control applications.
Technical FAQs
1. What type of module is the Schneider TMASD1?
The Schneider TMASD1 is an SD memory card accessory designed for Modicon M2xx series controllers.
2. Which Schneider Electric controllers are compatible with the TMASD1?
The TMASD1 is compatible with Modicon M221, Modicon M241, and Modicon M251 logic controllers.
3. What is the storage capacity of the TMASD1 memory card?
The TMASD1 provides 256 MB Flash memory capacity for controller application storage.
4. What are the main functions of the TMASD1?
The memory card is used for application backup, program transfer, firmware management, and controller data storage.
5. Can the TMASD1 be used to duplicate PLC programs?
Yes. It allows stored applications to be transferred between compatible Modicon controllers for faster machine replication.
6. Is the TMASD1 a standard commercial SD card?
No. It is a Schneider Electric industrial memory accessory designed specifically for Modicon M2xx controllers.
7. Does the TMASD1 support firmware transfer?
Yes. The card can be used for supported firmware update and controller maintenance operations.
8. How is the TMASD1 installed?
The memory card is inserted into the dedicated SD card interface of compatible Modicon controllers.
9. What type of memory technology does the TMASD1 use?
The TMASD1 uses Flash memory technology for industrial application storage.
10. What industries commonly use the TMASD1?
It is commonly used in machine automation, packaging equipment, manufacturing systems, and OEM control applications.
