Brand:Schneider PLC Item No.:TMC4AI2 Product Origin:France Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TMC4AI2 Analog Input Cartridge Module is a compact expansion solution designed to enhance the analog measurement capability of Modicon M241 controllers. With two configurable analog input channels supporting voltage and current signals, it enables seamless integration of industrial sensors into modern automation systems.
Engineered for machine automation applications, the TMC4AI2 helps simplify control cabinet design while providing reliable signal acquisition for monitoring and process control. Its flexible input configuration makes it suitable for OEM equipment, production machinery, and compact industrial control solutions.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TMC4AI2
Product Family
Modicon M241
Module Type
Analog Input Cartridge Module
Number of Analog Inputs
2
Input Signal Type
Voltage / Current
Voltage Input Range
0…10 V DC
Current Input Range
0…20 mA / 4…20 mA
Resolution
12 bits
Sampling Duration
10 ms
Accuracy Error
±0.2% Full Scale at 25°C
Temperature Drift
±0.006% FS/°C
Input Connection
Removable Spring Terminal Block
Terminal Pitch
3.81 mm
Supply Voltage
20.4…28.8 V DC
Input Protection
Voltage and Current Overload Protection
Communication Interface
Controller Cartridge Interface
Compatible Controller
Modicon M241
Mounting Type
Controller Cartridge Mounting
Dimensions
Approx. 34 × 50 × 21 mm
Weight
Approx. 55 g
Recommended Companion Models
Model
Product Name
Schneider TM241CEC24T
Modicon M241 Ethernet Controller
Schneider TM241CE40T
Modicon M241 Logic Controller
Schneider TM241C24R
Modicon M241 Compact Controller
Schneider TM3AI4
Modicon TM3 Analog Input Module
Frequently Selected Alternatives
Model
Product Name
Schneider TMC4TI2
Modicon M241 Temperature Input Cartridge
Schneider TMC4HOIS01
Modicon M241 High Speed Output Cartridge
Schneider TM3AI2H
Modicon TM3 Analog Input Module
Schneider TM5SAI2H
Modicon TM5 Analog Input Module
Where It Excels in Industrial Use
• Machine Sensor Data Acquisition
Designed for Modicon M241 controllers, the TMC4AI2 provides additional analog input capability for collecting real-time signals from industrial sensors, transmitters, and measurement devices.
• Process Monitoring and Control Systems
Suitable for applications requiring continuous monitoring of pressure, flow, level, speed, and other analog process variables through standard industrial signals.
• Compact OEM Machine Automation
Ideal for machine builders who need to expand controller functionality without adding a separate external I/O rack, helping maintain compact cabinet designs.
• Precision Measurement Applications
Provides reliable analog signal conversion for equipment requiring accurate voltage or current measurement within automated production environments.
Key Strengths at a Glance
• Dual Analog Input Expansion
Provides two configurable analog input channels, allowing Modicon M241 controllers to connect multiple field measurement devices.
• Multiple Signal Type Support
Supports 0…10 V voltage input as well as 0…20 mA and 4…20 mA current input signals, offering flexible compatibility with industrial sensors.
• 12-Bit Signal Resolution
Delivers 4096-step analog conversion for stable and accurate measurement processing in automation applications.
• Space-Saving Cartridge Design
The compact cartridge format integrates directly with Modicon M241 controllers, reducing wiring complexity and simplifying system expansion.
Technical FAQs
1. What type of module is the Schneider TMC4AI2?
The Schneider TMC4AI2 is an analog input cartridge designed for Modicon M241 logic controllers.
2. How many analog input channels does the TMC4AI2 provide?
The TMC4AI2 provides two analog input channels for connecting compatible industrial sensors and transmitters.
3. What input signal types are supported by the TMC4AI2?
The module supports 0…10 V voltage input, 0…20 mA current input, and 4…20 mA current input signals.
4. What is the resolution of the TMC4AI2 analog inputs?
The module provides 12-bit analog resolution, corresponding to 4096 measurement steps.
5. Which controller is compatible with the TMC4AI2?
The TMC4AI2 is designed for Modicon M241 logic controllers.
6. What type of connection does the TMC4AI2 use?
The cartridge uses a removable spring terminal block with a 3.81 mm pitch connection design.
7. Can the TMC4AI2 be used with 4–20 mA transmitters?
Yes. The module supports standard 4–20 mA industrial transmitter signals for measurement applications.
8. What software is used to configure the TMC4AI2?
The cartridge can be configured through EcoStruxure Machine Expert software for Modicon controller programming and I/O setup.
9. What industries commonly use the TMC4AI2?
Typical applications include packaging machinery, process equipment, material handling systems, and automated production lines.
10. Does the TMC4AI2 require additional communication hardware?
No. The cartridge communicates directly through the compatible Modicon M241 controller architecture.
