Brand:Schneider PLC Item No.:TSX3710001 Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TSX3710001 PLC Processor Module is a Modicon TSX Micro controller designed for dependable industrial automation control. As part of the TSX37 series, it integrates PLC processing capability, memory resources, power supply, and expansion support into a compact controller solution.
Built for industrial environments where reliability and continuity are essential, the TSX3710001 remains a practical choice for machine maintenance, automation upgrades, and legacy system support. Its modular architecture enables flexible configuration while helping users preserve existing control strategies and reduce migration costs.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TSX3710001
Product Family
Modicon TSX Micro
Module Type
PLC Processor Module
Controller Type
Compact Modular PLC
Power Supply
100…240 V AC
Supply Frequency
50/60 Hz
Expansion Slots
2 Slots
Analog Input Capability
0…10 V
Analog Output Capability
0…10 V
Output Current
0.5 A
Program Memory
Up to 128 Kwords Program & Data
Internal Data Memory
Up to 20 Kwords RAM
Flash Memory
15 Kwords Data
Communication
Serial Communication Interface
Supported Programming Software
PL7 Micro
Mounting Type
Base / Rack Installation
Operating Temperature
0…60 °C
Protection Rating
IP20
Dimensions
Approx. 172 × 150 × 132 mm
Weight
Approx. 1.5 kg
Recommended Companion Models
Model
Product Name
Schneider TSX3705001
Modicon TSX Micro PLC Base Controller
Schneider TSX3721001
Modicon TSX Micro PLC Controller
Schneider TSXDMZ28DR
Modicon TSX Micro Digital Input/Output Module
Schneider TSXASZ200
Modicon TSX Micro Analog Input Module
Frequently Selected Alternatives
Model
Product Name
Schneider TSX3708001
Modicon TSX Micro PLC Base Controller
Schneider TSX3722001
Modicon TSX Micro PLC Controller
Schneider TM221CE16R
Modicon M221 Logic Controller
Schneider TM241CE24T
Modicon M241 Logic Controller
Where It Excels in Industrial Use
• Legacy Machine Automation Control
Designed for the Modicon TSX Micro platform, the TSX3710001 provides reliable PLC control performance for existing industrial systems requiring stable operation and long-term maintenance support.
• Factory Equipment Retrofit Projects
Well suited for upgrading or maintaining established automation installations where replacing the entire control architecture is not practical.
• Compact Production Machinery
Suitable for packaging machines, assembly equipment, material handling systems, and other industrial applications requiring compact PLC-based control.
• Small and Medium Automation Systems
Provides integrated processing, memory, communication, and expansion capability for applications built around the Modicon TSX Micro family.
Key Strengths at a Glance
• Integrated TSX Micro Base Controller Design
Combines PLC processing functions, power supply, memory resources, and expansion interfaces in a compact automation controller platform.
• Flexible Expansion Architecture
Supports additional TSX Micro modules, allowing users to increase digital I/O, analog functions, and communication capabilities according to application requirements.
• Reliable Industrial Communication
Supports serial communication functions suitable for industrial networking and Modbus-based automation environments when configured with compatible hardware and software.
• Proven Legacy PLC Performance
Offers dependable control execution for installed TSX Micro systems, making it valuable for industrial maintenance, spare replacement, and retrofit applications.
Technical FAQs
1. What type of product is the Schneider TSX3710001?
The Schneider TSX3710001 is a Modicon TSX Micro PLC base controller designed for industrial automation applications.
2. Which automation platform does the TSX3710001 belong to?
The TSX3710001 belongs to the Modicon TSX Micro automation platform.
3. What power supply does the TSX3710001 use?
The TSX3710001 uses a 100…240 V AC power supply range.
4. How many expansion slots are available on the TSX3710001?
The controller provides expansion capability through its modular slot structure, allowing additional TSX Micro modules to be installed.
5. What programming software is used with the TSX3710001?
The TSX3710001 is programmed using Schneider Electric PL7 programming software designed for TSX Micro controllers.
6. Does the TSX3710001 support Modbus communication?
Yes. Compatible TSX Micro models in this range support Modbus RTU communication through the integrated communication interface or additional communication options.
7. What type of applications commonly use the TSX3710001?
Typical applications include industrial machinery, production lines, packaging equipment, and automation retrofit projects.
8. Can the TSX3710001 be expanded with additional I/O modules?
Yes. The controller supports compatible TSX Micro expansion modules for increasing system functionality.
9. Is the TSX3710001 still part of Schneider Electric’s current product range?
The TSX3710001 is a legacy Modicon TSX Micro product and is mainly used today for maintenance, replacement, and retrofit applications.
10. What makes the TSX3710001 suitable for replacement projects?
Its compatibility with existing TSX Micro systems allows engineers to maintain proven machine control designs while extending equipment service life.
