Brand:Schneider PLC Item No.: TSX3722000 Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TSX3722000 PLC Processor Module is a Modicon TSX Micro modular base controller developed for industrial applications requiring dependable processing capability, communication performance, and flexible system expansion. It combines PLC control functions with integrated automation features, providing engineers with a versatile solution for machine and process control.
Designed for demanding industrial environments, the TSX3722000 supports advanced automation requirements through integrated communication, analog functions, counting capability, and expandable memory options. Its proven TSX Micro architecture makes it a valuable choice for legacy system maintenance, OEM machinery, and industrial retrofit projects.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TSX3722000
Product Family
Modicon TSX Micro
Module Type
PLC Processor Module
Product Type
Modular Base Controller
Power Supply
100…240 V AC
Supply Voltage Range
90…264 V AC
Number of Slots
3
Communication Interface
TER/AUX Serial Link
Communication Protocol
Uni-Telway / Modbus RTU
Communication Speed
19.2 kbit/s
Analog Inputs
8 × 0…10 V
Analog Output
1 × 0…10 V
Counting Function
Incremental Counter, 10 Hz
Real-Time Clock
Integrated
Internal RAM
20 Kwords Data
Flash Memory
15 Kwords Data
PCMCIA Memory Support
128 Kwords Program and Data
Boolean Execution Time
0.13 μs
Programming Software
PL7
Expansion Capability
TSX Micro I/O Modules
Mounting Type
Modular Base Installation
Protection Rating
IP20
Dimensions
Approx. 137 × 116 × 69 mm
Weight
Approx. 0.58 kg
Recommended Companion Models
Model
Product Name
Schneider TSX3722001
Modicon TSX Micro 37 21/22 Modular Base Controller
Schneider TSX3721101
Modicon TSX Micro Modular Base Controller
Schneider TSXDMZ28DR
Modicon TSX Micro Digital I/O Module
Schneider TSXAEZ801
Modicon TSX Micro Analog Input Module
Frequently Selected Alternatives
Model
Product Name
Schneider TSX3721001
Modicon TSX Micro Modular Base Controller
Schneider TSX3710001
Modicon TSX Micro PLC Controller
Schneider TSX3708001
Modicon TSX Micro PLC Controller
Schneider TM241CE24T
Modicon M241 Logic Controller
Where It Excels in Industrial Use
• Advanced Machine Automation Control
The Schneider TSX3722000 is a Modicon TSX Micro modular base controller designed for demanding industrial automation applications. It provides reliable PLC processing, integrated communication, and expansion capability for manufacturing equipment and automated production systems.
• Industrial Retrofit and Legacy System Upgrade
Ideal for maintaining existing TSX Micro installations, the TSX3722000 allows engineers to replace aging control components while preserving proven PLC programs and established machine architectures.
• OEM Machinery and Production Lines
Suitable for packaging equipment, assembly machines, material handling systems, and process automation applications requiring compact but flexible PLC control.
• Multi-Function Automation Applications
With integrated analog processing, counting functions, communication interfaces, and modular expansion support, the TSX3722000 is suitable for complex automation tasks beyond basic digital control.
Key Strengths at a Glance
• Powerful TSX Micro 37 Series Architecture
Provides a modular PLC platform combining processing performance, memory management, communication functions, and expansion flexibility for industrial automation projects.
• Integrated Communication Interfaces
Includes TER/AUX serial communication and Modbus RTU connectivity, enabling communication with HMIs, drives, remote devices, and industrial networks.
• Enhanced Application Flexibility
Supports analog input/output functions, counting channels, event tasks, and memory expansion options for more advanced control applications.
• Reliable Long-Term Automation Solution
The TSX Micro platform provides proven industrial reliability, making the TSX3722000 a practical choice for system maintenance, replacement, and retrofit projects.
