Brand:Schneider PLC Item No.:TSX3722001 Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TSX3722001 PLC Processor Module is a Modicon TSX Micro modular base controller designed for industrial automation systems requiring reliable control performance and flexible configuration options.
Featuring integrated communication interfaces, analog processing capability, counting functions, and expandable memory resources, the TSX3722001 provides a versatile automation platform for machine builders and system integrators. Its modular design allows users to adapt control architectures according to different industrial requirements while maintaining dependable PLC operation.
The controller is particularly valuable in legacy automation environments where reliability, compatibility, and reduced downtime are critical factors. It offers an effective solution for maintaining existing TSX Micro-based systems and supporting long-term industrial operation.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TSX3722001
Product Family
Modicon TSX Micro
Module Type
PLC Processor Module
Product Type
Modular Base Controller
Primary Voltage
100…240 V AC
Voltage Range
90…264 V AC
Number of Slots
3
Communication Interface
TER/AUX Serial Link
Communication Protocol
Uni-Telway / Modbus RTU
Communication Speed
19.2 kbit/s
Analog Inputs
8 × 0…10 V
Analog Output
1 × 0…10 V
Counting Function
Incremental Counter 10 Hz
Real-Time Clock
Integrated
Internal RAM
20 Kwords Data
PCMCIA Memory Support
128 Kwords Program and Data
Flash Memory
15 Kwords Data
Boolean Execution Time
0.13 μs
Programming Software
PL7
Expansion Capability
TSX Micro Expansion Modules
Mounting Type
Modular Base Installation
Protection Rating
IP20
Dimensions
Approx. 190 × 100 × 90 mm
Weight
Approx. 1.36 kg
Recommended Companion Models
Model
Product Name
Schneider TSX3722000
Modicon TSX Micro Modular Base Controller
Schneider TSX3722001
Modicon TSX Micro Modular Base Controller
Schneider TSXDMZ28DR
Modicon TSX Micro Digital I/O Module
Schneider TSXAEZ801
Modicon TSX Micro Analog Input Module
Frequently Selected Alternatives
Model
Product Name
Schneider TSX3721101
Modicon TSX Micro Modular Base Controller
Schneider TSX3721001
Modicon TSX Micro Modular Base Controller
Schneider TSX3710001
Modicon TSX Micro PLC Controller
Schneider TM241CE24T
Modicon M241 Logic Controller
Where It Excels in Industrial Use
• Advanced Industrial Machine Control
The Schneider TSX3722001 is a Modicon TSX Micro modular base controller designed for automation systems requiring reliable PLC processing, flexible expansion, and integrated communication capabilities. It is widely suited for manufacturing machinery, production lines, and industrial control applications where stable operation is essential.
• Automation Retrofit and Legacy System Replacement
The TSX3722001 provides a practical solution for maintaining existing TSX Micro installations. It enables engineers to continue using proven PLC programs and existing automation structures while extending equipment service life.
• OEM Machinery and Process Equipment
Suitable for packaging systems, assembly equipment, conveyors, material handling systems, and customized industrial machines requiring compact but powerful PLC control.
• Integrated Control and Communication Applications
With analog processing, counting functions, serial communication, and modular expansion support, the TSX3722001 is suitable for automation projects requiring more than basic digital control.
Key Strengths at a Glance
• High-Flexibility TSX Micro Controller Architecture
Combines PLC processing, memory management, communication functions, and expansion capability in a compact modular controller platform for industrial applications.
• Integrated Uni-Telway and Modbus Communication
Provides built-in serial communication interfaces supporting Uni-Telway and Modbus RTU networks for connection with HMIs, industrial devices, and automation equipment.
• Enhanced Analog and Counting Functions
Includes analog input/output capability and incremental counting functions, allowing the controller to handle more complex automation requirements.
• Reliable Legacy Automation Platform
Based on the proven Modicon TSX Micro series, the TSX3722001 remains a dependable choice for industrial maintenance, spare replacement, and retrofit projects.
Technical FAQs
1. What type of product is the Schneider TSX3722001?
The Schneider TSX3722001 is a Modicon TSX Micro modular base controller designed for industrial PLC automation applications.
2. Which PLC family does the TSX3722001 belong to?
The TSX3722001 belongs to the Schneider Electric Modicon TSX Micro automation platform.
3. What power supply does the TSX3722001 require?
The TSX3722001 operates with a 100…240 V AC primary power supply range.
4. How many expansion slots are available on the TSX3722001?
The TSX3722001 provides three expansion slots for compatible TSX Micro modules.
5. Which communication protocols are supported by the TSX3722001?
The controller supports Uni-Telway and Modbus RTU communication through integrated TER/AUX serial interfaces.
6. What programming software is used with the TSX3722001?
The TSX3722001 is configured and programmed using Schneider Electric PL7 programming software for TSX Micro controllers.
7. Does the TSX3722001 support analog signals?
Yes. The controller supports 8 analog inputs and 1 analog output with a 0…10 V signal range.
8. Does the TSX3722001 include counting functions?
Yes. The controller includes an incremental counting input function supporting 10 Hz counting applications.
9. Can the TSX3722001 support memory expansion?
Yes. The controller supports PCMCIA memory expansion for additional program and data storage capacity.
10. What applications commonly use the TSX3722001?
Typical applications include industrial machinery, packaging equipment, process automation, production systems, and TSX Micro retrofit projects.
