Brand:Schneider PLC Item No.:TSXASZ401 Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TSXASZ401 Analog Output Module is a Modicon TSX Micro expansion module developed for industrial automation systems requiring dependable analog voltage control. Featuring four analog output channels with 0…10 V and ±10 V capability, it provides an efficient interface between PLC logic and analog-controlled field equipment.
Designed for machine builders, system integrators, and industrial maintenance teams, the TSXASZ401 offers reliable output performance for applications including drive control, actuator adjustment, and process regulation. Its compact TSX Micro architecture allows seamless integration into existing automation systems while maintaining stable long-term operation.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TSXASZ401
Product Family
Modicon TSX Micro
Module Type
Analog Output Module
Number of Analog Outputs
4
Output Type
Voltage Output
Output Range
0…10 V / ±10 V
Analog Conversion
11 bits (0…10 V), 11 bits + sign (±10 V)
Response Time
400 μs
Output Load
≥ 2 Ω
Protection Type
Short-Circuit Protection
Isolation Voltage
1000 V AC
Temperature Drift
0.096% / 10°C
Current Consumption
90 mA at 5 V DC
Connection Type
Screw Terminal Block
Mounting Type
TSX Micro Rack Installation
Protection Rating
IP20
Operating Temperature
0…60°C
Dimensions
Approx. 103 × 80 × 25 mm
Weight
Approx. 0.2 kg
Recommended Companion Models
Model
Product Name
Schneider TSX3722001
Modicon TSX Micro Modular Base Controller
Schneider TSXAEZ801
Modicon TSX Micro Analog Input Module
Schneider TSXAEZ802
Modicon TSX Micro Current Analog Input Module
Schneider TSXAMZ600
Modicon TSX Micro Analog Mixed I/O Module
Frequently Selected Alternatives
Model
Product Name
Schneider TSXASY410
Modicon Premium Analog Output Module
Schneider TSXASZ800
Modicon TSX Micro Analog Output Module
Schneider BMXAMO0410
Modicon X80 Analog Output Module
Schneider TM3AQ4
Modicon TM3 Analog Output Module
Where It Excels in Industrial Use
• Precision Analog Signal Output Control
The Schneider TSXASZ401 is a Modicon TSX Micro analog output module designed for industrial automation systems requiring stable and accurate voltage signal generation. With four analog output channels, it provides reliable control interfaces for actuators, variable speed drives, regulators, and other analog-controlled devices.
• Machine Automation and Equipment Regulation
Suitable for applications requiring PLC-controlled adjustment of speed, position, pressure, flow, or other industrial parameters through analog voltage outputs.
• Process Control System Expansion
The TSXASZ401 extends Modicon TSX Micro PLC capabilities by adding dedicated analog output functions, enabling automation systems to interact with field devices requiring continuous control signals.
• Legacy Automation Upgrade and Maintenance
A dependable option for engineers maintaining existing TSX Micro installations, helping extend the service life of established PLC systems while preserving original control architectures.
Key Strengths at a Glance
• Four-Channel Analog Voltage Output
Provides four independent analog outputs supporting 0…10 V and ±10 V signal ranges for flexible industrial control applications.
• Stable Signal Conversion Performance
Features 11-bit conversion for 0…10 V signals and 11-bit plus sign conversion for ±10 V operation, delivering reliable analog output resolution.
• Fast Response for Dynamic Control
With a response time of approximately 400 μs, the module supports applications requiring efficient analog signal updates.
• Integrated Protection Design
Includes short-circuit protection and channel isolation features to improve operational reliability in industrial environments.
Technical FAQs
1. What type of product is the Schneider TSXASZ401?
The Schneider TSXASZ401 is a Modicon TSX Micro analog output module designed for PLC-based industrial automation applications.
2. How many analog output channels does the TSXASZ401 provide?
The TSXASZ401 provides four analog output channels for voltage signal control.
3. Which output signal ranges are supported by the TSXASZ401?
The module supports 0…10 V and ±10 V analog voltage output ranges.
4. Which PLC platform is compatible with the TSXASZ401?
The TSXASZ401 is designed for Schneider Electric Modicon TSX Micro automation platforms.
5. What conversion resolution does the TSXASZ401 provide?
The module provides 11-bit conversion for 0…10 V output and 11-bit plus sign conversion for ±10 V output.
6. What devices can be controlled using the TSXASZ401?
The module can control compatible analog devices such as actuators, speed controllers, proportional valves, and industrial regulators.
7. Does the TSXASZ401 require an external power supply?
No. The module receives power through the TSX Micro PLC system backplane.
8. What protection functions are included in the TSXASZ401?
The module includes short-circuit protection to improve output reliability during industrial operation.
9. What programming software is used with the TSXASZ401?
The TSXASZ401 is configured through Schneider Electric PL7 programming software used with TSX Micro controllers.
10. Is the TSXASZ401 suitable for retrofit applications?
Yes. It is commonly selected for replacement, maintenance, and expansion projects involving existing Modicon TSX Micro automation systems.
