Brand:Schneider PLC Item No.:TSXCAY21 Product Origin: France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TSXCAY21 Motion Control Module is a Modicon Premium automation component developed for advanced servo motor control applications. Designed to provide precise positioning and coordinated motion management, it enables PLC-based systems to handle complex movement tasks across multiple industrial axes.
With support for two-axis control, flexible encoder feedback options, multiple operating modes, and advanced servo loop functions, the TSXCAY21 provides a powerful solution for machine builders and automation engineers working with high-performance motion applications.
The module is particularly valuable in industries requiring accurate synchronization, repeatable positioning, and reliable servo control, including packaging, material handling, and specialized manufacturing equipment.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TSXCAY21
Product Family
Modicon Premium
Module Type
Motion Control Module
Application
Servo Motor Control
Axis Number
2 Independent Axes
Axis Type
Limited Axis / Following Axis
Servo Loop Type
Proportional with Overshoot Compensation and Gain Switching
Servo Loop Response
2 ms
Operating Modes
Automatic / Manual / Direct Drive / Follower / OFF
Motion Profile
Trapezoidal / Parabolic
Axis Length
32000…32000000 position units
Acquisition Speed
54000…270000 points/min
Acceleration Time
8 ms…10 s
Encoder Support
Incremental Encoder / SSI Absolute Encoder
SSI Encoder Frequency
200 kHz
Incremental Encoder Frequency
Up to 500 kHz
Analog Output Range
±10 V
Analog Output Resolution
13 bits + sign
Power Dissipation
7.2…11.5 W
Current Consumption
200 mA at 5 V DC / 300 mA at 24 V DC
Connection Interface
SUB-D / HE-10 Connectors
Protection Rating
IP20
Mounting Type
Modicon Premium Rack Installation
Dimensions
Approx. 130 × 40 × 150 mm
Weight
Approx. 0.64 kg
Recommended Companion Models
Model
Product Name
Schneider TSXP572623M
Modicon Premium Processor Module
Schneider TSXRKY12
Modicon Premium Rack Module
Schneider TSXPSY2600
Modicon Premium Power Supply Module
Schneider TSXTAPS1505
Modicon Premium Encoder Connection Interface
Frequently Selected Alternatives
Model
Product Name
Schneider TSXCAY22
Modicon Premium Motion Control Module
Schneider TSXCAY33
Modicon Premium Motion Control Module
Schneider TSXCAY41
Modicon Premium Motion Control Module
Schneider TSXCAY42
Modicon Premium Motion Control Module
Where It Excels in Industrial Use
• High-Precision Servo Motion Applications
The Schneider TSXCAY21 is a Modicon Premium motion control module designed for servo motor control applications requiring accurate positioning, speed management, and coordinated axis movement. It supports control of up to two independent axes, making it suitable for demanding industrial motion systems.
• Packaging and Material Handling Equipment
The module is well suited for packaging machines, conveyors, textile equipment, and material handling systems where synchronized servo operation and repeatable positioning are essential.
• Machine Automation and Motion Upgrades
The TSXCAY21 provides advanced motion functionality for Modicon Premium PLC systems, allowing manufacturers to enhance existing automation platforms with dedicated servo control capabilities.
• Industrial Retrofit and Maintenance Projects
Designed for established Modicon Premium installations, the TSXCAY21 remains a practical choice for replacing existing motion modules and extending the service life of legacy automation equipment.
Key Strengths at a Glance
• Dual-Axis Servo Control Capability
Supports up to two independent motion axes, enabling flexible machine designs with coordinated servo motor control.
• Advanced Servo Loop Management
Features proportional servo loop control with overshoot compensation and gain switching, improving motion stability and positioning accuracy.
• Flexible Encoder Compatibility
Supports incremental encoders and absolute encoder interfaces, including SSI absolute encoder signals, providing compatibility with various motion feedback systems.
• Multiple Motion Operating Modes
Provides automatic, manual, direct drive, follower, and OFF operating modes to support different machine control strategies.
Technical FAQs
1. What type of product is the Schneider TSXCAY21?
The Schneider TSXCAY21 is a Modicon Premium motion control module designed for servo motor control applications.
2. How many axes can the TSXCAY21 control?
The TSXCAY21 can control up to two independent motion axes.
3. Which PLC platform is compatible with the TSXCAY21?
The TSXCAY21 is designed for the Schneider Electric Modicon Premium automation platform.
4. What types of motors are supported by the TSXCAY21?
The module is designed specifically for servo motor control applications.
5. What encoder types can be connected to the TSXCAY21?
The TSXCAY21 supports incremental encoder inputs and absolute encoder interfaces, including SSI absolute encoder connections.
6. What motion profile functions are available on the TSXCAY21?
The module supports trapezoidal and parabolic speed profile paths for motion trajectory control.
7. What operating modes does the TSXCAY21 provide?
The TSXCAY21 supports automatic mode, manual mode, direct drive mode, follower mode, and OFF mode.
8. What feedback signals can the TSXCAY21 monitor?
The module can monitor encoder feedback, sensor feedback, counter inputs, servo drive status, and movement execution conditions.
9. What is the analog output capability of the TSXCAY21?
The TSXCAY21 provides analog output with a range of ±10 V and 13-bit plus sign resolution for motion reference signals.
10. Is the TSXCAY21 suitable for existing automation systems?
Yes. The TSXCAY21 is commonly used for maintenance, replacement, and retrofit projects involving Modicon Premium motion control systems.
