Ingersoll Rand 47588684001 85563245 Hydraulic Hose Maintenance Kit

Where It Excels in Industrial Use

• Industrial Air Compressor Service — The 47588684001 maintenance kit is intended for hose-related service on compatible Ingersoll Rand compressor systems, making it suitable for maintenance teams responsible for keeping critical compressed-air equipment operational.

• High-Flow Hose Applications — The associated 85563245 hose is identified as a 2.00-inch × 38.00-inch hydraulic hose, providing a substantially larger flow path than the 1.00-inch hose configurations used in many other compressor service applications.

• Heavy-Duty Maintenance Operations — Its large-bore hose configuration makes the component relevant to demanding industrial equipment where secure fluid or air routing and robust hose construction are important to reliable operation.

• Planned Replacement Programs — Incorporating the hose into scheduled maintenance allows service personnel to address aging or deteriorated hose assemblies before leakage, mechanical damage, or connection failure becomes an unplanned production issue.

Key Strengths at a Glance

• Defined OEM Part Reference — 85563245 provides a specific Ingersoll Rand replacement reference, helping maintenance teams avoid uncertain dimensional substitutions when servicing compatible compressor equipment.

• Large 2.00-Inch Hose Size — The documented 2.00-inch hose diameter provides a large flow passage suited to applications requiring substantial fluid or air movement through the associated compressor circuit.

• 38-Inch Hose Configuration — The 38.00-inch specification provides a defined replacement length, helping preserve the intended routing and connection geometry of the original installation.

• Superseding Replacement Available — 85563245 is listed as superseded by Ingersoll Rand replacement part 24279002, giving maintenance teams an alternative OEM reference when the original part is no longer supplied.

Technical FAQs

1. What is Ingersoll Rand 47588684001?

47588684001 is identified as a water-cooled hose maintenance kit associated with Ingersoll Rand compressor service applications.

2. What is Ingersoll Rand 85563245?

85563245 is an Ingersoll Rand hydraulic hose identified in current product listings as a 2.00-inch × 38.00-inch hose.

3. What is the nominal diameter of 85563245?

The listed nominal hose size is 2.00 inches.

4. What is the specified length of 85563245?

Current replacement listings specify the hose at 38.00 inches in length.

5. Can 85563245 be replaced by another 2.00-inch hose?

Not automatically. The complete application, hose construction, fittings, pressure capability, temperature range, length, and routing must be verified before selecting a replacement.

6. Why is the correct hose length important during compressor maintenance?

Maintaining the specified length helps preserve the original routing and prevents excessive tension, sharp bends, abrasion, or interference with surrounding equipment.

7. What should be checked when replacing 85563245?

Technicians should verify the compressor model, hose routing, end connections, sealing surfaces, clearance from hot or moving components, and the applicable replacement-part documentation.

8. Is 85563245 still available under its original part number?

Current product information identifies 85563245 as superseded and lists 24279002 as its replacement reference.

9. Is 24279002 automatically interchangeable with 85563245?

It should not be assumed without checking the applicable compressor parts documentation. A superseding number normally requires confirmation that the newer configuration is approved for the specific equipment.

10. What can happen if a large-bore compressor hose deteriorates?

A deteriorated hose can develop leakage, structural damage, connection problems, or flow restrictions. In a production compressor system, such a failure can lead to equipment downtime and unplanned maintenance.
