The ABB TB806 Power Supply Module is an advanced and highly reliable 24V DC power solution designed for industrial automation applications. Whether you are powering control systems, programmable logic controllers (PLCs), sensors, or other vital automation components, the TB806 ensures your systems remain operational in even the most demanding industrial environments.

Offering a robust design with comprehensive protection features and high efficiency, the TB806 helps optimize your automation systems, reduce downtime, and minimize operational costs. The power supply module’s flexible installation and wide input voltage range make it an excellent choice for industrial sectors such as manufacturing, energy management, and material handling.

With its superior performance, the ABB TB806 is ideal for applications requiring stable, continuous 24V DC power to ensure reliable operation of critical industrial equipment.

Technical Specifications

Specification	Details
Model	TB806 Power Supply Module
Input Voltage	85-265 VAC, 47-63 Hz
Output Voltage	24V DC ±1%
Nominal Output Current	10A
Efficiency	92% (at full load)
Operating Temperature	-10°C to 60°C (14°F to 140°F)
Weight	2.1 kg (4.63 lbs)
Dimensions (W x H x D)	135 x 160 x 115 mm (5.31 x 6.30 x 4.53 inches)
Cooling Type	Forced Air Cooling
Protection Features	Overvoltage, Overcurrent, Overtemperature, Short Circuit, Surge Protection
Mounting Type	DIN Rail Mounting
Certifications	CE, UL, RoHS

Recommended Related Models

For varying industrial power needs, consider these related ABB models:

ABB TB804: A smaller power supply model for lower current requirements, suitable for less demanding applications.
ABB TB810: High-output power supply for larger systems or applications requiring more power.
ABB DCS 800 Series: A comprehensive range of power solutions for larger, complex industrial automation systems.
ABB PM850: A power protection module to safeguard systems against electrical disturbances and faults.
ABB SM860: A modular power supply system designed for scalable and flexible automation installations.

Popular ABB Models

ABB offers a wide variety of industrial automation products, including power supplies, control systems, and protection modules. Here are some of the most popular models:

ABB SD880: A robust and high-capacity power supply designed for heavy-duty industrial environments.
ABB ACS580: Energy-efficient variable frequency drives designed for precise motor control in industrial settings.
ABB IRB 6700: High-performance industrial robots for manufacturing, assembly, and material handling applications.
ABB PPM500: Power protection systems to ensure stable and safe operations of critical equipment.
ABB MNS 3.0: A modular power distribution system that is scalable for industrial plants and facilities.

Applications

The ABB TB806 Power Supply Module is ideal for a wide range of industrial automation applications:

Automation Systems: Provides 24V DC power to PLCs, control systems, and other automation devices, ensuring smooth and continuous operation.
Manufacturing Plants: Powers automated production lines, assembly robots, packaging machines, and other manufacturing equipment.
Material Handling: Powers conveyors, sorters, and automated storage/retrieval systems used in logistics, warehouses, and distribution centers.
HVAC Systems: Ideal for powering HVAC systems in large commercial and industrial facilities, ensuring optimal climate control.
Energy Systems: Powers control systems in energy management infrastructure, including renewable energy plants and electrical grids.

Advantages

High Efficiency: With an efficiency of 92% at full load, the TB806 reduces energy consumption, helps lower operational costs, and minimizes heat generation, contributing to overall system performance.
Compact and Durable: Despite its high output capacity, the TB806 features a compact design, making it easy to integrate into control panels and machinery enclosures while maintaining durability and reliability.
Advanced Protection Features: The TB806 is equipped with overvoltage, overcurrent, thermal, short-circuit, and surge protection to ensure the safety of both the power supply and the connected equipment.
Wide Input Voltage Range: The TB806 operates with an input voltage range of 85-265 VAC, making it suitable for global use with varying power supply standards.
Easy Installation: Designed for DIN rail mounting, the TB806 allows for simple installation in industrial control panels or enclosures, saving time and effort during setup.
Long-Term Reliability: Built for continuous operation in harsh industrial environments, the TB806 offers high reliability and durability, minimizing downtime and maintenance costs.

Technical FAQs

What is the input voltage range for the ABB TB806?
- The TB806 can operate within an input voltage range of 85-265 VAC, making it adaptable for use in different regions around the world.
What is the efficiency rating of the TB806?
- The TB806 operates at 92% efficiency at full load, reducing energy consumption and minimizing heat generation.
What protection features are included with the TB806?
- The TB806 comes with overvoltage, overcurrent, short-circuit, thermal, and surge protection to safeguard both the power supply and connected systems.
How much current can the TB806 supply?
- The TB806 can supply up to 10A of current at 24V DC, making it ideal for medium to large industrial automation systems.
Can the TB806 be used outdoors?
- The TB806 is designed for indoor use, but it can be housed in a protective enclosure for outdoor use or in harsh environmental conditions.
What is the operating temperature range for the TB806?
- The TB806 operates within a temperature range of -10°C to 60°C (14°F to 140°F), suitable for most industrial applications.
How is the TB806 mounted?
- The TB806 uses a standard DIN rail mounting system for easy installation in industrial control panels or enclosures.
What are the dimensions and weight of the TB806?
- The TB806 weighs 2.1 kg (4.63 lbs) and has dimensions of 135 x 160 x 115 mm (5.31 x 6.30 x 4.53 inches), making it compact and easy to install.
Is the TB806 suitable for large systems?
- Yes, the TB806’s 10A output is suitable for medium to large industrial systems that require stable 24V DC power.
Can the TB806 be integrated with other ABB systems?
- Yes, the TB806 is compatible with other ABB automation products, allowing for seamless integration into larger systems.
