The ABB TB807 Power Supply Module is a high-performance and reliable 24V DC power solution designed to meet the needs of industrial automation systems. Whether you're powering programmable logic controllers (PLCs), sensors, or other critical industrial equipment, the TB807 ensures stable and uninterrupted operation, even in the most demanding environments.

Built with energy efficiency and long-term durability in mind, the TB807 helps optimize industrial automation systems, reduce operational costs, and minimize downtime. Featuring advanced protection mechanisms, it safeguards both the power supply module and connected equipment from electrical disturbances such as overvoltage, short circuits, and thermal overload. Its compact design and flexible mounting options make it easy to integrate into various industrial applications, from manufacturing plants to energy management systems.

Technical Specifications

Specification	Details
Model	TB807 Power Supply Module
Input Voltage	85-265 VAC, 47-63 Hz
Output Voltage	24V DC ±1%
Nominal Output Current	12A
Efficiency	93% (at full load)
Operating Temperature	-10°C to 70°C (14°F to 158°F)
Weight	2.3 kg (5.07 lbs)
Dimensions (W x H x D)	145 x 170 x 125 mm (5.71 x 6.69 x 4.92 inches)
Cooling Type	Forced Air Cooling
Protection Features	Overvoltage, Overcurrent, Overtemperature, Short Circuit, Surge Protection
Mounting Type	DIN Rail Mounting
Certifications	CE, UL, RoHS

Recommended Related Models

For varying power supply needs, you can also consider these related ABB models:

ABB TB805: A lower-output power supply module for systems with less power demand.
ABB TB810: A higher-output power supply solution for larger industrial applications requiring more current.
ABB DCS 800 Series: A comprehensive range of power and control systems tailored to complex automation setups.
ABB PM850: A power protection module that ensures the safety and stability of your equipment.
ABB SM860: Modular and scalable power supplies for flexible industrial automation configurations.

Popular ABB Models

ABB provides a range of advanced industrial solutions. Here are some of the most popular models:

ABB SD880: A rugged and high-capacity power supply for heavy-duty industrial environments.
ABB ACS580: Variable frequency drives for optimized motor control in industrial applications.
ABB IRB 6700: High-precision industrial robots designed for demanding manufacturing tasks.
ABB PPM500: Power protection systems designed to safeguard industrial systems against power fluctuations.
ABB MNS 3.0: Modular and flexible power distribution systems, ideal for complex industrial plants.

Applications

The ABB TB807 Power Supply Module is designed for use in various industrial automation applications:

Automation Systems: Supplies 24V DC power to PLCs, control systems, and automation devices, ensuring reliable and uninterrupted performance.
Manufacturing Plants: Powers automated production lines, assembly robots, packaging machines, and other manufacturing systems.
Material Handling: Ideal for powering conveyors, sorters, and automated storage/retrieval systems used in warehouses and logistics.
HVAC Systems: Provides reliable 24V DC power for heating, ventilation, and air conditioning systems in large commercial and industrial buildings.
Energy Management: Powers control systems in energy plants, electrical grids, and renewable energy infrastructure.

Advantages

High Efficiency: With 93% efficiency at full load, the TB807 helps reduce energy consumption, minimize heat generation, and lower overall operational costs.
Advanced Protection: Equipped with overvoltage, overcurrent, thermal, short-circuit, and surge protection, the TB807 ensures the safety of both the power supply and the connected systems.
Compact and Durable: The TB807 features a compact design, making it easy to integrate into control panels and enclosures, while still delivering high output power.
Wide Input Voltage Range: The TB807 operates within an input voltage range of 85-265 VAC, ensuring compatibility with power supplies in different regions.
Easy Installation: The TB807 is designed for DIN rail mounting, making it simple to install in industrial control panels, saving time and reducing installation complexity.
Reliable Long-Term Operation: Built to withstand harsh industrial conditions, the TB807 provides continuous, reliable power to critical systems, reducing maintenance and downtime.

Technical FAQs

What is the input voltage range for the ABB TB807?
- The TB807 operates within an input voltage range of 85-265 VAC, making it suitable for use in different geographical regions.
What is the efficiency rating of the TB807?
- The TB807 achieves 93% efficiency at full load, which helps to minimize energy consumption and reduce operating costs.
What protection features are included with the TB807?
- The TB807 includes overvoltage, overcurrent, thermal protection, short-circuit protection, and surge protection to ensure the safety of both the power supply and the connected systems.
How much current can the TB807 supply?
- The TB807 can supply up to 12A of current at 24V DC, making it ideal for medium to large industrial automation systems.
Can the TB807 be used outdoors?
- The TB807 is designed for indoor use. However, it can be housed in a protective enclosure for use in outdoor environments or harsh conditions.
What is the operating temperature range for the TB807?
- The TB807 operates in a temperature range of -10°C to 70°C (14°F to 158°F), suitable for a variety of industrial applications.
How is the TB807 mounted?
- The TB807 uses DIN rail mounting, allowing for quick and easy installation in industrial control panels or machinery enclosures.
What are the dimensions and weight of the TB807?
- The TB807 weighs 2.3 kg (5.07 lbs) and has dimensions of 145 x 170 x 125 mm (5.71 x 6.69 x 4.92 inches), making it compact for its output capacity.
Is the TB807 suitable for large systems?
- Yes, with a 12A output, the TB807 is ideal for medium to large industrial systems that require reliable 24V DC power.
Can the TB807 be integrated with other ABB systems?
- Yes, the TB807 is fully compatible with other ABB products, making it easy to integrate into larger industrial control systems.
