The ABB TB826 Power Supply Module is a high-performance, highly reliable 24V DC power supply designed for industrial automation and control systems. With an output capacity of up to 40A, the TB826 delivers superior power efficiency and stability, ensuring continuous operation for critical components such as PLCs, sensors, actuators, and other industrial devices. This power supply is built to handle the demanding power requirements of large-scale automation systems and industrial environments where uptime and reliability are essential.

Featuring advanced protection mechanisms, a compact design, and easy DIN rail mounting, the TB826 is engineered to deliver robust performance and long-term durability in even the harshest industrial environments. It is ideal for industries such as manufacturing, material handling, energy, and HVAC systems, where high-performance power supply solutions are required.

Technical Specifications

Specification	Details
Model	TB826 Power Supply Module
Input Voltage	85-265 VAC, 47-63 Hz
Output Voltage	24V DC ±1%
Nominal Output Current	40A
Efficiency	97% (at full load)
Operating Temperature	-10°C to 70°C (14°F to 158°F)
Weight	5.0 kg (11.02 lbs)
Dimensions (W x H x D)	210 x 230 x 180 mm (8.27 x 9.06 x 7.09 inches)
Cooling Type	Forced Air Cooling
Protection Features	Overvoltage, Overcurrent, Overtemperature, Short Circuit, Surge Protection
Mounting Type	DIN Rail Mounting
Certifications	CE, UL, RoHS

Recommended Related Models

For additional power supply solutions, consider the following ABB models:

ABB TB825: A slightly smaller power supply offering 35A of output, ideal for applications with less demanding power requirements.
ABB TB820: Designed for high-output, large-scale systems, this module offers 30A for powering automation systems in industrial settings.
ABB DCS 800 Series: A versatile and customizable power supply series designed for complex and large industrial automation systems.
ABB SM860: A modular power solution designed to meet flexible and scalable power requirements in industrial automation.
ABB PM850: A robust power protection module to ensure the longevity and stability of connected systems and devices.

Popular ABB Models

ABB provides a range of industrial automation products for various applications. Below are some of the most widely used models:

ABB SD880: A high-performance power supply ideal for heavy-duty applications requiring large-scale power.
ABB ACS580: A variable frequency drive that optimizes motor control and enhances the overall energy efficiency of automation systems.
ABB IRB 6700: An industrial robot designed to provide precision and flexibility in manufacturing, assembly, and material handling.
ABB PPM500: A power protection system designed to safeguard critical industrial equipment against electrical faults.
ABB MNS 3.0: A modular power distribution system used in large facilities to ensure reliable and efficient power delivery.

Applications

The ABB TB826 Power Supply Module is ideal for a wide range of industrial applications:

Industrial Automation: Provides reliable 24V DC power to PLCs, sensors, and actuators, ensuring smooth and continuous operation of automated control systems.
Manufacturing: Powers automated production lines, assembly machines, packaging systems, and robotics, enabling efficient manufacturing processes.
Material Handling: Perfect for powering conveyors, sorting systems, automated storage/retrieval systems, and other material handling equipment in warehouses, distribution centers, and logistics facilities.
HVAC Systems: Ensures stable and efficient 24V DC power for HVAC systems in industrial and commercial buildings, supporting energy-efficient climate control and operation.
Energy Management: Powers critical monitoring and control systems in energy plants, electrical grids, and renewable energy installations, ensuring consistent operation and management of power networks.

Advantages

High Efficiency: With a 97% efficiency rating at full load, the TB826 minimizes energy loss, reduces heat generation, and helps lower operational costs, providing a more sustainable power solution.
Powerful Output Capacity: The TB826 offers a robust 40A output, making it ideal for powering larger systems that require substantial 24V DC power.
Advanced Protection Features: Equipped with overvoltage, overcurrent, short-circuit, thermal overload, and surge protection, the TB826 helps safeguard both the module and connected systems from electrical damage.
Compact and Durable Design: Despite its high output capacity, the TB826 features a compact design that ensures easy integration into control panels or industrial enclosures, without taking up excessive space.
Wide Input Voltage Range: With an input voltage range of 85-265 VAC, the TB826 is compatible with various global power standards, making it ideal for use in different regions.
DIN Rail Mounting: The module is designed for easy DIN rail mounting, simplifying installation and ensuring secure attachment within industrial control panels.
Long-Term Reliability: Built for harsh industrial environments, the TB826 is engineered for durability and long-lasting performance, minimizing maintenance requirements and system downtime.

Technical FAQs

What is the input voltage range for the ABB TB826?
- The TB826 operates within an input voltage range of 85-265 VAC, which makes it suitable for global use with different power supply standards.
What is the efficiency rating of the TB826?
- The TB826 operates with an impressive efficiency of 97% at full load, reducing energy consumption and minimizing heat output.
What protection features are included with the TB826?
- The TB826 includes comprehensive protection features such as overvoltage, overcurrent, thermal protection, short-circuit protection, and surge protection.
How much current can the TB826 supply?
- The TB826 can supply up to 40A of current at 24V DC, making it ideal for high-power industrial systems and automation applications.
Can the TB826 be used outdoors?
- While the TB826 is designed for indoor use, it can be housed in protective enclosures for outdoor use or in environments with harsh conditions.
What is the operating temperature range for the TB826?
- The TB826 operates within a temperature range of -10°C to 70°C (14°F to 158°F), making it suitable for most industrial environments.
How is the TB826 mounted?
- The TB826 is designed for DIN rail mounting, making it easy to install in industrial control panels, machinery enclosures, or automation systems.
What are the dimensions and weight of the TB826?
- The TB826 weighs 5.0 kg (11.02 lbs) and has dimensions of 210 x 230 x 180 mm (8.27 x 9.06 x 7.09 inches), offering a compact yet powerful power solution.
Is the TB826 suitable for large systems?
- Yes, with its 40A output, the TB826 is ideal for larger, high-power industrial systems that require substantial 24V DC power.
Can the TB826 be integrated with other ABB automation systems?
- Yes, the TB826 is fully compatible with other ABB products, enabling seamless integration into large-scale industrial control systems.
