The ABB TB840 Power Supply Module is a high-capacity, highly reliable 24V DC power supply designed for the most demanding industrial automation and control applications. With an impressive output capacity of up to 50A, the TB840 delivers consistent and stable power for large-scale automation systems, making it ideal for industries where uptime and reliability are paramount. Whether you’re powering PLCs, control systems, sensors, actuators, or other critical equipment, the TB840 ensures your systems operate efficiently and without interruption.

Engineered for performance, the TB840 features advanced protection mechanisms, a robust and compact design, and an easy DIN rail mounting system, making it suitable for use in various industrial environments, including manufacturing, material handling, energy, and HVAC applications. It provides a dependable, energy-efficient solution for both medium and large-scale automation setups that require substantial power to operate complex systems.

Technical Specifications

Specification	Details
Model	TB840 Power Supply Module
Input Voltage	85-265 VAC, 47-63 Hz
Output Voltage	24V DC ±1%
Nominal Output Current	50A
Efficiency	98% (at full load)
Operating Temperature	-10°C to 70°C (14°F to 158°F)
Weight	6.0 kg (13.23 lbs)
Dimensions (W x H x D)	230 x 240 x 200 mm (9.06 x 9.45 x 7.87 inches)
Cooling Type	Forced Air Cooling
Protection Features	Overvoltage, Overcurrent, Overtemperature, Short Circuit, Surge Protection
Mounting Type	DIN Rail Mounting
Certifications	CE, UL, RoHS

Recommended Related Models

To suit various power requirements, here are a few related ABB power supply models:

ABB TB830: Provides 45A output, ideal for high-demand industrial systems that require a high current but slightly less than the TB840.
ABB TB820: A slightly lower capacity option, offering 40A, for medium-sized automation setups and control systems.
ABB DCS 800 Series: A modular and customizable power solution for highly complex automation systems, designed for flexibility and scalability.
ABB SM860: A highly adaptable, scalable power supply module for industrial applications, offering advanced features for power distribution.
ABB PM850: A robust protection module that shields sensitive equipment from electrical faults and power surges, ensuring system integrity.

Popular ABB Models

ABB’s reputation for industrial automation excellence is supported by a broad portfolio of products. Some of the most popular models include:

ABB SD880: A high-performance power supply solution for demanding industrial environments requiring large-scale power.
ABB ACS580: A variable frequency drive (VFD) designed to optimize motor control and enhance system energy efficiency in industrial applications.
ABB IRB 6700: High-precision robots engineered for manufacturing, assembly, and material handling applications, delivering fast and accurate performance.
ABB PPM500: A power protection module that ensures reliable operation by safeguarding equipment from voltage fluctuations, surges, and electrical faults.
ABB MNS 3.0: A modular power distribution system designed to improve flexibility and efficiency in electrical distribution within industrial plants.

Applications

The ABB TB840 Power Supply Module is engineered to meet the high power demands of industrial automation systems across a variety of applications:

Industrial Automation: Powers control systems, PLCs, sensors, and actuators, ensuring smooth operation of complex automation setups.
Manufacturing: Ideal for automated production lines, assembly systems, packaging machines, and robotics, where constant power is critical to maintaining production efficiency.
Material Handling: Provides reliable 24V DC power for conveyors, sorting systems, automated storage/retrieval systems, and other material handling equipment in warehouses and distribution centers.
HVAC Systems: Offers stable power to HVAC systems in commercial and industrial buildings, supporting energy efficiency and climate control.
Energy Management: Perfect for powering monitoring and control systems in power plants, electrical grids, and renewable energy systems, ensuring the stability and efficiency of power management operations.

Advantages

Exceptional Efficiency: The TB840 operates with an impressive 98% efficiency at full load, reducing energy consumption and minimizing heat output, which results in lower operational costs and reduced cooling needs.
High Output Capacity: With a powerful 50A output, the TB840 is perfect for large-scale industrial systems requiring high power for complex processes and automation systems.
Comprehensive Protection Features: Built-in overvoltage, overcurrent, thermal protection, short-circuit protection, and surge protection ensure that the TB840 keeps both the module and your connected systems safe from electrical hazards.
Compact and Robust Design: Despite its high output current, the TB840 is designed to be compact, making it easy to integrate into control panels or industrial enclosures without occupying too much space.
Wide Input Voltage Range: With an input voltage range of 85-265 VAC, the TB840 is adaptable for use in a variety of global power standards, ensuring compatibility with systems around the world.
DIN Rail Mounting: The TB840 is designed for quick and easy DIN rail mounting, which streamlines installation in industrial environments and ensures secure placement within control panels.
Long-Term Reliability: Built for industrial durability, the TB840 delivers reliable performance over extended periods, reducing maintenance requirements and minimizing the risk of downtime.

Technical FAQs

What is the input voltage range for the ABB TB840?
- The TB840 operates within an input voltage range of 85-265 VAC, ensuring compatibility with different power standards worldwide.
What is the efficiency rating of the TB840?
- The TB840 has a high efficiency rating of 98% at full load, minimizing energy consumption and reducing the need for cooling.
What protection features are included with the TB840?
- The TB840 includes overvoltage, overcurrent, thermal overload, short-circuit, and surge protection to safeguard both the module and connected systems.
How much current can the TB840 provide?
- The TB840 can supply up to 50A of 24V DC power, making it ideal for large-scale and high-demand automation systems.
Can the TB840 be used outdoors?
- The TB840 is designed for indoor use, but it can be installed in protective enclosures for use in outdoor or harsh environments.
What is the operating temperature range for the TB840?
- The TB840 operates within a temperature range of -10°C to 70°C (14°F to 158°F), making it suitable for a variety of industrial settings.
How is the TB840 mounted?
- The TB840 is designed for DIN rail mounting, allowing for easy installation and secure attachment in industrial control panels.
What are the dimensions and weight of the TB840?
- The TB840 weighs 6.0 kg (13.23 lbs) and has dimensions of 230 x 240 x 200 mm (9.06 x 9.45 x 7.87 inches), offering a compact yet powerful solution for high-demand applications.
Is the TB840 suitable for large systems?
- Yes, with a 50A output, the TB840 is ideal for larger, high-power systems in industrial automation.
Can the TB840 be integrated with other ABB automation products?
- Yes, the TB840 is fully compatible with other ABB products, making it easy to integrate into complex industrial control systems.
