Siemens 6SN1118-0NJ01-0AA2 Single-Axis Control Loop Module
Siemens 6SN1118-0NJ01-0AA2 Single-Axis Control Loop Module
0.0
Points
Brand:Siemens Item No.:6SN1118-0NJ01-0AA2 Product Origin:Germany Product Dimensions:305 x 51 x 127 mm Product Weight:0.56 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6SN1118-0NJ01-0AA2 is intended to function as part of a complete SIMODRIVE motion-control architecture. Unlike a conventional PLC module, its purpose is directly related to the control of an individual drive axis.
A typical installation can include a higher-level CNC or automation controller, SIMODRIVE control hardware, power modules, motors, feedback devices, and associated communication or option components. The control loop module forms an important part of this architecture by handling the control functions associated with its designated axis.
When replacing a legacy SIMODRIVE module, engineers should avoid selecting components solely by appearance or general product family. Different Siemens control modules can have different axis configurations, feedback interfaces, software requirements, and hardware revisions.
The 6SN1118-0NJ01-0AA2 is therefore best treated as a specific replacement part whose compatibility should be confirmed against the original machine configuration before installation and commissioning.
Technical Specifications
Parameter
Specification
Brand
Siemens
Model
6SN1118-0NJ01-0AA2
Product Family
SIMODRIVE 611
Product Type
Single-Axis Control Loop Module
Control Type
Motion / Drive Control
Number of Axes
1
Application
CNC, machine tools and industrial drive systems
System Integration
SIMODRIVE drive system
Dimensions
305 × 51 × 127 mm
Weight
0.56 kg (1.23 lb)
Product Status
Legacy / discontinued
Recommended Related Models
Model
Product Type
Relationship
Siemens 6SN1118-0NJ01-0AA0
Single-Axis Control Unit
Earlier related version
Siemens 6SN1118-0NJ01-0AA1
Single-Axis Control Loop Module
Related control-loop version
Siemens 6SN1118-0NH11-0AA1
Dual-Axis Control Loop Module
Related SIMODRIVE HRS control module
Siemens 6SN1118-0NH11-0AA0
Dual-Axis Control Unit
Related earlier control generation
Popular Related Models
Model
Product Type
Siemens 6SN1118-0NJ01-0AA0
Single-Axis Control Unit
Siemens 6SN1118-0NJ01-0AA1
Single-Axis Control Loop Module
Siemens 6SN1118-0NH11-0AA1
Dual-Axis Control Loop Module
Siemens 6SN1118-0NH11-0AA0
Dual-Axis Control Unit
Siemens 6SN1114-0NB01-0AA0
PROFIBUS-DP Motion Control Option Module
For replacement and repair projects, verify the complete Siemens MLFB, control generation, feedback configuration, software version, memory configuration, and associated SIMODRIVE power components before installation.
Applications in CNC and Industrial Motion Systems
The Siemens 6SN1118-0NJ01-0AA2 is designed for applications where an individual drive axis requires dedicated closed-loop control. It works as part of the larger SIMODRIVE system, coordinating the control functions of the associated drive and motor according to the machine configuration.
Typical applications include CNC machine tools, machining centers, production machinery, automated positioning equipment, and other industrial systems that depend on Siemens SIMODRIVE technology.
For maintenance applications, the module can be particularly valuable when an existing machine still relies on its original SIMODRIVE architecture. Replacing a defective control-loop module with the correct matching component can help restore an individual axis without requiring an unnecessary replacement of the complete drive system.
Important Advantages for Drive System Maintenance
Dedicated single-axis control
The 6SN1118-0NJ01-0AA2 is designed specifically for single-axis applications, making it appropriate for systems where each controlled axis requires dedicated drive control hardware.
SIMODRIVE system integration
The module is designed to operate as part of a Siemens SIMODRIVE drive configuration, allowing it to work with the corresponding power, motor, feedback, and control components.
Closed-loop motion control
As a control loop module, it forms part of the feedback and regulation path between the machine controller and associated drive system.
Compact installation format
With a 51 mm module width, the control unit is designed for integration into the compact SIMODRIVE drive architecture commonly found in industrial machine installations.
Useful for legacy equipment
The 6SN1118-0NJ01-0AA2 is particularly relevant to service organizations and machine owners maintaining older Siemens CNC and industrial automation equipment.
Efficient replacement strategy
When the existing drive system is otherwise functional, replacing only the failed control component can be more practical than redesigning the entire motion-control system.
Suitable for spare-parts programs
Keeping correctly identified SIMODRIVE control modules available as maintenance spares can reduce troubleshooting and equipment-recovery time when a control-axis fault occurs.
Technical FAQs
1. What is the Siemens 6SN1118-0NJ01-0AA2?
It is a Siemens SIMODRIVE single-axis control loop module designed for industrial motion-control applications.
2. How many axes does the 6SN1118-0NJ01-0AA2 control?
The module is designed for one controlled axis.
3. Is the module a standalone PLC?
No. It is a drive control-loop component and must operate within a compatible SIMODRIVE system.
4. What applications commonly use this type of module?
Typical applications include CNC machine tools, machining equipment, production machinery, positioning systems, and legacy Siemens industrial drive installations.
5. What should be checked before replacing the module?
The complete Siemens MLFB, SIMODRIVE drive configuration, control generation, feedback system, software, memory configuration, and machine-specific parameters should be checked.
6. Can the 6SN1118-0NJ01-0AA2 be installed in any SIMODRIVE 611 system?
No. Compatibility depends on the specific SIMODRIVE hardware generation and the complete machine configuration. Physical similarity alone does not guarantee compatibility.
7. What can cause a newly installed control module to fail commissioning?
Incorrect part selection, incompatible software, incorrect parameters, feedback problems, memory-data issues, communication faults, or problems elsewhere in the drive system can prevent successful commissioning.
8. Should machine parameters be backed up before replacing the control module?
Yes. Machine-specific parameters and configuration data should be backed up whenever possible before replacing control hardware.
9. Can the module be used for machine-tool applications?
Yes. SIMODRIVE control-loop hardware is associated with industrial CNC and machine-tool drive applications, provided that the complete system configuration is compatible.
10. What is the most important information when sourcing a replacement?
The complete Siemens order number 6SN1118-0NJ01-0AA2 should be matched carefully. The control generation, feedback arrangement, software requirements, and associated drive components should also be verified.
