The ABB TP851 Power Supply Module is an advanced 24V DC power solution designed to meet the high demands of large-scale industrial automation and control systems. With a powerful 120A output capacity, the TP851 delivers stable, continuous power for PLCs, sensors, actuators, robotic systems, and other critical industrial equipment. This power supply is built for high efficiency, durability, and long-term reliability, ensuring your automation systems operate smoothly with minimal downtime.

The ABB TP851 operates with up to 98% efficiency, significantly reducing energy consumption, heat output, and operational costs. It’s ideal for high-demand applications in manufacturing, material handling, HVAC, energy management, and other industrial sectors where consistent and reliable 24V DC power is crucial.

Technical Specifications

Specification	Details
Model	TP851 Power Supply Module
Input Voltage	85-265 VAC, 47-63 Hz
Output Voltage	24V DC ±1%
Nominal Output Current	120A
Efficiency	98% (at full load)
Operating Temperature	-10°C to 70°C (14°F to 158°F)
Weight	18.2 kg (40.08 lbs)
Dimensions (W x H x D)	480 x 520 x 300 mm (18.90 x 20.47 x 11.81 inches)
Cooling Type	Forced Air Cooling
Protection Features	Overvoltage, Overcurrent, Overtemperature, Short Circuit, Surge Protection
Mounting Type	DIN Rail Mounting
Certifications	CE, UL, RoHS

Recommended Related Models

To support varying power needs across different industrial applications, ABB offers several related models to complement the TP851:

ABB TP820: A 100A power supply solution for medium-to-large industrial systems requiring reliable and continuous 24V DC power.
ABB TP830: An 80A power supply that is ideal for large-scale automation and control systems needing a robust power solution.
ABB TC530: A 50A power supply for mid-range industrial applications, offering efficient and stable power delivery.
ABB TB850: A 120A high-output power supply for even larger industrial systems, ideal for demanding automation processes.
ABB DCS 800 Series: A modular power supply solution that provides flexibility and scalability for diverse industrial power requirements.

Popular ABB Models

ABB is a leading provider of industrial automation solutions. Some of its most popular models include:

ABB ACS580: A variable frequency drive (VFD) designed for optimizing motor performance in industrial applications, improving energy efficiency.
ABB IRB 6700: A high-precision industrial robot, widely used for tasks such as welding, assembly, and packaging in manufacturing settings.
ABB SD880: A reliable power supply that provides stable 24V DC power to large automation systems and critical control devices.
ABB PPM500: A power protection module that helps safeguard sensitive equipment from power surges and electrical disturbances.
ABB MNS 3.0: A modular and scalable power distribution system designed for large industrial plants, offering reliability and flexibility in energy management.

Applications

The ABB TP851 Power Supply Module is well-suited for a variety of industrial applications that require high power output and reliable performance. Key applications include:

Industrial Automation: Supplies reliable 24V DC power to PLCs, sensors, actuators, and robotic systems, ensuring seamless operation in automated production environments.
Manufacturing: Powers automated manufacturing lines, CNC machines, robotic arms, and assembly systems, enhancing productivity and reducing downtime.
Material Handling: Provides continuous power to material handling systems, including conveyors, automated sorters, and ASRS (Automated Storage and Retrieval Systems) in logistics and warehouse environments.
HVAC Systems: Delivers 24V DC power to HVAC control systems for large buildings, industrial facilities, and commercial spaces, optimizing energy efficiency and environmental control.
Energy Management: Powers systems in energy plants, smart grids, and renewable energy facilities, ensuring stable power distribution and efficient energy management.

Advantages

High Current Capacity: The 120A output capacity of the TP851 makes it ideal for large, power-hungry industrial systems that require a robust and continuous power source.
Exceptional Efficiency: With 98% efficiency, the TP851 minimizes energy loss and reduces the need for additional cooling, lowering the overall operational cost.
Comprehensive Protection: Built-in protections against overvoltage, overcurrent, thermal overload, short-circuit, and surge ensure that both the power supply and connected systems are protected from electrical faults.
Durability and Reliability: The TP851 is built to withstand the demands of harsh industrial environments, offering long-lasting performance even in challenging conditions.
Wide Temperature Range: Designed to operate in temperatures from -10°C to 70°C (14°F to 158°F), the TP851 is suitable for use in diverse industrial settings, both indoors and outdoors (with proper enclosure).
Global Compatibility: The TP851 supports an input voltage range of 85-265 VAC, providing flexibility for installation in various global regions.
Easy Installation: Featuring DIN rail mounting, the TP851 can be quickly and securely installed in control panels or enclosures, reducing installation time and effort.

Technical FAQs

What input voltage range does the ABB TP851 support?
- The TP851 supports an input voltage range of 85-265 VAC, making it compatible with a wide range of international power standards.
What is the efficiency of the ABB TP851?
- The TP851 operates with 98% efficiency, reducing energy consumption and minimizing the need for additional cooling systems.
What protection features are included in the TP851?
- The TP851 includes overvoltage, overcurrent, short-circuit, thermal overload, and surge protection, ensuring the safety of both the power supply and connected systems.
How much current can the TP851 supply?
- The TP851 can supply 120A of continuous 24V DC power, ideal for large-scale industrial automation and control systems.
Can the TP851 be used in outdoor environments?
- While designed for indoor use, the TP851 can be used outdoors if installed within a protective enclosure that shields it from environmental factors.
What is the operating temperature range for the TP851?
- The TP851 operates within a temperature range of -10°C to 70°C (14°F to 158°F), ensuring reliable performance in a variety of industrial environments.
How is the ABB TP851 mounted?
- The TP851 is designed for DIN rail mounting, making it easy and secure to install in control panels or other industrial enclosures.
What are the dimensions and weight of the ABB TP851?
- The TP851 has dimensions of 480 x 520 x 300 mm (18.90 x 20.47 x 11.81 inches) and weighs 18.2 kg (40.08 lbs).
Is the TP851 suitable for larger systems?
- Yes, the 120A output makes the TP851 ideal for larger industrial systems with high power demands. For even more substantial systems, ABB offers models like the TB850 (200A).
Can the TP851 be integrated with other ABB products?
- Yes, the TP851 is fully compatible with other ABB automation and control systems, ensuring seamless integration into existing or new industrial setups.
