Brand:Ingersoll Rand Item No.: 47579357001 15472392 Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47579357001 15472392 configuration combines an 8,000-hour water-cooled maintenance service reference with the specified 15472392 cooler sealing gasket. The primary maintenance reference is associated with compatible IRN 55–75 kW oil-free water-cooled compressor systems.
15472392 is separately identified as a gasket for oil cooler assembly 39796677 in applicable Sierra SL/SM/SH compressor configurations. It is intended to seal the relevant oil cooler flange and support retention of circulating lubricant at the serviced connection.
Because the two references have different documented application contexts, this configuration requires careful compatibility verification. The compressor model, serial number, installed cooler assembly, and current parts documentation should be checked before ordering or installing 15472392 on an IRN 55–75 kW oil-free system.
Technical Specifications
Specification
Details
Manufacturer
Ingersoll Rand
Configuration
47579357001 15472392
Product Type
Oil Cooler Gasket Maintenance Configuration
Primary Service Reference
47579357001
Service Interval
8,000 hours
Primary Compressor Application
IRN 55–75 kW oil-free, water-cooled systems
Specified Component
15472392
Component Type
Oil cooler sealing gasket
Documented Cooler Assembly
39796677
Documented Platform for 15472392
Sierra SL/SM/SH and applicable related configurations
Sealing Location
Oil cooler core-to-cover flange
Sealing Function
Retention of circulating cooling oil at the flange joint
Installation Interface
Cooler flange; assembly-specific
Dimensions
Not reliably specified; exact gasket profile should be matched to the cooler assembly
Weight
Not reliably specified
Material
Configuration-specific; verify against current parts documentation
Application
Maintenance configuration requiring exact compressor and cooler verification
Service Use
Scheduled maintenance and oil cooler overhaul
Compatibility Check
Compressor model, serial number, cooler assembly, flange profile, and current parts documentation should be verified
Recommended Companion Models
Model
Application Context
Ingersoll Rand IRN 55
Compatible 55 kW oil-free compressor platform for the 47579357001 service family, subject to configuration verification
Ingersoll Rand IRN 75
Compatible 75 kW oil-free compressor platform for the 47579357001 service family, subject to configuration verification
Ingersoll Rand IRN 55–75 kW Water-Cooled
Primary platform associated with the 47579357001 8,000-hour water-cooled maintenance reference
Ingersoll Rand Sierra SL/SM/SH
Applicable compressor family associated with the documented 15472392 oil cooler gasket application
Frequently Selected Alternatives
Reference
Typical Function
47579355001
8,000-hour water-cooled maintenance kit for compatible IRN 37–45 kW oil-free systems
47579614001
8,000-hour air-cooled maintenance kit for compatible IRN 37–45 kW oil-free systems
15472509
Ingersoll Rand gasket for an applicable cooler assembly in the M200–250 service family
47588740001
Water/oil cooler gasket for applicable Ingersoll Rand cooler service configurations
Where It Excels in Industrial Use
• 8,000-hour water-cooled servicing — 47579357001 is identified as an 8,000-hour water-cooled maintenance kit for compatible IRN 55–75 kW oil-free compressor systems, supporting major scheduled maintenance.
• Oil cooler service work — 15472392 is an Ingersoll Rand sealing gasket associated with the oil cooler flange of applicable Sierra compressor configurations, making it relevant to cooler overhaul and sealing work where the reference is specified.
• Planned cooler maintenance — The configuration can be used when a scheduled service event requires the maintenance kit to be managed together with a specified cooler sealing component.
• Leak-prevention applications — A correctly matched cooler flange gasket helps maintain sealing integrity at the mating surfaces and reduces the risk of lubricant leakage from the serviced connection.
• Configuration-controlled maintenance — Because the two references originate from potentially different compressor applications, exact model and serial-number verification is particularly important before treating them as an installed configuration.
Key Strengths at a Glance
• 8,000-hour maintenance reference — 47579357001 is associated with water-cooled IRN 55–75 kW oil-free compressor maintenance.
• Defined cooler gasket — 15472392 is listed as a gasket for oil cooler assembly 39796677 in applicable Sierra SL/SM/SH compressor configurations.
• Flange sealing support — The gasket provides sealing between the applicable oil cooler mating surfaces during cooler service.
• Maintenance planning convenience — The paired references identify both the scheduled service package and the requested cooler sealing component for maintenance preparation.
• Compatibility must be confirmed — 15472392 should not be assumed to fit an IRN 55–75 kW oil-free system simply because it is paired with the 8,000-hour maintenance reference; the exact compressor application should be checked first.
Technical FAQs
1. What is the Ingersoll Rand 47579357001 15472392 configuration used for? It is a requested maintenance configuration combining the 8,000-hour water-cooled service reference 47579357001 with the specified 15472392 oil cooler sealing gasket.
2. What is 47579357001? 47579357001 is identified as an 8,000-hour water-cooled maintenance kit for compatible IRN 55–75 kW oil-free compressor systems.
3. What is the function of 15472392? 15472392 is identified as a sealing gasket for oil cooler assembly 39796677 in applicable Sierra SL/SM/SH compressor configurations.
4. Where is 15472392 installed? The gasket is associated with the flange connection between the applicable oil cooler core and cover, where it provides a sealing interface for the cooler circuit.
5. Is 15472392 automatically compatible with IRN 55–75 kW oil-free compressors? No. Its documented application is associated with specific Sierra oil cooler configurations, so compatibility with an IRN 55–75 kW oil-free compressor must be confirmed against the exact machine documentation.
6. Why should an oil cooler gasket be replaced during cooler service? A gasket that has been compressed or disturbed during disassembly may not reliably restore the original sealing condition, so replacement during applicable cooler overhaul helps maintain joint integrity.
7. What should be checked before installing 15472392? The oil cooler assembly reference, flange profile, compressor model and serial number, mating surfaces, and applicable Ingersoll Rand parts documentation should all be verified.
8. What can indicate a failed cooler flange gasket? Possible indications include visible lubricant seepage around the cooler flange, contamination near the joint, or abnormal cooler-system behavior associated with loss of sealing integrity.
9. Does replacing 15472392 complete the 8,000-hour maintenance service? No. The gasket is only the specified component in this requested configuration; the complete maintenance scope is determined by the applicable compressor service schedule.
10. Can 15472392 be reused after cooler disassembly? Reuse should not be assumed. The gasket should normally be replaced when required by the applicable cooler service procedure, particularly when removal has compromised its original sealing condition.
