Ingersoll Rand 47579353001 / 39911615 Heavy-Duty 8,000-Hour Water-Cooled Maintenance Kit with Oil Filter Element
Ingersoll Rand 47579353001 / 39911615 Heavy-Duty 8,000-Hour Water-Cooled Maintenance Kit with Oil Filter Element
0.0
Points
Brand:Ingersoll Rand Item No.:47579353001 39911615 Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.08 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47579353001 / 39911615 configuration combines an 8,000-hour water-cooled maintenance kit with an oil filter element for applicable compressor service applications.
47579353001 is designated for the Sierra 90-150 water-cooled compressor range. 39911615 is an oil filter element used on applicable Ingersoll Rand rotary screw compressors and is documented in several EP and ESP series applications.
The 39911615 filter is approximately 223.6 mm high and 97 mm in outside diameter, with a 1-3/8-inch, 12-thread connection. Its filtration function helps maintain cleaner compressor oil and supports reliable oil circulation through the compression system.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Primary Part Number
47579353001
Associated Part Number
39911615
Maintenance Interval
8,000 hours
Kit Type
Water-cooled maintenance kit
Applicable Compressor Range
Sierra 90-150
Component Type
Oil filter element
Filter Application
Compressor oil filtration
Approx. Filter Height
223.6 mm
Approx. Filter Outside Diameter
97 mm
Connection
1-3/8-inch, 12-thread UNF
Approx. Net Weight
1.21 kg
Filtration Media
Inorganic microfibers, according to published filter specifications
Function
Removal of particles and contaminants from compressor oil
Packaging
Configuration-dependent
Recommended Companion Models
Model
Product Name
47579352001
8,000-Hour Water-Cooled Maintenance Kit – Sierra 37-75
47579354001
8,000-Hour Water-Cooled Maintenance Kit – Sierra 200-300
8,000-Hour Air-Cooled Maintenance Package – Sierra 90-150
47579186001
4,000-Hour Maintenance Package – Sierra 90-150
47578984001
2,000-Hour Maintenance Package – Sierra 90-150
47579627001
Water-Cooled Hose Package – Sierra 90-150
Where It Fits in Industrial Applications
• Designed for scheduled maintenance of Ingersoll Rand Sierra 90-150 water-cooled compressor systems.
• Part number 47579353001 identifies the 8,000-hour water-cooled maintenance kit for the Sierra 90-150 range.
• Part number 39911615 identifies an Ingersoll Rand oil filter element for applicable rotary screw compressor applications.
• The oil filter removes particles and contaminants from compressor oil before the oil returns to the compression system.
• This combined configuration is suitable for planned maintenance where the scheduled service kit and replacement oil filtration component are required.
• Combines the water-cooled maintenance kit with a dedicated oil filter element.
• Helps maintain clean compressor oil and protect oil-circulation components from particulate contamination.
• The 39911615 oil filter is associated with applications requiring high-pressure, high-efficiency compressor filtration.
• Provides a practical configuration for organized compressor servicing and spare-parts management.
Technical FAQs
1. What is Ingersoll Rand 47579353001?
47579353001 is an 8,000-hour water-cooled maintenance kit associated with Ingersoll Rand Sierra 90-150 compressor systems.
2. What is Ingersoll Rand 39911615?
39911615 is an Ingersoll Rand oil filter element used in applicable rotary screw compressor applications.
3. What is the function of the 39911615 oil filter?
The oil filter removes particles and contaminants from compressor oil before the oil is returned to the compression process.
4. Which compressor applications use 39911615?
The part is documented for several Ingersoll Rand rotary screw compressor applications, including EP and ESP series equipment. Compatibility should be confirmed against the specific compressor model.
5. What is the approximate size of 39911615?
Published specifications identify the filter at approximately 223.6 mm in overall height and 97 mm in outside diameter, with a 1-3/8-inch, 12-thread UNF connection.
6. What is the approximate weight of 39911615?
A published filter specification lists a net weight of approximately 1.21 kg.
7. How often is the 39911615 oil filter normally replaced?
Some Ingersoll Rand service references recommend oil filter replacement at approximately 2,000 operating hours or annually for applicable compressor models. The actual interval should follow the maintenance schedule for the specific machine.
8. Is 39911615 the same as 39856844?
39911615 is documented as the replacement for 39856844 in applicable applications where the parts manual identifies 39856844 as the oil or coolant filter.
9. Is this configuration intended for preventive maintenance?
Yes. The 8,000-hour designation of 47579353001 indicates its role in scheduled preventive maintenance, while 39911615 provides the associated oil filtration component.
10. Should 47579353001 and 39911615 be treated as one product configuration?
Yes. For this product listing, the two supplied part numbers are treated as one complete configuration, combining the 8,000-hour water-cooled maintenance kit with the associated oil filter element.
