Ingersoll Rand 47607047001 / 24900458 Coolant Filter Maintenance Module

Where It Fits in Industrial Applications

• Designed for applicable Ingersoll Rand rotary screw compressor maintenance applications.

• 24900458 is identified as a spin-on coolant filter element for compatible compressor systems.

• Suitable for compressor lubrication and coolant circuits where the specified filter is required.

• Applicable parts documentation identifies 24900458 for compressor platforms including RS90ie, RS110ie, RS132i, RS132ie, RS160i, and RS160ie.

• Intended for scheduled filter replacement as part of routine compressor maintenance.

Key Strengths at a Glance

• Coolant filtration: 24900458 is designed to remove particulate contamination from the compressor coolant circuit.

• Maintenance-oriented configuration: Combines 47607047001 with the specified 24900458 filter.

• Spin-on construction: The filter is identified as a spin-on coolant filter, simplifying replacement during scheduled service.

• Defined physical format: Published specifications identify an approximate overall height of 364 mm and outside diameter of about 118 mm.

• Established compressor application: Used across applicable Ingersoll Rand compressor configurations, including RS90ie through RS160ie models.

Technical FAQs

1. What is Ingersoll Rand 47607047001?

47607047001 is identified as a scheduled maintenance kit for applicable Ingersoll Rand compressor configurations.

2. What is Ingersoll Rand 24900458?

24900458 is a spin-on coolant filter element used in applicable Ingersoll Rand compressed-air equipment and is also listed by some suppliers as an oil filter.

3. Are 47607047001 and 24900458 one product configuration?

For this product listing, the two supplied part numbers are treated as one complete maintenance configuration, with 47607047001 identifying the maintenance kit and 24900458 identifying the associated coolant filter.

4. What does the 24900458 filter remove?

The filter is intended to remove particulate contamination and degradation products from the compressor coolant or lubricant circulation system.

5. Which compressor models are associated with 24900458?

Parts references identify 24900458 for applicable RS90ie, RS110ie, RS132i, RS132ie, RS160i, and RS160ie configurations, with additional applications depending on equipment version.

6. Is 24900458 an oil filter or a coolant filter?

It is described as a coolant filter in Ingersoll Rand parts references, while several suppliers also categorize it as an oil filter because it filters the compressor lubricant/coolant circuit.

7. What are the approximate dimensions of 24900458?

Published supplier specifications list an overall height of approximately 364 mm and a largest outside diameter of approximately 118 mm.

8. What is the approximate weight of the 24900458 filter?

A supplier listing reports a weight of approximately 5.6 lb, or about 2.54 kg.

9. When should 24900458 normally be replaced?

For applicable RS90ie through RS160ie configurations, published service information identifies replacement at approximately 4,000 operating hours or six months, subject to the machine-specific maintenance schedule.

10. Should the compressor model and serial number be checked before ordering?

Yes. The compressor model, serial number, existing filter part number, and applicable maintenance documentation should be verified before installation.
