The ABB AO930S Analog Output Module is a versatile and high-performance solution designed for precise control of analog signals in industrial automation systems. Integrated with the AC 800M control platform, this module provides 8 output channels, offering high-resolution voltage and current outputs for controlling a wide range of field devices, such as actuators, valves, and motor drives. Whether it's for power generation, chemical processing, water treatment, or manufacturing, the AO930S ensures accurate and reliable analog output control, optimizing industrial processes and improving operational efficiency.

The AO930S is engineered for flexibility and reliability, making it an ideal choice for demanding industrial environments where performance, accuracy, and responsiveness are crucial. This module excels in scenarios where precise feedback and fine control over processes are essential.

Technical Specifications

Feature	Specification
Module Type	Analog Output Module (AO930S)
Output Channels	8 Analog Output Channels
Signal Type	Voltage (0-10V), Current (4-20mA)
Resolution	16-bit
Power Supply	24 VDC
Mounting	DIN Rail Mount
Operating Temperature	-25°C to 70°C
Weight	0.80 kg
Dimensions	160 mm (W) x 120 mm (H) x 90 mm (D)
Accuracy	±0.1% Full Scale (for analog outputs)
Response Time	< 1 ms
Communication Interface	Integrated with AC 800M Controller

Recommended Related Models

ABB AI840A – A 16-channel analog input module, ideal for applications requiring high-channel density and fast data acquisition.
ABB AO810 – A general-purpose analog output module for controlling devices based on real-time data and system outputs.
ABB DI810 – Digital input module for precise monitoring of discrete signals in industrial automation systems.

Popular ABB Models

ABB AC 800M Controller – The main control unit for ABB's industrial automation systems, which integrates seamlessly with I/O modules such as the AO930S.
ABB AI830A – A highly accurate 16-channel analog input module, providing high resolution and fast response for critical industrial applications.
ABB DO820 – A digital output module designed for controlling field devices such as actuators, solenoids, and relays.
ABB AO830 – Analog output module for controlling external devices with precise voltage or current output signals, ideal for industrial automation.

Applications

The ABB AO930S Analog Output Module is ideal for a variety of industrial applications requiring accurate control over analog signals. Some of the key use cases include:

Power Generation – Control and monitor actuators, valves, and other critical components in power plants, ensuring efficient energy production and plant performance.
Chemical Processing – Adjust chemical flows, temperature, and pressure in reactors, distillation columns, and mixers, ensuring safe and efficient chemical processes.
Water Treatment – Control dosing systems, pumps, and valves, ensuring water quality standards are met in both drinking water and wastewater treatment facilities.
Manufacturing – Maintain consistent quality control by regulating temperature, pressure, and other vital process parameters in production lines and manufacturing systems.

Advantages

High Output Precision: With 16-bit resolution and an accuracy of ±0.1% full scale, the AO930S delivers precise and reliable control over voltage and current outputs.
Dual Output Capability: The module supports both voltage (0-10V) and current (4-20mA) output signals, making it versatile and compatible with a wide range of industrial equipment.
Wide Operating Temperature Range: The AO930S is designed to function in temperatures ranging from -25°C to 70°C, ensuring reliable performance in both mild and harsh industrial environments.
Fast Response Time: With a response time of less than 1 ms, the AO930S ensures quick data processing, making it ideal for real-time control in critical applications.
Compact Design: The module is DIN rail-mountable, offering easy installation and efficient space utilization in control panels.
Reliable Communication: The AO930S integrates seamlessly with the AC 800M Controller, enabling stable communication and effective control in complex automation systems.

Technical FAQs

What types of signals can the AO930S module output?
- The AO930S can output both voltage (0-10V) and current (4-20mA) signals, offering compatibility with various field devices such as actuators, valves, and controllers.
How many output channels does the AO930S provide?
- The AO930S provides 8 analog output channels, allowing for simultaneous control of multiple devices in complex systems.
What is the operating temperature range of the AO930S?
- The AO930S operates within a temperature range of -25°C to 70°C, making it suitable for both standard and extreme industrial environments.
What is the accuracy of the AO930S module?
- The AO930S has an accuracy of ±0.1% full scale for analog outputs, ensuring precise control over industrial processes.
How is the AO930S mounted?
- The module is designed for DIN rail mounting, providing easy installation and saving space in industrial control panels.
Can the AO930S be used in hazardous locations?
- The AO930S is intended for non-hazardous environments. For hazardous areas, ABB offers other I/O modules with proper certifications for such conditions.
What is the response time of the AO930S module?
- The AO930S features a response time of less than 1 ms, ensuring fast data processing and real-time feedback for critical control tasks.
What power supply does the AO930S require?
- The AO930S operates with a 24 VDC power supply, providing consistent and stable performance for control applications.
What communication interface does the AO930S use?
- The AO930S integrates seamlessly with the AC 800M Controller, allowing for smooth and reliable communication within industrial automation systems.
Which industries benefit the most from the AO930S module?
- The AO930S is most beneficial in industries like power generation, chemical processing, water treatment, and manufacturing, where precise control of field devices is critical to the overall system performance.
