Siemens 6AG1732-0AA00-7AA0 SIPLUS PS DC/DC Power Supply Module
Siemens 6AG1732-0AA00-7AA0 SIPLUS PS DC/DC Power Supply Module
0.0
Points
Brand:Siemens Item No.: 6AG1732-0AA00-7AA0 Product Origin: Germany Product Dimensions:109 × 64 × 58 mm Product Weight:0.696 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1732-0AA00-7AA0 is a SIPLUS PS DC/DC stabilized power supply based on the SITOP Power 6EP1732-0AA00. It accepts a 48 / 60 / 110 V DC input and provides a regulated 24 V DC output rated at 2 A.
The module provides approximately 48 W of output power, with an adjustable output range of 23.5 to 26.5 V DC. It supports parallel operation of up to two units for enhanced performance and mounts directly on an EN 60715 35 × 15 DIN rail. The SIPLUS version incorporates conformal coating for demanding industrial applications.
Technical Specifications
Parameter
Specification
Brand
Siemens
Order Number
6AG1732-0AA00-7AA0
Product Type
SIPLUS PS DC/DC Stabilized Power Supply
Base Model
6EP1732-0AA00
Input Type
DC
Nominal Input Voltage
48 / 60 / 110 V DC
Operating Input Range
Approx. 38 to 121 V DC
Input Ratio
3:1
Output Type
Regulated, isolated DC voltage
Rated Output Voltage
24 V DC
Output Adjustment Range
23.5 to 26.5 V DC
Rated Output Current
2 A
Maximum Output Power
Approx. 48 W
Static Output Tolerance
Approx. ±1%
Static Mains Compensation
Approx. 0.1%
Static Load Regulation
Approx. 0.4%
Maximum Residual Ripple
100 mV peak-to-peak
Maximum Spikes
300 mV peak-to-peak
Typical Efficiency
Approx. 84%
Typical Power Loss
Approx. 9 W at rated output
Parallel Operation
Up to 2 units
Status Indication
Green LED for 24 V OK
Mounting
EN 60715 35 × 15 DIN rail
Conformal Coating
Yes
Operating Temperature
0 °C to +70 °C
Dimensions
Not reliably published as a fixed value in the available Siemens product data
Net Weight
Approx. 0.696 kg
Recommended Companion Models
Model
Product Name
6EP1732-0AA00
Siemens SITOP Power DC/DC 24 V/2 A Power Supply
6AG1931-2BA00-3AA0
Siemens SIPLUS PS 24 V/0.375 A DC/DC Power Supply
6AG1437-3BA10-7AA0
Siemens SIPLUS PS PSU8200 Power Supply
6AG1505-0RA00-7AB0
Siemens SIPLUS S7-1500 PS 60 W Power Supply
Frequently Selected Alternatives
Model
Product Name
6EP1732-0AA00
Siemens SITOP Power 24 V/2 A DC/DC Power Supply
6AG1931-2BA00-3AA0
Siemens SIPLUS PS 24 V/0.375 A DC/DC Power Supply
6AG1436-2BA10-7AA0
Siemens SIPLUS PSU300S 20 A Power Supply
6AG1505-0KA00-7AB0
Siemens SIPLUS S7-1500 PS 25 W 24 V DC Power Supply
Where It Fits in Industrial Applications
• Designed for industrial automation systems requiring a regulated 24 V DC control power supply from higher-voltage DC sources.
• 6AG1732-0AA00-7AA0 is a Siemens SIPLUS PS DC/DC stabilized power supply based on 6EP1732-0AA00.
• Converts a 48 / 60 / 110 V DC input supply into a regulated 24 V DC output suitable for compatible automation equipment.
• The conformal-coated SIPLUS construction is intended for demanding industrial environments.
Key Strengths at a Glance
• Provides a regulated 24 V DC output at up to 2 A, delivering up to approximately 48 W of output power.
• Accepts a wide DC input range of 48 to 110 V DC, with an operating input range of approximately 38 to 121 V DC.
• Provides galvanically isolated and controlled DC output voltage for compatible control circuits.
• Supports DIN-rail mounting on EN 60715 35 × 15 rails.
• Includes adjustable output voltage from 23.5 to 26.5 V DC and a front status indication for 24 V output availability.
Technical FAQs
1. What is Siemens 6AG1732-0AA00-7AA0?
6AG1732-0AA00-7AA0 is a Siemens SIPLUS PS DC/DC stabilized power supply based on 6EP1732-0AA00, providing 24 V DC at up to 2 A.
2. What is the input voltage range?
The nominal DC input supply is 48 to 110 V DC, while the specified operating input range is approximately 38 to 121 V DC.
3. What output voltage does the power supply provide?
The nominal output voltage is 24 V DC, with an adjustable range of approximately 23.5 to 26.5 V DC.
4. What is the maximum output current?
The rated output current is 2 A, corresponding to approximately 48 W of available output power.
5. Is the output voltage regulated?
Yes. The unit provides a stabilized and isolated DC output, with static total output-voltage tolerance specified at approximately ±1%.
6. Can the output voltage be adjusted?
Yes. The output voltage can be adjusted between approximately 23.5 and 26.5 V DC using the integrated potentiometer.
7. Can multiple units be connected in parallel?
Yes. Up to two units can be connected in parallel for enhanced performance, subject to the applicable Siemens installation requirements.
8. How is the power supply mounted?
The module is designed to snap onto an EN 60715 35 × 15 DIN rail.
9. What environmental features does the SIPLUS version provide?
The SIPLUS version uses conformal coating and is specified for an operating temperature range of 0 °C to +70 °C under the applicable product conditions.
10. What should be verified before replacing this power supply?
The input DC voltage, required 24 V load current, output adjustment requirements, DIN-rail arrangement, wiring, and compatibility with the existing SITOP/SIPLUS power architecture should be verified before installation.
