Siemens 6AG1800-3BA00-7AA0 SIPLUS SINAUT ST7 TIM 3V-IE Communication Module
Siemens 6AG1800-3BA00-7AA0 SIPLUS SINAUT ST7 TIM 3V-IE Communication Module
0.0
Points
Brand:Siemens Item No.: 6AG1800-3BA00-7AA0 Product Origin: Germany Product Dimensions:40 mm ×125 mm×120 mm Product Weight:0.20 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1800-3BA00-7AA0 is a SIPLUS SINAUT ST7 TIM 3V-IE communication module based on the 6NH7800-3BA00. It is designed for SINAUT communication with SIMATIC S7-300 and C7 systems, combining conventional RS-232 WAN communication with IP-based communication through an Industrial Ethernet interface.
The module provides one 9-pin Sub-D RS-232 interface and one RJ45 Ethernet interface. Industrial Ethernet communication operates from 10 to 100 Mbit/s, while the RS-232 interface supports 50 to 38,400 bit/s. The module operates from 24 V DC and is designed for demanding industrial environments with conformal coating and an operating temperature range of -25 °C to +70 °C.
Technical Specifications
Parameter
Specification
Brand
Siemens
Order Number
6AG1800-3BA00-7AA0
Product Type
SIPLUS SINAUT ST7 TIM 3V-IE Communication Module
Base Model
6NH7800-3BA00
Application
SINAUT telecontrol communication
Compatible Controller
SIMATIC S7-300 and C7
Industrial Ethernet Interfaces
1
Industrial Ethernet Connector
RJ45
Industrial Ethernet Transmission Rate
10 to 100 Mbit/s
RS-232 Interfaces
1
RS-232 Connector
9-pin Sub-D
RS-232 Transmission Rate
50 to 38,400 bit/s
Supply Voltage
24 V DC
Permissible Supply Range
20.4 to 28.8 V DC
Maximum Current Consumption
0.2 A
Typical Power Loss
5.8 W
C-PLUG
Not provided
Backup Battery
Not required
Mounting
S7-300 rail / compact module format
Module Format
S7-300 single-width compact module
Front Protection
IP20
Operating Temperature
-25 °C to +70 °C
Storage Temperature
-40 °C to +70 °C
Transport Temperature
-40 °C to +70 °C
Maximum Installation Altitude
5,000 m
Conformal Coating
Yes
Width
40 mm
Height
125 mm
Depth
120 mm
Net Weight
Approx. 0.20 kg
Recommended Companion Models
Model
Product Name
6NH7800-3BA00
Siemens SINAUT ST7 TIM 3V-IE Communication Module
6AG1800-4BA00-7AA0
Siemens SIPLUS SINAUT ST7 TIM 4R-IE Communication Module
6AG1543-1MX00-7XE0
Siemens SIPLUS TIM 1531 IRC Communication Module
6AG1803-3BA00-7AA0
Siemens SIPLUS SINAUT ST7 TIM 3V-IE DNP3 Communication Module
Frequently Selected Alternatives
Model
Product Name
6NH7800-3BA00
Siemens SINAUT ST7 TIM 3V-IE Communication Module
6AG1800-4BA00-7AA0
Siemens SIPLUS SINAUT ST7 TIM 4R-IE Communication Module
6AG1803-3BA00-7AA0
Siemens SIPLUS SINAUT ST7 TIM 3V-IE DNP3 Communication Module
6AG1803-4BA00-7AA0
Siemens SIPLUS NET TIM 4R-IE DNP3 Communication Module
Where It Fits in Industrial Applications
• Designed for SINAUT ST7 telecontrol and wide-area communication applications with Siemens SIMATIC S7-300 and C7 systems.
• 6AG1800-3BA00-7AA0 is a SIPLUS SINAUT ST7 TIM 3V-IE communication module based on 6NH7800-3BA00.
• Provides one RS-232 interface for SINAUT communication through conventional WAN connections and one RJ45 interface for IP-based WAN or LAN communication.
• Supports communication over Ethernet, GPRS routers, modems, IWLAN, and other compatible network infrastructures.
• The SIPLUS version uses conformal coating and is specified for operation from -25 °C to +70 °C.
Key Strengths at a Glance
• Provides SINAUT communication between SIMATIC S7-300/C7 stations and remote control or monitoring systems.
• Combines conventional RS-232 WAN communication with Industrial Ethernet communication in one compact module.
• Supports Industrial Ethernet transmission rates from 10 to 100 Mbit/s.
• Provides an RS-232 transmission range from 50 to 38,400 bit/s for compatible SINAUT connections.
• Supports IP-based communication architectures, including secure VPN solutions through compatible Siemens network components.
Technical FAQs
1. What is Siemens 6AG1800-3BA00-7AA0?
6AG1800-3BA00-7AA0 is a Siemens SIPLUS SINAUT ST7 TIM 3V-IE communication module based on 6NH7800-3BA00.
2. What is the main application of the TIM 3V-IE?
The module is designed to provide SINAUT telecontrol communication for SIMATIC S7-300 and C7 automation systems over conventional WAN and IP-based networks.
3. What communication interfaces are provided?
The module provides one RS-232 interface for external SINAUT communication and one RJ45 Industrial Ethernet interface for IP-based communication.
4. What Industrial Ethernet transmission speed is supported?
The Industrial Ethernet interface supports transmission rates from 10 to 100 Mbit/s.
5. What RS-232 transmission rates are supported?
The RS-232 interface supports transmission rates from 50 to 38,400 bit/s.
6. Can the TIM 3V-IE communicate through IP-based networks?
Yes. The Ethernet interface supports SINAUT communication over IP-based WAN or LAN networks and can be used with compatible network infrastructure such as GPRS routers, DSL connections, and Siemens security components.
7. What supply voltage does the module require?
The module operates from a nominal 24 V DC supply, with a specified operating range of 20.4 to 28.8 V DC.
8. Is a C-PLUG or backup battery required?
No. The technical documentation specifies that the module does not use a removable C-PLUG and does not require an optional backup battery.
9. What environmental conditions is the SIPLUS version designed for?
The module is specified for operation from -25 °C to +70 °C and uses conformal coating. It also has specified resistance to chemically, mechanically, and biologically active substances under the applicable environmental classifications.
10. What should be verified before replacing this communication module?
The SINAUT architecture, SIMATIC controller type, RS-232 WAN configuration, Ethernet network arrangement, power supply, firmware requirements, and existing telecontrol configuration should be verified before replacement.
