Siemens 6AG1803-4BA00-7AA0 SIPLUS NET TIM 4R-IE DNP3 Communication Module
Siemens 6AG1803-4BA00-7AA0 SIPLUS NET TIM 4R-IE DNP3 Communication Module
0.0
Points
Brand:Siemens Item No.: 6AG1803-4BA00-7AA0 Product Origin: Germany Product Dimensions:12.0 × 8.0 × 12.5 cm Product Weight:0.487 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1803-4BA00-7AA0 is a SIPLUS NET TIM 4R-IE DNP3 communication module based on 6NH7803-4BA00-0AA0. It is designed for DNP3 telecontrol communication with SIMATIC S7-300, S7-400, and compatible PC-based systems.
The module combines two RS-232/RS-485 interfaces for conventional WAN communication with two RJ45 interfaces for DNP3 communication over IP-based WAN or LAN networks. It supports DNP3 master and node functions, Modbus RTU applications, diagnostic functions, and communication-data buffering.
The SIPLUS version incorporates conformal coating and an extended operating temperature range of -25 °C to +70 °C. Siemens documentation identifies the module as the SIPLUS version of the TIM 4R-IE DNP3 platform.
Technical Specifications
Parameter
Specification
Brand
Siemens
Order Number
6AG1803-4BA00-7AA0
Product Type
SIPLUS NET TIM 4R-IE DNP3 Communication Module
Base Model
6NH7803-4BA00-0AA0
Application
DNP3 telecontrol communication
Compatible Systems
SIMATIC S7-300, S7-400, PC
RS-232 Interfaces
2
RS-485 Interfaces
2
Serial Interfaces
2 combined RS-232/RS-485
Industrial Ethernet Interfaces
2
Industrial Ethernet Connector
RJ45
Communication Protocol
DNP3
DNP3 Functions
Master / Node
Modbus RTU
Supported
Mounting
S7-300 rail
Module Format
S7-300 communication module
Front Protection
IP20
Operating Temperature
-25 °C to +70 °C
Storage Temperature
-40 °C to +70 °C
Transport Temperature
-40 °C to +70 °C
Conformal Coating
Yes
Dimensions (L × W × H)
12.0 × 8.0 × 12.5 cm
Net Weight
Approx. 0.487 kg
Recommended Companion Models
Model
Product Name
6NH7803-4BA00-0AA0
Siemens TIM 4R-IE DNP3 Communication Module
6AG1803-3BA00-7AA0
Siemens SIPLUS NET TIM 3V-IE DNP3 Communication Module
6AG1800-4BA00-7AA0
Siemens SIPLUS SINAUT ST7 TIM 4R-IE Communication Module
6AG1543-1MX00-7XE0
Siemens SIPLUS TIM 1531 IRC Communication Module
Frequently Selected Alternatives
Model
Product Name
6NH7803-4BA00-0AA0
Siemens TIM 4R-IE DNP3 Communication Module
6AG1803-3BA00-7AA0
Siemens SIPLUS NET TIM 3V-IE DNP3 Communication Module
6AG1800-4BA00-7AA0
Siemens SIPLUS SINAUT ST7 TIM 4R-IE Communication Module
6AG1800-3BA00-7AA0
Siemens SIPLUS SINAUT ST7 TIM 3V-IE Communication Module
Where It Fits in Industrial Applications
• Designed for DNP3 telecontrol and wide-area communication applications using Siemens SIMATIC automation systems.
• 6AG1803-4BA00-7AA0 is a SIPLUS NET TIM 4R-IE DNP3 communication module based on 6NH7803-4BA00-0AA0.
• Provides two combined RS-232/RS-485 interfaces for DNP3 communication through conventional WAN networks.
• Provides two RJ45 interfaces for DNP3 communication through IP-based WAN or LAN networks.
• The SIPLUS version uses conformal coating and supports an operating temperature range of -25 °C to +70 °C.
Key Strengths at a Glance
• Combines two serial RS-232/RS-485 interfaces and two Industrial Ethernet interfaces in one telecontrol communication module.
• Supports DNP3 communication through both conventional WAN and IP-based network architectures.
• Supports DNP3 master and node functionality for compatible telecontrol configurations.
• Provides separate communication paths that can support media redundancy and continued data communication during path switching.
• Includes onboard processing and memory for buffering communication data and reducing the risk of data loss during communication interruptions.
Technical FAQs
1. What is Siemens 6AG1803-4BA00-7AA0?
6AG1803-4BA00-7AA0 is a Siemens SIPLUS NET TIM 4R-IE DNP3 communication module based on 6NH7803-4BA00-0AA0.
2. What is the main application of the TIM 4R-IE DNP3?
The module is designed for DNP3-based telecontrol communication between compatible SIMATIC automation stations, remote terminal units, and control-center systems.
3. How many serial interfaces are provided?
The module provides two combined RS-232/RS-485 interfaces for DNP3 communication over conventional WAN networks and compatible serial applications.
4. How many Industrial Ethernet interfaces are available?
The TIM 4R-IE DNP3 provides two RJ45 Industrial Ethernet interfaces for communication over IP-based WAN or LAN networks.
5. Does the module support DNP3 master and node functions?
Yes. The module supports DNP3 master and node functionality in compatible configurations and can operate as part of a DNP3 telecontrol architecture.
6. Can the serial interfaces be used for Modbus RTU communication?
Yes. The technical documentation identifies support for connecting a Modbus RTU slave to an S7-300 system through a serial interface.
7. Does the module support communication redundancy?
Yes. The two separate communication paths can be used for media redundancy, allowing communication to continue during an appropriate path switchover.
8. What environmental conditions does the SIPLUS version support?
The module is specified for operation from -25 °C to +70 °C and uses conformal coating. Siemens also specifies resistance to chemically active substances according to applicable environmental classifications.
9. What systems can use the TIM 4R-IE DNP3?
The module is intended for use with SIMATIC S7-300, S7-400, and compatible PC-based systems within supported DNP3 telecontrol architectures.
10. What should be verified before replacing this communication module?
The DNP3 communication architecture, controller type, RS-232/RS-485 configuration, Industrial Ethernet network topology, power supply, firmware, and existing telecontrol configuration should be verified before replacement.
