Siemens 6AG1901-1BB10-7AA0 SIPLUS NET RJ45 Plug 180 Connector
Siemens 6AG1901-1BB10-7AA0 SIPLUS NET RJ45 Plug 180 Connector
0.0
Points
Brand:Siemens Item No.:6AG1901-1BB10-7AA0 Product Origin: Germany Product Dimensions:130 × 90 × 142 mm Product Weight:0.034 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1901-1BB10-7AA0 is a SIPLUS NET RJ45 Plug 180 2×2 designed for Industrial Ethernet FastConnect installations. It is based on the 6GK1901-1BB10-2AA0 and combines a rugged metal enclosure with integrated FastConnect termination technology.
The connector supports 10/100 Mbit/s Industrial Ethernet communication and is designed for IE FC cable 2×2 installation cables. Its 180° cable outlet provides a practical connection arrangement for Siemens network components and communication processors.
As a SIPLUS product, the connector features conformal coating and an extended -40 °C to +70 °C operating temperature range, making it suitable for industrial applications with demanding environmental conditions.
• Features a rugged metal enclosure for industrial network installations.
• Uses FastConnect technology with integrated cut-and-clamp contacts for 4-wire Industrial Ethernet TP installation cables.
• Provides a convenient 180° cable outlet for compact and organized cabinet or equipment wiring.
• Conformal coating and an extended -40 °C to +70 °C operating temperature range support demanding industrial applications.
• Supplied as one RJ45 plug per package.
Technical FAQs
1. What is Siemens 6AG1901-1BB10-7AA0?
6AG1901-1BB10-7AA0 is a SIPLUS NET RJ45 Plug 180 2×2 connector based on the Siemens 6GK1901-1BB10-2AA0.
2. What is the main purpose of this connector?
It is used to terminate compatible Industrial Ethernet FastConnect installation cables and connect them to Siemens network components equipped with RJ45 interfaces.
3. What communication speed does the connector support?
The connector is designed for Industrial Ethernet communication at 10 and 100 Mbit/s.
4. What type of cable is it designed for?
It is designed for IE FC cable 2×2 installation cables with four conductors suitable for Industrial Ethernet applications.
5. What does the 180 designation mean?
The 180 designation refers to the 180° cable outlet orientation of the RJ45 plug.
6. What connection technology does this plug use?
The connector uses FastConnect technology with integrated cut-and-clamp contacts for the compatible 4-wire TP Industrial Ethernet installation cable.
7. Is the connector suitable for harsh industrial environments?
Yes. The SIPLUS version includes conformal coating and is specified for an extended operating temperature range of -40 °C to +70 °C.
8. What is the difference between 6AG1901-1BB10-7AA0 and 6AG1901-1BB20-7AA0?
The primary difference is the cable outlet orientation. 6AG1901-1BB10-7AA0 provides a 180° cable outlet, while 6AG1901-1BB20-7AA0 provides a 90° cable outlet.
9. Is this connector supplied individually?
Yes. The Siemens ordering information specifies one RJ45 plug per package.
10. What should be verified before ordering this connector?
The Industrial Ethernet cable type, connector orientation, connected Siemens device, and required FastConnect installation method should be checked to ensure compatibility.
