Siemens 6AG1901-1BB20-7AA0 SIPLUS NET RJ45 Plug 90 Connector
Siemens 6AG1901-1BB20-7AA0 SIPLUS NET RJ45 Plug 90 Connector
0.0
Points
Brand:Siemens Item No.:6AG1901-1BB20-7AA0 Product Origin: Germany Product Dimensions:4.2 × 1.37 × 1.6 cm Product Weight:0.035 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1901-1BB20-7AA0 is a SIPLUS NET RJ45 Plug 90 2×2 designed for Industrial Ethernet FastConnect installations. It is based on the 6GK1901-1BB20-2AA0 and combines a rugged metal enclosure with an integrated FastConnect termination system.
The connector supports 10/100 Mbit/s Industrial Ethernet communication and is designed for IE FC Cable 2×2 installation cables. Its 90° cable outlet provides a right-angle connection arrangement that can help simplify network cable routing in control cabinets and industrial equipment.
As a SIPLUS version, the connector features conformal coating and an extended -40 °C to +70 °C operating temperature range. The connector is specified as a Cat5 Industrial Ethernet component with IP20 protection.
Technical Specifications
Parameter
Specification
Brand
Siemens
SIPLUS Order Number
6AG1901-1BB20-7AA0
Standard Base Product
6GK1901-1BB20-2AA0
Product Type
SIPLUS NET RJ45 Plug 90 2×2
Connector Type
RJ45 plug-in connector
Application
Industrial Ethernet
Data Rate
10/100 Mbit/s
Cable Type
IE FC Cable 2×2
Connection Technology
FastConnect
Cable Outlet
90°
Enclosure Material
Metal
Cable Connection
Integrated cut-and-clamp contacts for 4-wire TP FC installation cable
• Features a rugged metal enclosure for reliable industrial network connections.
• Uses FastConnect technology with integrated cut-and-clamp contacts for compatible 4-wire TP installation cables.
• Provides a 90° cable outlet that can simplify cable routing in compact control cabinets and equipment installations.
• Conformal coating and an extended -40 °C to +70 °C operating temperature range support demanding industrial environments.
• Supplied as one RJ45 plug per package.
Technical FAQs
1. What is Siemens 6AG1901-1BB20-7AA0?
6AG1901-1BB20-7AA0 is a SIPLUS NET RJ45 Plug 90 2×2 connector based on the Siemens 6GK1901-1BB20-2AA0.
2. What is the main function of this connector?
The connector is used to terminate compatible Industrial Ethernet installation cables and connect them to network components or terminal equipment through an RJ45 interface.
3. What communication speed does the connector support?
The connector is designed for Industrial Ethernet communication at 10 Mbit/s and 100 Mbit/s.
4. What type of cable is compatible with this RJ45 plug?
It is designed for Siemens IE FC Cable 2×2 and compatible 4-wire TP Industrial Ethernet installation cables.
5. What does the 90 designation indicate?
The 90 designation refers to the connector's 90° cable outlet, which provides a right-angle cable routing arrangement.
6. What connection technology does the plug use?
The connector uses Siemens FastConnect technology with integrated cut-and-clamp contacts for the Industrial Ethernet installation cable.
7. Is the connector suitable for harsh industrial environments?
Yes. The SIPLUS version has conformal coating and is specified for operation from -40 °C to +70 °C, supporting use in demanding industrial environments.
8. What is the difference between 6AG1901-1BB20-7AA0 and 6AG1901-1BB10-7AA0?
The primary difference is the cable outlet orientation. 6AG1901-1BB20-7AA0 has a 90° cable outlet, while 6AG1901-1BB10-7AA0 has a 180° cable outlet.
9. How many connectors are supplied in one package?
The Siemens ordering information specifies one RJ45 plug per package.
10. What should be verified before ordering this connector?
The Industrial Ethernet cable type, required cable outlet orientation, connected network device, and FastConnect installation requirements should be checked before ordering.
