Siemens 6AG1950-2AA01-4AA0 SIPLUS SIWAREX U Weighing Electronics
Siemens 6AG1950-2AA01-4AA0 SIPLUS SIWAREX U Weighing Electronics
0.0
Points
Brand:Siemens Item No.:6AG1950-2AA01-4AA0 Product Origin: Germany Product Dimensions:15.0 × 13.0 × 4.9 cm Product Weight:0.282 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1950-2AA01-4AA0 is a SIPLUS SIWAREX U electronic weighing system based on the 7MH4950-2AA01. It is designed as a compact SIMATIC S7-300 function module for simple weighing and force-measurement applications.
The module can be integrated into SIMATIC S7-300 and ET 200M systems and provides direct access to weighing measurements through the automation controller. Depending on the configuration, one or two measurement channels can be used, with the module converting load-cell sensor signals into weight values for further processing.
The SIPLUS version features conformal coating and an operating temperature range of 0 °C to +60 °C. It is intended for environments with specified chemically, mechanically, and biologically active substances and can support applications requiring enhanced environmental resistance.
Technical Specifications
Parameter
Specification
Brand
Siemens
SIPLUS Order Number
6AG1950-2AA01-4AA0
Standard Base Product
7MH4950-2AA01
Product Family
SIPLUS SIWAREX U
Product Type
Electronic weighing system / weighing electronics
System Compatibility
SIMATIC S7-300 and ET 200M
Measurement Channels
1 or 2, depending on configuration
Primary Function
Weighing and force measurement
Signal Processing
Digital filtering supported
Software
SIWATOOL U
Bus Connection
SIMATIC S7-300 / ET 200M backplane
Included Accessory
Bus connector
Conformal Coating
Yes
Ambient Temperature
0 °C to +60 °C
Relative Humidity
Up to 100%, condensation/frost permissible under specified conditions
Environmental Resistance
Chemically, mechanically, and biologically active substances under specified SIPLUS conditions
Dimensions (L × W × H)
Approx. 15.0 × 13.0 × 4.9 cm
Net Weight
Approx. 0.282 kg
Recommended Companion Models
Model
Product Name
7MH4950-2AA01
Siemens SIWAREX U Electronic Weighing System
7MH4710-1BA
Siemens SIWAREX JB Junction Box for Load Cells
6ES7392-1BJ00-0AA0
Siemens SIMATIC S7-300 20-Pin Front Connector
7MH4710-5BA
Siemens SIWAREX IS Ex Interface for Intrinsically Safe Load-Cell Connection
• Designed for integration into SIMATIC S7-300 and ET 200M automation systems for industrial weighing and force-measurement applications.
• Provides electronic weighing functions for simple static weighing and force-measurement tasks.
• Suitable for applications such as crane load monitoring, conveyor-belt loading measurement, elevator or rolling-mill overload protection, and belt-tension monitoring.
• Based on the Siemens 7MH4950-2AA01 SIWAREX U weighing electronics with conformal coating.
• Designed for industrial environments with exposure to specified chemically, mechanically, and biologically active substances.
Key Strengths at a Glance
• Provides a compact weighing interface that integrates directly into the SIMATIC automation architecture.
• Supports one or two measurement channels, allowing each channel to be assigned to a weighing scale.
• Converts load-cell sensor signals into weight values for processing by the SIMATIC controller.
• Supports digital filtering of the measured signal for improved weighing-system processing.
• Includes a bus connector and can be mounted directly on a SIMATIC S7-300 or ET 200M backplane.
• Supports configuration and commissioning with Siemens SIWATOOL U software.
• Conformal coating and SIPLUS environmental protection support demanding industrial installations.
Technical FAQs
1. What is Siemens 6AG1950-2AA01-4AA0?
6AG1950-2AA01-4AA0 is a SIPLUS SIWAREX U electronic weighing system based on the Siemens 7MH4950-2AA01.
2. What is the main function of SIWAREX U?
SIWAREX U measures sensor signals from weighing or force-measurement applications and provides the resulting measurement values to the SIMATIC automation system.
3. How many weighing channels does the SIWAREX U provide?
The SIWAREX U is available with one or two measurement channels, with one measurement channel required for each connected scale.
4. Which automation systems can use this module?
The module is designed for SIMATIC S7-300 and ET 200M automation systems and can be integrated into the system backplane.
5. What types of applications are suitable for SIWAREX U?
Typical applications include crane and cable load monitoring, conveyor-belt loading measurement, overload protection for industrial elevators or rolling mills, and belt-tension monitoring.
6. Can the weighing signal be digitally filtered?
Yes. SIWAREX U supports digital filtering of the measured sensor signal for weighing-system applications.
7. Can SIWAREX U be used in hazardous areas?
The weighing module can be used in hazardous-area applications when the appropriate optional intrinsically safe Ex interface and associated approved system configuration are used.
8. What software can be used to configure the module?
SIWATOOL U can be used for convenient parameterization, adjustment, diagnostics, and commissioning of compatible SIWAREX U weighing modules.
9. What environmental features does the SIPLUS version provide?
The module has conformal coating and is specified for 0 °C to +60 °C operation. Its SIPLUS environmental specification also permits condensation under the specified conditions, although commissioning while condensation is present is not permitted.
10. What should be verified before ordering this module?
The SIMATIC system type, number of weighing channels, load-cell configuration, required Ex interface, environmental conditions, and applicable SIWAREX accessories should be verified before ordering.
