Brand:Siemens Item No.:6AG1952-1AP00-7AA0 Product Origin: Germany Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.055 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1952-1AP00-7AA0 is a SIPLUS S7-400 RAM memory card with an 8 MB capacity. It is based on the standard 6ES7952-1AP00-0AA0 and is designed for compatible SIMATIC S7-400 and S7-400H CPU configurations.
The card uses the long-design S7-400 form factor and provides RAM storage for user programs and associated data in compatible automation systems. It is intended for direct installation into the memory-card slot of the corresponding S7-400 CPU.
As a SIPLUS version, the card incorporates conformal coating and supports an operating temperature range of -25 °C to +70 °C. This makes it suitable for industrial applications requiring enhanced environmental resistance while retaining the functionality of the standard 8 MB S7-400 RAM memory card.
Technical Specifications
Parameter
Specification
Brand
Siemens
SIPLUS Order Number
6AG1952-1AP00-7AA0
Standard Base Product
6ES7952-1AP00-0AA0
Product Family
SIPLUS S7-400
Product Type
RAM memory card
Memory Type
RAM
Memory Capacity
8 MB
Design
Long design
Application
SIMATIC S7-400 / S7-400H
Installation
S7-400 CPU memory-card slot
Conformal Coating
Yes
Operating Temperature
-25 °C to +70 °C
Maximum Installation Altitude
5,000 m
Product Status
Active
Dimensions (L × W × H)
Not reliably published as a fixed product value
Net Weight
Approx. 0.055 kg
Recommended Companion Models
Model
Product Name
6AG1414-5HM06-7AB0
Siemens SIPLUS S7-400 CPU 414-5H
6AG1416-5HS06-7AB0
Siemens SIPLUS S7-400 CPU 416-5H
6AG1952-1AM00-7AA0
Siemens SIPLUS S7-400 4 MB RAM Memory Card
6AG1952-1AS00-7AA0
Siemens SIPLUS S7-400 16 MB RAM Memory Card
Frequently Selected Alternatives
Model
Product Name
6ES7952-1AP00-0AA0
Siemens SIMATIC S7-400 8 MB RAM Memory Card
6AG1952-1AL00-4AA0
Siemens SIPLUS S7-400 2 MB RAM Memory Card
6AG1952-1AM00-7AA0
Siemens SIPLUS S7-400 4 MB RAM Memory Card
6AG1952-1AS00-7AA0
Siemens SIPLUS S7-400 16 MB RAM Memory Card
Where It Fits in Industrial Applications
• Designed as an 8 MB RAM memory card for compatible Siemens SIMATIC S7-400 automation systems.
• Provides additional RAM capacity for S7-400 CPU configurations requiring the corresponding long-design memory card.
• Suitable for compatible S7-400 and S7-400H automation applications where 8 MB RAM is specified.
• Based on the standard Siemens 6ES7952-1AP00-0AA0 RAM memory card with SIPLUS conformal coating.
• Intended for industrial installations requiring an extended operating temperature range and enhanced environmental resistance.
Key Strengths at a Glance
• Provides 8 MB RAM capacity for compatible S7-400 CPU applications.
• Uses the long-design S7-400 memory-card format for direct installation into the corresponding CPU slot.
• Supports storage of user program and data required by compatible S7-400 automation systems.
• Conformal-coated construction improves resistance to specified industrial environmental conditions.
• Supports an operating temperature range of -25 °C to +70 °C.
• Provides a practical memory expansion and replacement option for compatible S7-400 installations.
Technical FAQs
1. What is Siemens 6AG1952-1AP00-7AA0?
6AG1952-1AP00-7AA0 is a SIPLUS S7-400 8 MB RAM memory card based on the Siemens 6ES7952-1AP00-0AA0.
2. What is the memory capacity of this card?
The card provides 8 MB of RAM memory.
3. Which automation systems use this memory card?
The card is designed for compatible SIMATIC S7-400 and S7-400H CPU configurations that support the corresponding long-design RAM memory card.
4. What does the long-design designation mean?
Long design refers to the physical form factor of the S7-400 memory card intended for the corresponding CPU memory-card slot.
5. What is the difference between this card and the 4 MB version?
The primary difference is memory capacity. 6AG1952-1AP00-7AA0 provides 8 MB RAM, while 6AG1952-1AM00-7AA0 provides 4 MB RAM.
6. Is 6AG1952-1AP00-7AA0 based on a standard Siemens memory card?
Yes. The SIPLUS card is based on the standard 6ES7952-1AP00-0AA0 8 MB S7-400 RAM memory card.
7. What environmental features does the SIPLUS version provide?
The card has conformal coating and supports an operating temperature range of -25 °C to +70 °C, providing enhanced suitability for demanding industrial environments.
8. Can this card replace a lower-capacity S7-400 RAM card?
Only when the specific S7-400 CPU and application support the 8 MB capacity. The CPU's supported memory-card types should be checked before replacement.
9. Is this card intended for S7-300 systems?
No. It is designed for the S7-400 memory-card architecture and should be used only with compatible S7-400 CPU configurations.
10. What should be verified before ordering this memory card?
The S7-400 CPU model, required memory capacity, long-design format, existing memory-card specification, and environmental requirements should be verified before ordering.
