Brand:Siemens Item No.:6AG1960-1AA06-7XA0 Product Origin: Germany Product Dimensions:5.8 × 1.3 × 1.4 cm Product Weight:0.014 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1960-1AA06-7XA0 is a SIPLUS S7-400H synchronization module based on the standard 6ES7960-1AA06-0XA0. It is designed to provide the synchronization connection between compatible CPU 41xH units in S7-400H high-availability systems.
The module supports fiber-optic patch cables up to 10 m and incorporates conformal coating for enhanced environmental protection. With an operating temperature range of approximately -25 °C to +70 °C, it is intended for demanding industrial automation installations.
Technical Specifications
Parameter
Specification
Brand
Siemens
Part Number
6AG1960-1AA06-7XA0
Product Type
SIPLUS S7-400H Synchronization Module
Base Standard Part Number
6ES7960-1AA06-0XA0
Application
S7-400H CPU 41xH synchronization
Synchronization Cable
Fiber-optic patch cable
Maximum Patch-Cable Length
10 m
Maximum Current Consumption
Approx. 220 mA
Typical Power Loss
Approx. 0.77 W
Environmental Protection
Conformal coating
Operating Temperature
Approx. -25 °C to +70 °C
Maximum Installation Altitude
5,000 m
Dimensions (L × W × H)
5.8 × 1.3 × 1.4 cm
Net Weight
Approx. 0.014 kg
Recommended Companion Models
Model
Product Name
6AG1414-5HM06-7AB0
Siemens SIPLUS S7-400 CPU 414-5H
6AG1416-5HS06-7AB0
Siemens SIPLUS S7-400 CPU 416-5H
6AG1960-1AA04-7BA0
Siemens SIPLUS S7-400H 2 m HF-Sync Optical Fiber Cable
6AG1960-1AA04-7KA0
Siemens SIPLUS S7-400H 10 m HF-Sync Optical Fiber Cable
Frequently Selected Alternatives
Model
Product Name
6ES7960-1AA06-0XA0
Siemens SIMATIC S7-400H Synchronization Module
6AG1960-1AB06-7XA0
Siemens SIPLUS S7-400H Synchronization Module for Fiber-Optic Cables up to 10 km
6AG1960-1AA04-7BA0
Siemens SIPLUS S7-400H 2 m HF-Sync Optical Fiber Cable
6AG1960-1AA04-7KA0
Siemens SIPLUS S7-400H 10 m HF-Sync Optical Fiber Cable
Where It Fits in Industrial Applications
• Designed as a SIPLUS synchronization module for connecting compatible S7-400H CPU 41xH configurations.
• Used in high-availability S7-400H systems where synchronization between redundant CPU units is required.
• Supports fiber-optic patch-cable connections with a maximum applicable cable length of 10 m.
• Suitable for demanding industrial environments requiring extended temperature and environmental protection.
Key Strengths at a Glance
• Provides synchronization connectivity for compatible S7-400H CPU configurations.
• Supports fiber-optic patch cables up to 10 m.
• Based on the Siemens 6ES7960-1AA06-0XA0 synchronization module.
• Features conformal coating and an operating temperature range of approximately -25 °C to +70 °C.
Technical FAQs
1. What is Siemens 6AG1960-1AA06-7XA0?
6AG1960-1AA06-7XA0 is a SIPLUS S7-400 synchronization module based on the standard 6ES7960-1AA06-0XA0.
2. What is the primary function of this synchronization module?
The module provides the synchronization connection required between compatible CPU 41xH units in an S7-400H high-availability system.
3. What type of cable does 6AG1960-1AA06-7XA0 support?
It is designed for fiber-optic patch-cable connections with a maximum applicable cable length of 10 m.
4. Which Siemens automation platform uses this module?
The module is intended for compatible SIMATIC S7-400H high-availability automation systems.
5. What is the operating temperature range?
The specified operating temperature range is approximately -25 °C to +70 °C.
6. Does the module have conformal coating?
Yes. The SIPLUS version incorporates conformal coating for enhanced reliability in demanding industrial environments.
7. What is the maximum current consumption?
The maximum current consumption is approximately 220 mA.
8. What is the typical power loss of the module?
The typical power loss is approximately 0.77 W.
9. Can this module be used with a fiber-optic cable longer than 10 m?
No. This synchronization-module version is specified for patch cables up to 10 m. Applications requiring longer fiber-optic connections use the corresponding S7-400H synchronization solution intended for distances up to 10 km.
10. What should be verified before ordering this synchronization module?
The CPU 41xH configuration, required synchronization distance, existing synchronization-module part number, and applicable S7-400H system documentation should be verified before ordering.
