Brand:Siemens Item No.:6AG1960-1AB06-7XA0 Product Origin: Germany Product Dimensions:5.8 × 1.3 × 1.4 cm Product Weight:0.014 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1960-1AB06-7XA0 is a SIPLUS S7-400H remote synchronization module based on the standard 6ES7960-1AB06-0XA0. It is designed for synchronization between compatible CPU 41xH units in S7-400H high-availability systems.
The module supports fiber-optic synchronization over cable runs of up to 10 km and incorporates conformal coating for enhanced environmental protection. With an operating temperature range of approximately -25 °C to +70 °C, it is intended for demanding industrial automation installations.
Technical Specifications
Parameter
Specification
Brand
Siemens
Part Number
6AG1960-1AB06-7XA0
Product Type
SIPLUS S7-400H Remote Synchronization Module
Base Standard Part Number
6ES7960-1AB06-0XA0
Synchronization Version
V6
Application
S7-400H CPU 41xH synchronization
Maximum Fiber-Optic Cable Length
Up to 10 km
Maximum Current Consumption
Approx. 240 mA
Typical Power Loss
Approx. 0.83 W
Environmental Protection
Conformal coating
Operating Temperature
Approx. -25 °C to +70 °C
Maximum Installation Altitude
5,000 m
Dimensions (L × W × H)
5.8 × 1.3 × 1.4 cm
Net Weight
Approx. 0.014 kg
Recommended Companion Models
Model
Product Name
6AG1414-5HM06-7AB0
Siemens SIPLUS S7-400 CPU 414-5H
6AG1416-5HS06-7AB0
Siemens SIPLUS S7-400 CPU 416-5H
6AG1960-1AA06-7XA0
Siemens SIPLUS S7-400H Synchronization Module for Patch Cables up to 10 m
6AG1960-1AA04-7KA0
Siemens SIPLUS S7-400H 10 m HF-Sync Optical Fiber Cable
Siemens SIPLUS S7-400H Synchronization Module for Patch Cables up to 10 m
6AG1960-1AA04-7BA0
Siemens SIPLUS S7-400H 2 m HF-Sync Optical Fiber Cable
6AG1960-1AA04-7KA0
Siemens SIPLUS S7-400H 10 m HF-Sync Optical Fiber Cable
Where It Fits in Industrial Applications
• Designed as a SIPLUS S7-400H synchronization module for linking compatible CPU 41xH units in high-availability automation systems.
• Supports synchronization over fiber-optic cable runs of up to 10 km.
• Based on the Siemens 6ES7960-1AB06-0XA0 synchronization module and intended for demanding industrial environments.
• Suitable for S7-400H installations requiring long-distance synchronization between redundant CPU units.
Key Strengths at a Glance
• Provides V6 synchronization capability for fiber-optic connections up to 10 km.
• Supports both suitable patch and installation cable configurations for long-distance synchronization.
• Features conformal coating for enhanced environmental protection and reliability.
• Supports an operating temperature range of approximately -25 °C to +70 °C.
Technical FAQs
1. What is Siemens 6AG1960-1AB06-7XA0?
6AG1960-1AB06-7XA0 is a SIPLUS S7-400H remote synchronization module based on the standard 6ES7960-1AB06-0XA0.
2. What is the primary function of this synchronization module?
The module provides the synchronization connection between compatible CPU 41xH units in an S7-400H high-availability system.
3. What is the maximum synchronization cable distance?
The module is specified for fiber-optic cable connections up to 10 km.
4. Which Siemens automation platform uses this module?
It is designed for compatible SIMATIC S7-400H high-availability automation systems using CPU 41xH configurations.
5. What type of cable is used with 6AG1960-1AB06-7XA0?
The module is designed for suitable fiber-optic patch and installation cables for long-distance synchronization applications.
6. What is the operating temperature range?
The specified operating temperature range is approximately -25 °C to +70 °C.
7. Does the SIPLUS version include conformal coating?
Yes. The 6AG1960-1AB06-7XA0 includes conformal coating for enhanced protection in demanding industrial environments.
8. What is the maximum current consumption?
The maximum current consumption is approximately 240 mA.
9. What is the typical power loss of the module?
The typical power loss is approximately 0.83 W.
10. What should be verified before ordering this synchronization module?
The CPU 41xH configuration, required synchronization distance, fiber-optic cable type, existing synchronization-module part number, and applicable S7-400H system documentation should be verified before ordering.
