Siemens 6AG1960-1CB00-4AA5 SIPLUS S7-1500 10 m Sync Submodule
Siemens 6AG1960-1CB00-4AA5 SIPLUS S7-1500 10 m Sync Submodule
0.0
Points
Brand:Siemens Item No.: 6AG1960-1CB00-4AA5 Product Origin: Germany Product Dimensions:5.8 × 1.3 × 1.4 cm Product Weight:0.056 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1960-1CB00-4AA5 is a SIPLUS S7-1500 synchronization submodule based on the standard 6ES7960-1CB00-0AA5. It provides an optical synchronization interface for compatible S7-1500 controller configurations and uses an LC optical connection with an 850 nm interface wavelength.
The submodule is specified for patch-cable applications up to 10 m, with an optical interface range of up to 200 m depending on the fiber used. Conformal coating and an operating temperature range of 0 °C to +60 °C make it suitable for demanding industrial automation installations.
Technical Specifications
Parameter
Specification
Brand
Siemens
Part Number
6AG1960-1CB00-4AA5
Product Type
SIPLUS S7-1500 Synchronization Submodule
Base Standard Part Number
6ES7960-1CB00-0AA5
Synchronization Application
S7-1500 controller synchronization
Optical Interface
Yes
Optical Connection
LC
Optical Interface Wavelength
850 nm
Maximum Optical Interface Range
Up to 200 m, depending on optical fiber
Maximum Patch-Cable Length
10 m
Typical Power Loss
Approx. 0.77 W
Environmental Protection
Conformal coating
Operating Temperature
0 °C to +60 °C
Dimensions (L × W × H)
5.8 × 1.3 × 1.4 cm
Net Weight
Approx. 0.056 kg
Recommended Companion Models
Model
Product Name
6AG1517-3HP00-4AB0
Siemens SIPLUS S7-1500 CPU 1517H-3 PN
6AG1960-1FB00-4AA5
Siemens SIPLUS S7-1500 Synchronization Submodule for Long-Distance Connections
6AG1960-1AA06-7XA0
Siemens SIPLUS S7-400H Synchronization Module for Patch Cables up to 10 m
• Designed as a SIPLUS synchronization submodule for compatible Siemens S7-1500 CPUs.
• Provides optical synchronization between compatible S7-1500 controller components over fiber-optic patch cables.
• Supports synchronization connections with a maximum applicable patch-cable range of up to 10 m.
• Suitable for industrial automation installations requiring enhanced environmental protection and reliable controller synchronization.
Key Strengths at a Glance
• Provides an optical synchronization interface using an LC connection.
• Supports fiber-optic synchronization distances of up to 200 m depending on the selected optical fiber, while the specified patch-cable application is up to 10 m.
• Based on the Siemens 6ES7960-1CB00-0AA5 synchronization submodule.
• Features conformal coating and an operating temperature range of 0 °C to +60 °C.
Technical FAQs
1. What is Siemens 6AG1960-1CB00-4AA5?
6AG1960-1CB00-4AA5 is a SIPLUS S7-1500 synchronization submodule based on the standard 6ES7960-1CB00-0AA5.
2. What is the primary function of this synchronization submodule?
It provides an optical synchronization connection between compatible S7-1500 controller components.
3. What type of optical connection does the submodule use?
The module uses an LC optical connection with an optical interface wavelength of 850 nm.
4. What is the maximum synchronization range?
The maximum optical interface range is up to 200 m depending on the optical fiber used. For the specified patch-cable application, the submodule is intended for cables up to 10 m.
5. Which Siemens automation platform uses this submodule?
The 6AG1960-1CB00-4AA5 is designed for compatible SIMATIC S7-1500 controller configurations.
6. What is the operating temperature range?
The specified operating temperature range for horizontal installation is 0 °C to +60 °C.
7. Does the SIPLUS version include conformal coating?
Yes. The SIPLUS version incorporates conformal coating for enhanced environmental protection.
8. What is the typical power loss of the submodule?
The typical power loss is approximately 0.77 W.
9. Can the submodule be used with any S7-1500 CPU?
No. Compatibility depends on the specific S7-1500 CPU and its supported synchronization interface. The applicable Siemens hardware documentation should be checked before installation.
10. What should be verified before ordering this submodule?
The S7-1500 CPU model, required synchronization distance, fiber-optic cable type, existing synchronization-submodule part number, and applicable Siemens system documentation should be verified before ordering.
