Brand:Siemens Item No.:6AG1960-1FB00-4AA5 Product Origin: Germany Product Dimensions:5.8 × 1.3 × 1.4 cm Product Weight:0.044 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1960-1FB00-4AA5 is a SIPLUS S7-1500 synchronization submodule based on the standard 6ES7960-1FB00-0AA5. It provides an optical synchronization interface for compatible S7-1500 controller configurations and uses an LC optical connection with a 1,310 nm wavelength.
The module supports synchronization distances from approximately 2 m up to 10 km, depending on the optical fiber used. Conformal coating and an operating temperature range of 0 °C to +60 °C for horizontal installation make it suitable for demanding industrial automation applications.
Technical Specifications
Parameter
Specification
Brand
Siemens
Part Number
6AG1960-1FB00-4AA5
Product Type
SIPLUS S7-1500 Synchronization Submodule
Base Standard Part Number
6ES7960-1FB00-0AA5
Synchronization Application
S7-1500 controller synchronization
Optical Interface
Yes
Optical Connection
LC
Optical Interface Wavelength
1,310 nm
Minimum Optical Range
Approx. 2 m
Maximum Optical Range
Up to 10 km, depending on optical fiber
Typical Power Loss
Approx. 0.83 W
Environmental Protection
Conformal coating
Operating Temperature, Horizontal Installation
0 °C to +60 °C
Operating Temperature, Vertical Installation
0 °C to +40 °C
Dimensions (L × W × H)
5.8 × 1.3 × 1.4 cm
Net Weight
Approx. 0.044 kg
Recommended Companion Models
Model
Product Name
6AG1517-3HP00-4AB0
Siemens SIPLUS S7-1500 CPU 1517H-3 PN
6AG1960-1CB00-4AA5
Siemens SIPLUS S7-1500 Synchronization Submodule for Up to 200 m
6AG1960-1AA06-7XA0
Siemens SIPLUS S7-400H Synchronization Module for Patch Cables up to 10 m
• Designed as a SIPLUS S7-1500 synchronization submodule for compatible Siemens S7-1500 controller configurations.
• Provides optical synchronization over fiber-optic patch cables with a range of up to 10 km.
• Based on Siemens 6ES7960-1FB00-0AA5 and equipped with conformal coating for demanding industrial environments.
• Suitable for S7-1500 automation systems requiring long-distance synchronization between compatible controller components.
Key Strengths at a Glance
• Supports optical synchronization distances from approximately 2 m up to 10 km, depending on the selected optical fiber.
• Uses an LC optical connection with a 1,310 nm optical interface wavelength.
• Features conformal coating for enhanced protection in industrial environments.
• Supports an operating temperature range of 0 °C to +60 °C for horizontal installation.
Technical FAQs
1. What is Siemens 6AG1960-1FB00-4AA5?
6AG1960-1FB00-4AA5 is a SIPLUS S7-1500 synchronization submodule based on the standard 6ES7960-1FB00-0AA5.
2. What is the primary function of this synchronization module?
The module provides an optical synchronization connection between compatible S7-1500 controller components.
3. What is the maximum synchronization range?
The synchronization range is up to 10 km, depending on the optical fiber used.
4. What optical connection does the module use?
The module uses an LC optical connection with an optical interface wavelength of 1,310 nm.
5. What is the minimum specified optical range?
The specified minimum range is approximately 2 m, with the maximum range extending to 10 km depending on the optical fiber.
6. What is the operating temperature range?
For horizontal installation, the specified operating temperature range is 0 °C to +60 °C. Vertical installation has a reduced maximum operating temperature.
7. Does the SIPLUS version include conformal coating?
Yes. The 6AG1960-1FB00-4AA5 includes conformal coating for enhanced environmental protection.
8. What is the typical power loss of the module?
The typical power loss is approximately 0.83 W.
9. Can this module be used with every S7-1500 CPU?
No. Compatibility depends on the specific S7-1500 CPU and supported synchronization interface. The applicable Siemens hardware documentation should be checked before installation.
10. What should be verified before ordering this synchronization module?
The S7-1500 CPU model, required synchronization distance, optical-fiber specification, existing synchronization-submodule part number, and applicable Siemens system documentation should be verified before ordering.
