Siemens 6AG1961-2BA41-7AA0 SIPLUS PS PSE200U 10 A Selectivity Module

Where It Fits in Industrial Applications

• Designed as a four-channel electronic selectivity module for Siemens 24 V DC power distribution systems.

• Distributes a 24 V DC supply across four individually protected output channels.

• Supports adjustable current response values from 3 A to 10 A per channel for selective overload and short-circuit protection.

• Suitable for demanding industrial power-distribution applications requiring channel-level status monitoring.

Key Strengths at a Glance

• Provides four independently monitored 24 V DC output channels.

• Delivers up to 10 A rated output current per channel at ambient temperatures up to 60 °C.

• Allows the current response value to be adjusted from 3 A to 10 A via potentiometers.

• Features conformal coating and an operating temperature range of approximately -25 °C to +70 °C in horizontal mounting.

Technical FAQs

1. What is Siemens 6AG1961-2BA41-7AA0?

6AG1961-2BA41-7AA0 is a SIPLUS PS PSE200U 10 A four-channel selectivity module based on Siemens 6EP1961-2BA41.

2. What is the primary function of this selectivity module?

The module distributes 24 V DC power to four output channels while monitoring each channel for overload and short-circuit conditions.

3. How many output channels does the module provide?

The module provides four individually monitored output channels.

4. What is the rated output current per channel?

Each output channel supports up to 10 A at ambient temperatures up to 60 °C.

5. Is the output current response adjustable?

Yes. The current response value can be adjusted from 3 A to 10 A for each channel using the corresponding potentiometer.

6. What input voltage does 6AG1961-2BA41-7AA0 require?

The rated supply voltage is 24 V DC, with an allowable input voltage range of approximately 22 V to 30 V DC.

7. Does the module provide channel-level status information?

Yes. Each channel provides status indication, allowing individual output conditions to be monitored.

8. How is the module installed?

The module snaps onto an EN 60715 35 × 7.5/15 DIN rail and uses screw terminals for power, output, auxiliary, and signaling connections.

9. What is the operating temperature range?

For horizontal mounting with natural convection, the operating temperature range is approximately -25 °C to +70 °C.

10. What should be verified before ordering this selectivity module?

The 24 V DC power supply capacity, required number of protected feeders, channel current requirements, mounting arrangement, and applicable Siemens documentation should be verified before ordering.
